B.6 USER MENU
The user menu is entered by holding simultaneously the up and
down arrow buttons for 2 seconds. Individual parameters of the
user menu are visible as consecutive indications displayed on the
main screen as described in the table below.
Depending on the controller series, some operating modes and
parameters in the user menu may not be visible.
The parameters are selected using the up or down buttons and
the 'ü ü ' button is confirmed by the selection.
Table B-1: Thermostat menu
Code Alert description
P01 Schedules
P02 Copying Schedules.
P03 Pairing
P04 Setting the clock.
P05 'Day' preset temp.
P06 'Night' preset temp.
P07 'Antifreeze' Preset temp.
P08 'Party' Preset temp.
P09 Time duration of the 'Party' mode. (hours)
P10 'Holiday' Preset temp.
P11 Time duration of the 'Holiday' mode. (days)
P12 Time duration of the 'Out of house' mode .(hours)
P13 Time duration of the 'Airing' mode. (mins)
P15 Activate/Deactivate Key sounds.
P16 Activate/Deactivate Alarm sounding.
Turning OFF will only display alarm symbol on LCD screen.
P17 Activate/Deactivate Alarm sounding OFF between 22.00 and
06.00.
P18 Adjust Screen contrast. (%)
P19 Adjust LCD screen backlight. (%)
P20
Room thermostat temperature hysteresis. (
P21 Activate/Deactivate parental lock.
P30 Display active Radio strength from the receiver. (%)
P31 Thermostat program version.
P32
Thermostat temperature correction (
P34 Restore factory settings
P35 Thermostat address.
P41 Activate/Deactivate outdoor temperature indication.
P42 Show/Hide display on clock screen.
B.7

HOTEL MODE

Refer to Appendix A.6 for setting Wireless thermostat to Hotel
mode.
B.8 MEMORY RESET OF THE WIRELESS
RECEIVER
To perform a memory reset, hold down the P button in the receiver
for approximately 8 seconds. The LED will blink after releasing the
button confirming the action.
After performing a reset any required thermostats will need to be
re-paired.
Appendix B: Wireless Thermostat and Receiver
B.9
The Smart controller communicates alerts to the thermostat when
present in the system. Refer to Table B-2 for determining the fault
of a wireless thermostat display.
Table B-2: Thermostat alarm codes
Code
01
02
03
04
05
06
07
08
09
11
12
13
14
15
16
17
19
20
21
22
23
24
25
26
°C °C
)
27
28
°C °C
)

ALARMS

Alert description
Outside Temperature sensor error
No communication with the controller
No compatibility of programs
Panel temperature sensor error
DHW sensor error
Upper buffer temperature sensor error
Lower buffer temperature sensor error
Circuit 2 temperature sensor error
Circuit 3 temperature sensor error
Anti-freeze active
No communication with the thermostat
No communication with thermostat circuit 1
No communication with thermostat circuit 2
No communication with thermostat circuit 3
Alarm from digital input
No flow detected
Too often no flow detected
No communication with heat pump module
Circuit 4 temperature sensor error (not used)
Circuit 5 temperature sensor error (not used)
Circuit 6 temperature sensor error (not used)
Circuit 7 temperature sensor error (not used)
No communication with thermostat circuit 4 (not used)
No communication with thermostat circuit 5 (not used)
No communication with thermostat circuit 6 (not used)
No communication with thermostat circuit 7 (not used)
