Summary of Contents for Rockwell Automation Allen-Bradley OptixPanel 2800C AS Series
- Page 1 OptixPanel Compact Operator Panel Bulletin 2800C User Manual Original Instructions...
- Page 2 If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.
-
Page 3: Table Of Contents
Clean the Integrated Display ..........41 Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 4 Reinstall the Cover ............47 Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 5: Catalog Numbers
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system. Product Certifications website, rok.auto/certifications Provides declarations of conformity, certificates, and other certification details. - Page 6 Preface Notes: Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 7: Product Description
Aluminum and glass True Flat bezel with multi touch capacitive touchscreen (GL) Sizes available 4.3 in. W [16:9] 7.0 in. W [5:3] Widescreen (W) format is offered with analog resistive and projective capacitive (PCAP) touch screens. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 8 Features: • IP rating: IP65. • Seal Type: Polyurethane gasketing elastomer. • Frame material: EN AW-5754, H22 EN 485-1. Figure 4 - Construction detail Description Aluminum Frame 5 wires resistive touchscreen Glass Seal Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
- Page 9 NO STEP Features: • IP rating: IP65. • Seal Type: Polyurethane gasketing elastomer. • Frame material: Aluminum alloy 5754. Figure 7 - Construction detail Description Tempered glass PCAP capacitive multi-touch touchscreen Aluminum frame Seal Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 10: Side View
Recess for fixing clips Figure 9 - 7.0 in. side view Description Aeration holes Recess for fixing clips Connectors/LEDs/Buttons *LED 1 is present only in: OptixPanel Compact systems 7.0 in. size. OptixPanel Compact - rear view Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 11: Standards Compliance And Certifications
European Union. Obtain permission from the local power authority before you connect any computer configuration that draws more than 75 W of AC power directly from the public mains. All other I/O cables must be used only indoors. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 12: Technical Specifications
24V 0.4A SELV Power supply input Voltage Range 18…32V Battery 1 x BR1225A Internal access Operating Temperature 0°…+50 °C (32…122 °F) Storage Temperature -20°…+60 °C (-4…+140 °F) Operating / Storage Relative humidity 20%…90% RH (non-condensing) Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 13: Installation
The indicated environmental conditions must be observed. • Verify the operating temperature of the equipment to ensure that the specified temperature range is not exceed after it is installed in the end user application. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 14: Unpack
• The site must be indoors and non-hazardous. • The site must not expose the computer to direct sunlight. • The operator panel can operate in the following environmental conditions: - Operation temperature: 0…+50 °C (32…122 °F). Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 15: Mounting Requirements
IMPORTANT The vertical position can be tilted up to 20° forward or backward from the upright position. In that case the maximum operating temperature will be reduced from 50°C (122 °F) to 45°C (113 °F). Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 16: Approximate Dimensions
0.5 mm (0.01 in.). • For a uniform gasket seal, ensure the surface is clean and free of debris and that the roughness of the panel surface must be ≤ 120 microns (Rz 120). Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 17: Install The Operator Panel
From the front of the panel insert the computer into the cutout (A) and rotate it (B) until it adheres completely to the panel (C). • Slide the mounting clips into the holes on all four sides of the computer and repeat the following procedure for all the clips. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 18: Dc Power Supply Guidelines
I/O Ports ATTENTION: tighten the mounting clips to the specified torque to provide a proper seal and to help prevent product damage. Rockwell Automation assumes no responsibility for water or chemical damage to the computer or other equipment within the enclosure because of improper installation. -
Page 19: Connect Dc Power
4. Insert each stripped end into the DC terminal block and fix it with the corresponding screws (7) with 0.22...0.25 N•m (0.16...0.18 lb•ft) torque. 5. Insert the cable tie (9) through the slots of the terminal block (11) connector clamp [step (A)]. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 20 11. Apply power to the Operator Panel. 12. LED (a) and LED (b) illuminate green. 13. The operating system desktop appears after few seconds. LED (b) is present only on 7.0 in. size. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 21: Operation
• operator error in the control of the system • proper use of E-stops and other safety practices You must provide means to achieve a safe state during anomalies and verify that the system has adequate redundancy for critical functions. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 22: Touchscreen Calibration
Press Calibrate. • Follow the instructions on the screen and press on the crosses on the screen as they appear. The new calibration parameters are automatically saved as you exit the calibration procedure. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 23: Restart/Factory Reset
4. Release the button and wait. 5. At the end, the system restarts. Table 6 - Factory Restore LED Color Function Blue Blinking blue when factory restore procedure is in progress. Factory Restore LED Normal state. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 24 Chapter 3 Operation Notes: Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 25: Configuration
The device can be configured through the System Manager application, accessible locally from the device or remotely via any web browser. Access from device 1. After it is powered, the Device starts showing the boot logo. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 26 ATTENTION: Take note of the new password! Admin account is required to transfer the Optix Application via FactoryTalk Optix Studio. If you lose the password, you must restore the device to Factory Defaults, which deletes the Optix Application and system updates. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 27: System Manager
