All manuals and user guides at all-guides.com Table of Contents Manual Documentation Number: ESP904-4513m B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com...
. Virtual COM port provides access to any of the ports on the LPT) ESP904, like any other serial port (legacy, PCI, USB or PCMCIA) on the computer. Any program running on the computer and using Windows-based COM ports can access the serial devices attached to the...
Direct IP programs to communicate with the asynchronous serial ports on the ESP904. In this type of application the ESP904 is configured as a TCP or UDP server. The socket program running on the PC establishes a communication connection with the ESP904. The data is sent directly to and from the serial port on the server.
All manuals and user guides at all-guides.com Introduction To use this mode, the ESP904 must be set to either TCP/server or UDP/server with a designated communication port number. The virtual COM driver is the TCP or UDP client. Paired Mode is also called serial tunneling.
Hardware Setup Figure 1. Quick Start Hardware Setup Step 1: Connect the ESP904 to the network using a standard network cable Step 2: Connect the ESP904 to the RS-232 serial device. If the serial device is configured as a DCE use a straight-through serial cable. If the serial device is configured as a DTE use a crossover (null modem) cable.
Serial Servers connected to the LAN will appear in the window. Serial Server List Step 2: Double click the first ESP904 port on the list (4000) to bring up the configuration screen. Server Properties Figure 2. The Server Properties Window Step 3: Change the as required.
Baud Rate Data/Parity/Stop , and Flow Control to match the configuration of the serial device connected to the ESP904 serial port. Step 4: Communications with the serial device should now be operational. Chapter 1 Manual Documentation Number: ESP904-4513m B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
ESP904 Serial Server Module Power supply This manual CD-ROM disc with manual, VLINX ESP Manager and Virtual COM Driver software for Windows 98/ME/2000/2003/XP/NT 4.0/Vista ESP904 Connections, Indicators and Reset Switch The ESP904 has: Seven indicator LEDs ...
RJ-45 receptacle mounted in the top edge of the ESP904 chassis. The ESP904 can be connected to an Ethernet hub, switch, or wall plate using a standard straight-through RJ-45 (male) Ethernet cable. To connect directly to an RJ45 Ethernet port on a PC or laptop a crossover Ethernet cable must be used.
Figure 4. Top View of the ESP904 Serial Ports The ESP904 has four serial ports, each configurable through software as RS- 232, RS-422 or RS-485 interfaces. When in RS-232 mode the interfaces are configured as DTEs (Data Terminal Equipment).The connectors are DB-9M.
In Upgrade Mode firmware can be uploaded from a PC via its serial port to the ESP904 Port 1, using RS-232. Upgrading also can be via the network connection, using the ESP Manager software and a virtual COM port mapped to the ESP904 Port 1.
RS-485 Receiver Biasing network does not supply it. Remove the two side-cover screws of the ESP904, slide the cover off and re-position the bias jumpers (shown open in the figure below) to enable biasing (shorting). Figure 6. Internal Setting to Select RS-485 Bias (For more information on RS-485 Receiver Biasing, see B&B Electronics RS-...
All manuals and user guides at all-guides.com Making Hardware Connections ESP904 Serial Port Connector Pin-outs Pin-outs for RS-232, RS-422 and RS-485 operation are shown below. DB-9M RS-232 RS-422 RS-485 Signal Name Carrier Detect RXDA (−) Receive Data RXDB (+) Transmit Data...
The Windows-based software makes ESP Manager Virtual COM Port configuration fast and easy. If using Windows, installing the ESP Manager software and setting up virtual COM ports to configure the ESP904 is recommended. Software Installation includes: VLINX ESP software ...
Page 24
The installation progress will be shown until complete. Chapter 3 Manual Documentation Number: ESP904-4513m B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com...
Monitoring Port Status Saving and Loading Configuration Files Hardware Setup Step 1: Connect the ESP904 to the LAN or to a computer Ethernet port. Figure 15. Ethernet Connection via a LAN Manual Documentation Number: ESP904-4513m Chapter 4 B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
LAN addressing scheme. Searching window shown until active ESP901/ESP902/ESP904 serial servers on the LAN are listed in the window. Serial Server List Figure 20. The Search VLINX ESP Dialogue Box Configure Server Properties window displays the current configuration properties...
Disable Enable . Disable is the normal, or default, setting. When enabled, the ESP904 will send a DHCP request to the DHCP server, which will assign a dynamic IP address, net mask, and Chapter 5 Manual Documentation Number: ESP904-4513m B&B Electronics Mfg Co Inc –...
All manuals and user guides at all-guides.com Server Properties Configuration gateway to the ESP904. If a DHCP server is not available on the network the ESP904 will time out after 10 seconds and the default values will remain. A dynamic address assigned by the DHCP server may change if the ESP904 loses the Ethernet connection or power is removed.
Click Update to store settings for each port before changing to the other port. Baud Rate The serial port baud rate on the ESP904 must match the serial baud rate of the connected device unless using Virtual COM mode. In Virtual COM mode the software program will establish serial settings.
In all modes of operation, , the port number set in Direct IP Virtual COM the ESP904 menu must match the Virtual COM or socket software port settings. Example: The Virtual COM default setting is TCP/UDP Port 4000. If the port # property is changed to 4001, the virtual COM port will have to be changed to 4001.
This is a security feature activated by entering the IP address of the desired client. The ESP904 will only communicate with the listed IP address and all other requests for connection will be filtered out. The ESP904 must be set up as a to use this feature.
Page 47
If you leave any Web Server page without saving, any changes you have made will be ignored. Manual Documentation Number: ESP904-4513m Chapter 5 B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
For example, in a computer already having a COM1 and COM2, COM3 to COM 254 is available for the ESP904. It is recommended that COM Port 5 or higher be selected. The virtual COM port looks like a standard COM port to most Windows based applications which allows the software to open a connection with the serial port located anywhere on the LAN/WAN.
