What You Need - modway Cadence MOD-7157 Assembly Instructions Manual

Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
1 people recommended
for assembly
Furniture components:
1 Top Board
2 Bottom Board
3 Fixed Shelf
4 Bottom Skirt 1
5 Bottom Skirt 2
6 Bottom Skirt 3
7 Back Leg
8 Front Leg Left
9 Front Leg Right
10 Bar Side
Provided hardware:
A Cam Bolt Ø6 x 35 mm
B
Cam Lock Ø15 mm
C Cam Lock Ø12 mm
D Wood Dowel Ø8 x 30 mm
E Wood Dowel Ø6 x 30 mm
F Screw M 7 x 50 mm
G
Allen Key
H Screw M 4.5 x 12.5 mm
I Stopper
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1 11 Back Board
x1
x1
x1
x1
x1
x2
x1
x1
x2
x18 J
K
x14
x4 L

What you need:

x10
x4
Phillips
x4
x1
x8
x4
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
you're assembling the product.
Keep all components and packaging out of reach of children or animals
x1
10
8
7
4
Bracket x2
Screw Cap Ø15 mm x8
Rubber x2
Phillips Head Screwdriver
1
10
11
3
9
2
6
7
5
