LEGRAND 2 810 92 Series Manual

SOUND LIGHT DETECT W/O NEUTRAL
2 810 92xx xx:MW MB MG DS DB CH BA BB BC
2 810 92xx yy yy:MY SG
Safety instructions
This product should be installed in compliance with installation rules, preferably by a qualified electrician. Incorrect installation and/or incorrect
use can lead to risk of electric shock or fire.
Before carrying out the installation, read the instructions and take account of the product's specific mounting location.
Do not open up, dismantle, alter or modify the device except where specifically required to do so by the instructions.
All Legrand products must be opened and repaired exclusively by personnel trained and approved by Legrand. Any unauthorised opening or
repair completely cancels all liabilities and the rights to replacement and guarantees.
Use only Legrand brand accessories.
Presentation
Technical characteristics
240V~ 5....400W
100V~ 5....200W
Incandescent lamp
Electronic step-down converter for extra low-voltage incandescent lamps(e.g.halogen)
Iron core transformer for extra low-voltage incandescent lamps(e.g.halogen)
Fluorescent lamp
Self-ballasted fluorescent compact lamp(CFL)
Self-ballasted LED lamp
Inductive ballast fluorescent lamp with compensator
Wiring
Wire the connected switch.
L
N
-20 ...+70 -5 ...+35
Sound day/dusk
5....200VA 20....200VA
5....100VA
20....100VA
L1
≥40mm
30S
3....200VA 3....100W
3....100VA 3....50W
...
Ln（n≤10）
L2
1
V
100-240V~
1...4mm
50/60Hz
high/low
3....100W 7....100VA
3....50W
7....50VA
L
2