Page 50
All manuals and user guides at all-guides.com Installing Virtual COM Port The program searches the LAN for all available ESP901/ESP902/ESP904 Serial Servers. When complete, the window appears and Found Server displays a list of the servers that were found. Figure 37. The Found Server Window...
Page 51
The ESP Server must be set to match. Manual Documentation Number: ESP904-4513m Chapter 6 B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
Installing Virtual COM Port Matching the ESP904 and Virtual COM Port Settings The settings of the virtual COM ports in the Device Manager and the ESP904 Configuration menu must match. If the settings do not match, the virtual COM ports will not work. If these settings are changed in the Device Manager, it will only affect the operation of the virtual COM port.
Page 53
Device Manager Refresh if Windows does not auto refresh. Manual Documentation Number: ESP904-4513m Chapter 6 B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
Page 54
Installing Virtual COM Port Chapter 6 Manual Documentation Number: ESP904-4513m B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com...
Highlight the mapped COM port number to be removed. Figure 42. The ESP Manager Window Manual Documentation Number: ESP904-4513m Chapter 7 B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
Page 58
Removal Figure 46. Confirm Device Removal Step 5: click to proceed. The ESP904 COM # will be removed and the Device Manager window will refresh and display the remaining COM ports Chapter 7 Manual Documentation Number: ESP904-4513m B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
Upgrading Via ESP Manager The ESP Manager software can upload new firmware to the server using a direct PC connection via Port 1 of the ESP904, or using a virtual COM port mapped to Port 1. If connecting directly to a computer serial port, connect a null modem cable between the Computer RS-232 port and the ESP904 Port1 serial port.
If connected directly from the computer to Port 1 of the ESP904 the port will typically be COM1 or COM2 b. If using a virtual COM port to upgrade via the network, identify the virtual COM number and address mapped to Port 1 on the ESP904.
Mode and the COM port on the Computer. See Chapter 5 for details of each Server Property Settings. Console Mode Setup Step 1: Apply power to the ESP904. The power and ready LED will light. Step 2: Using VT100 Terminal...
If the server is accessed with a password but no changes are made, to end before disconnecting. Reset Manual Documentation Number: ESP904-4513m Chapter 9 B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
All manuals and user guides at all-guides.com Using the Web Server The Web Server can be used to configure the ESP904 from any web browser software (such as Internet Explorer). Server properties can be set up using two browser pages.
Page 66
The following page will appear: Chapter 10 Manual Documentation Number: ESP904-4513m B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com...
Page 67
Using the Web Server Figure 52. The Web Server Operation Page Click to store changes to the ESP904. Settings for each Port must be Save saved separately. If new property settings are not saved before leaving this page they will not take effect.
Page 68
Using the Web Server Chapter 10 Manual Documentation Number: ESP904-4513m B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com...
Console mode you may not be able to access it using Telnet. In this case use ESP Manager, Console Mode or Web Server for configuration. Manual Documentation Number: ESP904-4513m Chapter 11 B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
Page 71
The configuration menu will appear and display the current settings. Manual Documentation Number: ESP904-4513m Chapter 11 B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
All manuals and user guides at all-guides.com ESP904 Technical Data Hardware and ESP904 Serial Server module Included Power Supply: 12 VDC/1A (tip positive/sleeve negative) Accessories Power Plug: (Area Dependent: North America 120VAC/60Hz, Europe/United Kingdom 220/240VAC/50Hz) Manual: Paper copy of this manual, PDF available...
All manuals and user guides at all-guides.com RS-232 Connections ESP904 DB-9 Pin-outs in RS-232 Mode RS-232 RS-232 DB-9M Signal Name Carrier Detect Receive Data Transmit Data Data Terminal Ready Signal Ground Data Set Ready Request To Send Clear To Send Ring Indicator Figure 57.
RS-232 Straight-through Cable Connections In the RS-232 mode, the ESP904’s ports are configured as DTEs like a computer. If the device connected to the ESP904 is configured as a DCE use a straight through cable wired as shown below: RS-232 Signal Names...
All manuals and user guides at all-guides.com RS-422 Connections ESP904 DB-9 Pin-outs in RS-422 Mode RS-422 DB9M Signal Name Direction RS-422 Receive Data A (−) RXDA (−) Receive Data B (+) RXDB (+) Transmit Data B (+) TXDB (+) Transmit Data A (−) TXDA (−)
Page 82
The RS-422 mode can be used for full duplex 4-wire RS-485 operation provided that the ESP904 is acting as a sole master connecting to all the slave devices, and all slave devices share the Receive signal lines to the master. Set Flow Control for none, and omit connections to RTS/CTS line pairs.
Page 83
Figure 66. RS-422 Connection with No Flow Control Manual Documentation Number: ESP904-4513m Appendix B B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
All manuals and user guides at all-guides.com RS-485 Connections ESP904 DB-9 Pin-out in RS-485 Mode RS-485 Direction RS-485 DB9M Signal Name Data B (+) In/Out DATA B (+) Data A (−) In/Out DATA A (−) Signal Ground Figure 67. DB-9 Pin-out in RS-485 Mode...
Page 86
To connect 4-Wire RS-485 devices, the RS-422 Mode can be used provided the ESP904 will be connected as a master in a single master system. If using multiple masters, the ESP904 cannot be used, as it does not tri-state the transmitter in RS-422 mode.
Brown Figure 69. Pin-out for a Standard Ethernet Cable Manual Documentation Number: ESP904-4513m Appendix D B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com...
