Summary of Contents for TRENDnet TFM-561U
-
Page 2: Table Of Contents
Table of Contents Package Contents ..........................2 Comprehensive Modem Installation Instructions ................2 Modem Installation ........................2 System Setup ............................4 Setup instructions for Windows 7 ....................4 Setup instructions for Vista ......................8 Setup instructions for Windows XP/2000 ..................12 Linux ............................16 Communication Software ......................17 Limited Warranty .......................... -
Page 3: Package Contents
Package Contents TFM-561U Multi-Language Quick Installation Guide CD-ROM (Utility & User’s Guide) One RJ-11 telephone cable Please contact the local dealer if there any item missing. Comprehensive Modem Installation Instructions Modem Installation This section will provide instructions for the installation of your modem. There are hardware installation and system setup two parts for the modem. - Page 4 NOTE: The phone wall jack must be an ANALOG phone line (found in most of homes). Many offices are equipped with digital phone lines. Please be sure that you know which type of phone line you are using. The modem will be damaged if using a digital phone line. LED Indicators LINK: ...
-
Page 5: System Setup
System Setup Setup instructions for Windows 7 STEP 1. When the system was complete, windows will detect the modem automatically. The system have auto install the modem for system default STEP 2. Insert the included CD-ROM into computer’s CD-ROM drive. STEP 3. - Page 6 STEP 4: Click Install Driver, and then select the driver which suitable for your Operation System. STEP 5. Click OK to install the driver. - 5 -...
- Page 7 STEP 6. Click Install this driver software anyway STEP 7. Click OK to finish the installation STEP 8. To check your installation, go to Start > Setting > Control Panel > Double-click on the Phone and Modem Options icon. - 6 -...
- Page 8 STEP 9. Verify if the modem TFM-561U USB Modem has been installed to your computer. Click OK to exit. - 7 -...
-
Page 9: Setup Instructions For Vista
Setup instructions for Vista STEP 1. When the Found New Hardware Wizard appears, click Cancel STEP 2. Insert the included CD-ROM into computer’s CD-ROM drive. STEP 3. When Autoplay screen pop up, Click Run AUTORUN.EXE STEP 4: Click Install Driver, and then select the driver which suitable for your Operation System. - Page 10 STEP 5. Click OK to install the driver. STEP 6. Click Install this driver software anyway - 9 -...
- Page 11 STEP 8. To check your installation, go to Start > Setting > Control Panel > Double-click Phone and Modem Options icon. STEP 9. Verify if the modem TFM-561U USB Modem has been installed to your computer. Click OK to exit.
- Page 12 - 11 -...
-
Page 13: Setup Instructions For Windows Xp/2000
Setup instructions for Windows XP/2000 STEP 1. When the Found New Hardware Wizard appears, Select No, not this time, then click Cancel STEP 2. Select the Install from a list or specific location [Advanced] then click Next STEP 3. Insert the included CD-ROM into the CD-ROM drive. Select Include this location in the search, then click Browse to find available driver described as D:\Driver\Win2K_XP (D is the letter of the CD-ROM driver) - 12 -... - Page 14 STEP 4. Click Continue Anyway to install the driver. STEP 5. Click Finish to finish the installation - 13 -...
- Page 15 STEP 6. To verify the installation, go to Start > Setting > Control Panel > Double-click the Phone and Modem Options icon. STEP 7. Verify if the modem TFM-561U USB Modem has been installed to your computer. Click OK to exit.
- Page 16 - 15 -...
-
Page 17: Linux
You can refer the below how to do install Harley USB Modem under Linux. $ cat /proc/bus/usb/devices $ modprobe usbserial vendor=0x1111 product=0x2222 ----> (1111 & 2222 is VID & DID) <TFM-561U Vendor =0x0572 product=0x1329> $ dmesg $ minicom -s ---> ( dev/ttyUSB0 *... -
Page 18: Communication Software
Communication Software Netwaiting and Classic Phone Tools included on the CD-ROM are optional software programs. You do not have to use these two software programs with your new modem. Netwaiting allows you to manage incoming/outgoing telephone communication while connecting to the Internet over a single phone line (Call-waiting service is required). Classic Phone Tools will let you use basic fax functions. -
Page 19: Limited Warranty
TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment. - Page 20 Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to http://www.gnu.org/licenses/gpl.txt...
- Page 21 - 20 -...