Optix Application and system updates. System Manager The System Manager interface is divided into the following sections: • General • FT Optix • Interfaces • Networking. • FT Remote Access • Users • Diagnostic Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 28: General
WAN - Enable this option to allow access to the System Manager through the device's WAN port. This makes it easy for users to remotely manage and configure the device via the web interface. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 29 Calibrate Turn on this option to start the display calibration process, which enhances the touchscreen precision. When it is activated, a small red cross appears on the screen for you to tap. After Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
- Page 30 NTP server to listen for connections on the standard UDP port 123. Selecting no interface will disable the local NTP Server. External storage USB Enabled This check-box allow to activate/deactivate USB ports and external devices connected to them. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 31: Ft Optix
Fom FT Optix Studio, you select Save > Export > FactoryTalk Optix Application choosing OptixPanel Standard/Compact as target. • Define a password for the package. • Transfer the package to an USB Memory. • Plug the USB Memory into an available USB port. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 32: Interfaces
Section to set the device’s interfaces. Eth2: WAN Mac address The MAC address section displays the unique identifier for the Eth2 port of the device. This address is essential for network communication and device identification purposes. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 33: Networking
WAN – Select this option to be able to reach via VPN the devices on the subnet of the Eth2 port. • LAN - Select this option to be able to reach via VPN the devices on the subnet of the Eth1 port. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 34: Ft Remote Access
Connection port Select the appropriate port for connecting to the FactoryTalk Remote Access organization's servers. The available options include Auto (automatic selection), 80, 443, or 5935. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 35: Users
Date and Time, without the option Set local NTP server interfaces. • System information and Legal notices. • Entitlements (activate and Details). • WAN. • FactoryTalk Remote Access, without Connection status, Server, and Availability mode. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 36: Diagnostic
Firmware update is supported only via USB Memory with file systems FAT32 or exFAT. IMPORTANT The process takes approximately 2 minutes to complete. During this time, it's important NOT to turn off the device or remove power. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 37: Restore The Device To Factory Defaults
• FactoryTalk Optix entitlements. • The link to FactoryTalk Remote Access organization. This means that is not possible to change the Organization/Domain doing the restore to factory defaults as a protection against unwanted Organization/Domain change. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 38: External Storage Devices
To access external storage devices through an Optix Application, use the system path shown in the following table: Storage type Folder /storage/usb1 /storage/usb2 USB Memory /storage/usb3 ... is accessed with progressive numbers Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 39 Chapter 4 Configuration Notes: Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
- Page 40 Chapter 4 Configuration Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 41: Clean The Operator Panel
ATTENTION: Make sure that the isopropyl alcohol does not come in contact with the equipment labels. Alcohol can cause the label printing to smear. • Use a mild soap or detergent solution to remove residue. • Rinse with clean water. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 42 Chapter 5 Clean the Operator Panel Notes: Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 43: Troubleshooting
To avoid damage to the operator panel, you must uninstall the operator panel and place it in its original packing material before you ship it. Rockwell Automation is not responsible for damage to a operator panel that is shipped or transported while installed in a machine, panel, or rack. - Page 44 Chapter 6 Troubleshooting Notes: Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
-
Page 45: Replace Components
Follow these steps before you remove the operator panel cover or replace a hardware component. 1. Shut down the operator panel and all peripherals that are connected to it. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 46: Post-Configuration
Locate the backup battery position (1). • Remove the battery and replace it with one of the same model (BR1225A). • Replace the battery so the positive polarity side faces the locking tab. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... -
Page 47: Reinstall The Cover
On the side of the system reinstall the four fixing screws (2) of the back cover and with a Torx T7 screwdriver with torque limiting verify the torque of 0.6...0.7 N•m (5.3...6.1 lb•in). Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023... - Page 48 Chapter 7 Replace Components Figure 13 - Reinstall the cover • Follow the steps for Post-configuration. Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
- Page 49 OptixPanel Compact Operator Panel User Manual Rockwell Automation Publication 2800C-UM001A-EN-P - August 2023...
- Page 50 At the end of life, this equipment should be collected separately from any unsorted municipal waste. Rockwell Automation maintains current product environmental compliance information on its website at rok.auto/pec. Allen-Bradley, expanding human possibility, FactoryTalk, Optix, OptixPanel, Remote Access, and Rockwell Automation are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc.
