- Page 1 User Manual Original Instructions Elevator Controller Panel Bulletin Number 150 and KCM831...
-
Page 2: Important User Information
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. -
Page 3: Table Of Contents
Environmental Specifications ........22 Starter Cross Reference (Approximate) ......23 Rockwell Automation Publication 150-UM010C-EN-P - June 2019... - Page 4 Table of Contents Rockwell Automation Publication 150-UM010C-EN-P - June 2019...
-
Page 5: Summary Of Changes
Standards per UL 508 and CS C22.2 No. 14-95) as solid-state motor controllers in File E96956. They are also UL Listed and cUL Listed per UL 508 and CAN/CSA B44.1-96 as elevator controllers in File E3125. Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 6: Additional Resources
Provides general guidelines for installing a Rockwell publication 1770-4.1 Automation industrial system. Product Certifications website: rok.auto/certifications Provides declarations of conformity, certificates, and other certification details. You can view or download publications at http://www.rockwellautomation.com/global/literature-library/overview.page. Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 7: Starter Selection
150-C27NCD-K1 150-C27NCA-K2 12.3…37 150-C64NCD-K1 150-C64NCA-K2 14.3…43 150-C74NCD-K1 150-C74NCA-K2 200…600V AC, 50/60 Hz 20…60 150-C104NCD-K1 150-C104NCA-K2 28.3…85 150-C147NCD-K1 150-C147NCA-K2 34…135 150-C234NCD-K1 150-C234NCA-K2 (1) Motor FLA must fall within the specified range to operate correctly. Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 8: Catalog Number Breakdown
150-C64NCD-K1 150-C37NCD 100-C37D00 150-C74NCD-K1 150-C43NCD 100-C43D00 150-C104NCD-K1 150-C60NCD 100-C60D00 150-C147NCD-K1 150-C85NCD 100-C85D00 150-C234NCD-K1 150-C135NCD 100-D180D11 150-C27NCA-K2 150-C16NCD 100-C16L10 150-C64NCA-K2 150-C37NCD 100-C37L00 150-C74NCA-K2 150-C43NCD 100-C43L00 150-C104NCA-K2 150-C60NCD 100-C60L00 150-C147NCA-K2 150-C85NCD 100-C85L00 150-C234NCA-K2 150-C135NCD 100-D180A11 Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 9: Installation
71.9 (2.83) 94.2 (3.71) 37.1 (1.46) 30.2 (1.19) 4.3 lbs (2.0 kg) C27…C64 - Legacy 431.8 (17.0) 304.8 (12.0) 115.4 (4.54) 406.4 (16.0) 279.4 (11.0) 3.4 (0.13) — — 5.3 lbs (2.4 kg) Rockwell Automation Publication 150-UM010C-EN-P - June 2019... - Page 10 285.8 (11.3) 273.1 (10.8) 21 lbs (9.5 kg) C234 - KCM831 & Legacy 457.2 (18.0) 431.8 (17.0) 208.6 (8.21) 3.3 (0.13) 406.4 (279.4) 279.4 (11.0) 285.8 (11.3) 273.1 (10.8) 51 lbs (23 kg) Rockwell Automation Publication 150-UM010C-EN-P - June 2019...
-
Page 11: Installation Precautions
0.5…2.5 mm 0.5…2.5 mm 0.5…2.5 mm Control Terminals 4…8 in.-lb 4…8 in.-lb 5.3 in.-lb 5.3 in.-lb 5.3 in.-lb 5.3 in.-lb Tightening Torque 0.5…0.9 N•m 0.5…0.9 N•m 0.6 N•m 0.6 N•m 0.6 N•m 0.6 N•m Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 12: Connection Diagrams
Motor 1, 7 2, 8 3, 9 6, 12 4, 10 5, 11 Terminals Incoming Lines Motor 12-Lead 460V High-voltage Motor Connections Starter Jumper Terminals 4, 7 Motor 5, 8 Terminals 6, 9 Rockwell Automation Publication 150-UM010C-EN-P - June 2019... - Page 13 Motor 1, 7 2, 8 3, 9 6, 12 4, 10 5, 11 Terminals Incoming Lines Motor 12-Lead 460V High-voltage Motor Connections Starter Jumper Terminals 4, 7 Motor 5, 8 Terminals 6, 9 Rockwell Automation Publication 150-UM010C-EN-P - June 2019...
