Ma in Purposes and Scope of Application
1
NJG2 solid-state relays (SSRs) are suitable for resistive, inductive and
capacitive loads, and can be widely used in various automation control
fields such as CNC machinery, plastic machinery, food machinery,
packaging machinery, textile machinery, electric furnace heating/
thermostatic systems, petrochemical instruments and equipment,
entertainment facilities. NJG2 SSRs are available with an input control
voltage of DC3~32V/AC90~250V, an output current of 10A~120A, and
an output voltage of AC24~240V/AC40-480V/DC12-250V.
2
Model Specifications and Definitions
N JG 2 － □ □ □
(1) (2) (3) (4) (5) (6) (7)
(1) Manufacturer identification code
(2) Solid-state relay
(3) Design series number
(4) S: Single-phase; T: Three-phase
(5) Input voltage type, D: DC; A: AC
(6) Output voltage type, D: DC; A: AC
(7) Input voltage, 032: DD:DC 5~32V DA: DC 3-32V
(8) Maximum load current, 10A/15A/20A/25A/30A/40A/60A/80
(9) Load voltage, 220: AC24~240V 380: AC40~480V
(10) F: Closed type, omitted by default
□－ □
250: AC90~250V
A/100A/120A
024: DC12-250V
□
(8) (9) (10)
