JIMS 939 Instruction Sheet

No.1042-IS
I I n n s s t t r r u u c c t t i i o o n n S S h h e e e e t t F F o o r r T T o o o o l l N N o o . . 9 9 3 3 9 9 & & N N o o . . 9 9 5 5 8 8
13
8
11
10
7
9
12
Removal Notes:
1. On models with a hub plate, remove hub plate from wheel on opposite side of front brake rotor.
2. Some hubs may not provide adequate support for the main puller body. In these cases, center a used brake rotor
over the the hub to support the puller, or use JIMS No. 913 support plate for late cast front wheels with open hub.
Tools:
• 11/16" Wrench / socket
• 5/8" Open end wrench
• Torque wrench reading Ft/lbs + inch/lbs
• JIMS No. 913 Support plate for late cast wheels
A. Front Wheel Bearing Removal
1. Place the wheel vertically in a vice. (Protect the rim from being marred in the vice)
2. Assemble the remover tool. See parts list for the tool lubrication locations before using. Always replace both
bearings in hub.
A. Install No. 1042-1, 1042-2, or No. 1042-8 into bearing per bearing I.D. used. See parts list for the size
reference. Install puller tool into bearing by hand or use a rubber mallet to push through bearing I.D.
Stop pushing on bearing puller as soon as it has cleared the inside of bearing race. You should hear
and feel a slight click.
Note: Do not damage the threaded end of tool with hard face hammer.
B. Place bridge No. 1042-3 over bearing puller with the fingers of bridge facing the wheel. Lightly oil all
threads.
C. Place the large brass washer No. 1099 and large nut No. 1098 onto the puller and hand tighten the
nut until it stops at the top face of bridge.
CAUTION: Wear safety glasses. Excessive force may damage parts!
See JIMS
555 Dawson Drive, Camarillo, CA 93012 Phone 805-482-6913 • Fax 805-482-9224
Division of Thiessen Products, Inc.
1
3
2
15
6
• 3/4" Box wrench & socket
• 3/8" Allen
• 1- 1/8" Open end wrench
®
catalog for Hundreds of top quality professional tools.
The last tools you will ever need to buy.
Visit us on the web at www.jimsusa.com
Late Style Sealed Wheel
18
No.939
16
No.958
Note: Read entire instruction sheet before performing
14
•
•
17
4
•
5
Bearing Puller /
Installer
Use on all 2000-present Twin Cam
models, 2000-present Sportster
els, and 2002-present V-Rod.
Use on all 2007-present wheels using
25mm wheel bearings, with or without
ABS
work.
Remove wheels and prep per H-D® service
manual.
Refer to the exploded detail drawing for fit-
ment of No. 1042-1, No. 1042-2, and No.
1042-8 bearing puller.
Refer to the exploded detail drawing for fit-
ment of No. 1042-4, No. 1042-5, and No.
1042-9 bearing installer.
• Heat gun
• Lubricant
• Ratchet
Rev L
8-17
®
mod-
®