-
Page 14: Line Connection Diagrams, Power, And Motor Wiring
Figure 7 - KCM831 Devices— C234 C27…C147 Devices C234 Devices 1/L1 3/L2 5/L3 L1 L2 L3 SMC-3 1/L1 3/L2 5/L3 A1 A2 L1 L2 L3 2/T1 4/T2 6/T3 Incoming Line Connections L1 L2 L3 Incoming Line Connections Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 15: Chapter 3 Dip Switch Settings
If the motor does not reach speed before the time expires, the controller will continue under silicon- controlled rectifier (SCR) control and not close the bypass contactor. Rockwell Automation Publication 150-UM010C-EN-P - June 2019... - Page 16 Normal start/run command is given. Up-to-speed mode means that the contact changes state only when the controller is in bypass. Aux#2, when Up-to-speed added, operates opposite of this programming. Rockwell Automation Publication 150-UM010C-EN-P - June 2019...
-
Page 17: Motor Overload Setting
FLA: – Take the motor FLA and divide by 1.73 or follow Table Table 15 - Motor FLA/Overload Settings Motor FLA Motor FLA Motor FLA Motor FLA Motor FLA Motor FLA Rockwell Automation Publication 150-UM010C-EN-P - June 2019... - Page 18 Basic Timing Diagram, No Soft Stop Control Power Fault Occurs Fault Reset Start Enable Closed Fault Contactor Open Closed Fault Contact (97/98) Open Possible Aux Contact Configurations Closed Up to Speed Open Closed Normal Open Rockwell Automation Publication 150-UM010C-EN-P - June 2019...
-
Page 19: Startup And Troubleshooting
The conditions are as follows: • LED Off – No control power or start command given • LED On – The device is active with starting, running, or stopping. Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 20: Troubleshooting Steps
All Conditions • Check resistance of coil, replace if measured open applied • Verify auxiliary contact of controller is properly changing state, replace auxiliary contact or controller if contact does not operate correctly Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 21: Electrical
Control Power Requirements 74/104/147 200 mA @ 120V AC, 100 mA @ 240V AC 200 mA @ 120V AC, 120 mA @ 240V AC 27/64 — Fan Power Requirements 74/104/147 — 20 VA Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 22: Mechanical Specifications
Resistance to Shock Non-operational 5.5 G Environmental Table 23 - Environmental Specifications Specifications Attribute Value 0…50°C (32…122°F) Open Operating Temperature 0…40°C (32…104°F) Enclosed Altitude 2000 m (6560 ft) Humidity 5…95% (non-condensing) Pollution Degree Rockwell Automation Publication 150-UM010C-EN-P - June 2019... -
Page 23: Starter Cross Reference (Approximate)
US520619078 or US520496074 150DP-A78NBD-K1-FC-7FA2 150-D74NCD-K1 US521349074 150-C74NCD-K1 US520620078 or US520496074 150DP-A78NCD-K1-FC-7FA2 US520620104 or US520496104 150DP-A104NCD-K1-FC-7FA2 150-D104NCD-K1 US521349104 150-C104NCD-K1 US520495146 or US520496147 150DP-A146NAD-K1-FC-7FA2 150-D147NCD-K1 US521349147 150-C147NCD-K1 US520619146 or US520496147 150DP-A146NBD-K1-FC-7FA2 US520495168 150DP-A168NAD-K1-FC-7FA2 — US521349234 150-C234NCD-K1 Rockwell Automation Publication 150-UM010C-EN-P - June 2019... - Page 24 Chapter 5 Specifications Notes: Rockwell Automation Publication 150-UM010C-EN-P - June 2019...
-
Page 26: Rockwell Automation Support
Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, Rockwell Automation, Rockwell Software, and SMC are trademarks of Rockwell Automation, Inc. KCM831 is a trademark of KONE, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
