JAMES MARTIN VANITIES Columbia 883-V24-AGR Manual

Page: 1 o f 11
Columbia Series Vanity: 883-V24-AGR 883-V24-GW 883-V24-LTO
Columbia Series Metal Bases: 883-B24-BNK 883-B24-MBK 883-B24-RGD
Assembly/Installation Instructions
For your safety and to achieve the best possible installation of this cabinet,
James Martin Vanities always recommends you consult with a professional contractor.
Two people are required for the assembly and installation of these cabinets.
Important Notes: This vanity cabinet may be used freestanding, or may be mounted to a wall (floating). If
you are using this cabinet as a freestanding unit with the stainless steel base, please follow the
instructions on pages 06 - 1 1 *.
If you are using this cabinet as a wall mounted (floating) unit, please refer to pages
Door Pulls:
Three colors of door pulls (BNK Brushed Nickel)/ (MBK Matte Black)/ (RGD Radiant Gold) are included
with the cabinet, so you may choose the color which best suits your room.
Wood Shelf:
For more convenient shipping, the wood shelf used on the optional metal base, is included with the
cabinet. If you are wall mounting your cabinet, the shelf is an extra item and may be used for other
projects.
Materials
for
Installation:
A pre-attached metal mounting (French Cleat) brackets
= =
I
back of vanity cabinet
Step 1 Notes:
The metal mounting brackets have been
pre-installed to the backside of the cabinet
16" from the bottom of the cabinet, remove
one piece from the back of the cabinet .
For Warranty information, please visit jamesmartinvanities.com
Customer Service: 512-795-4171
Level
a
= = =
I
B
(0
J
T"'""
JAMES 1\1\ARTIN
I
�
Tape
Measure
0)
C\J
Step 2 Notes:
Draw a horizontal line on the wall at your desired
height. For this cabinet, most people use a
height of 29"
®
VA N I T I ES
01 - 05
* .
Pencil
,,. - - - -
--, - - -- - '
......
I
I
I
I
I
,.. -t
,.. ...- I
Wall
Version:202311
