Summary of Contents for Nolangroup n-com R Series
-
Page 2: Table Of Contents
Contents INSTALLATION ON THE HELMET .............................3 1.1.Installing the M951 system on the helmet ..........................4 1.2.Adjusting the microphone ................................8 1.3.Removing the M951 system from the helmet ......................... 8 BASIC FUNCTIONS ..................................9 2.1.Volume adjustment ................................... 9 2.2.Auto On / Off function ..................................9 2.3.Multi-language voice messages.............................. -
Page 3: Installation On The Helmet
INSTALLATION ON THE HELMET Important: Prior to installing the N-Com system, it is recommended to write down the identification code affixed to the product (see chapter 20.4). The installation video can be seen at www.n-com.it / Support section. Before you install the M951 system on the helmet, make sure it turns on properly. Press the “ON” ... -
Page 4: Installing The M951 System On The Helmet
1.1. Installing the M951 system on the helmet Hook up the microphone connector to the other end, following the directions of the arrows (Fig. 2). N.B.: You can adjust the position of the microphone. For instructions on how to do this, please see chapter. - Page 5 N.B.: For positioning of the keypad in helmets N87, N80-8 and N100-5, follow the instructions provided in the dedicated box. Fix the cable inside the helmet and make sure the left fixing clip snaps into its housing. Hook up the keypad to the helmet by clicking in the relevant hooks.
- Page 6 Fig. 11 ONLY FOR HELMET N100-5 – positioning of wiring and microphone Positioning the left side wiring: Lift up the plastic lining of the cheek padding (Fig. 12). Fix the cable inside the helmet and make sure the left fixing clip snaps into its housing (Fig. 13). ...
- Page 7 FOR N87, N80-8 and N100-5 HELMENTS ONLY – positioning the keypad Important: Installation of the keypad on the N87, N80-8, N100-5 helmets requires the use of the “KEYPAD ADAPTER” accessory, which is included in the package. LETTER ON THE ADAPTER COMPATIBLE HELMETS N100-5/PLUS, N87/PLUS N80-8...
-
Page 8: Adjusting The Microphone
Position the left and right speakers in the respective housing obtained in the polystyrene cheek padding. If necessary, rotate the speakers slightly in their housing. If necessary, secure them using the adhesive strips supplied as standard equipment. Reassemble the cheek padding. ... -
Page 9: Basic Functions
Unhook the right and left clips from the shell, levering upward using a flat head screw (or a similar tool), as shown in figure Fig. 27 Completely remove the M951 system from helmet using a flat head screwdriver (or similar tool) and re-install the cheek padding and the edge gasket. -
Page 10: Multi-Language Voice Messages
2.3. Multi-language voice messages The N-Com system offers voice prompts providing system information and confirmation of which functions are activated or deactivated. The default language is English. It is possible to change the language as follows: Via the N-Com system - Select Configuration Menu: with the N-Com already switched on, press and hold the “”... -
Page 11: Updating The Firmware
2.5. Updating the firmware Firmware updates for the N-Com system can be installed using the N-Com EASYSET program on your computer, or the N-Com EASYSET app on your smartphone. Via your computer with the N-Com EASYSET program Download N-Com EASYSET program from N-Com... -
Page 12: Pairing Up Menu
PAIRING UP MENU All the Bluetooth pairing up operations are carried out in this mode. In order to access the Pairing up Menu starting with the N-Com system switched off, press the “ON” key and keep it pressed for 4 seconds. Once in the “Pairing up”... -
Page 13: Mobile Phone / Mp3 Player Pair Up
E. Reset* In order to restore the factory settings of the device, press the key “” or “” until you hear the Factory Reset voice message “ ”. Press the “ON” confirmation key to restore all the factory settings of the device. Exiting the configuration* To exit the “Configuration”... -
Page 14: Mobile Phone
MOBILE PHONE To pair up a mobile phone to the M951 system, follow the procedure illustrated in Chapter 7. Answering a phone call Briefly press any key when you hear the incoming call signal. When you hear the ringtone, say any word out loud. You can enable / disable the “VOX phone”... - Page 15 N.B.: If no key is pressed within 15 seconds, the system exits the “Speed Dial” menu.
-
Page 16: Music Via Bluetooth
MUSIC VIA BLUETOOTH To pair up an Mp3 device to the M951 system, follow the procedure illustrated in Chapter 7. Play music (Play) Briefly press “ON”. Pause function (Pause) When the player is connected and playing music, briefly press “ON”. Next track (Skip) When the player is playing music, press “”... -
Page 17: Navigator Pair Up
NAVIGATOR PAIR UP M951 system is compatible with the most common satellite navigators for motorcycles. For a list of compatible models and additional details, visit the website www.n-com.it Make sure the M951 is turned off. Put the system in the “Pairing up” menu: press the “ON” key and keep it pressed for 4 seconds, ... -
Page 18: Audio Multitasking
10. AUDIO MULTITASKING The Audio Multitasking function makes it possible to music during Mesh Intercom communication Notes: The Audio Multitasking function is always enabled. 10.1. Adjusting the volumes Increasing or decreasing the volume of the foreground audio also increases or decreases the volume of the background audio. -
Page 19: Group Mesh Tm Pairing Up
11. GROUP MESH With Group Mesh , users can freely communicate with each other in the same private group in Group Mesh. For closed intercom conversations using Mesh Intercom, a Group Mesh needs to be created by the users. Up to 24 users can all be connected in each private group. 11.1. -
Page 20: Remote Control
13. REMOTE CONTROL The M951 device can be controlled by using a remote control (sold separately), so that you do not have to take your hands off the handlebars to use the keypad. The N-Com system is compatible with the RC4 Remote Control by SENA. The following table shows the correspondence of the keys: N-COM SYSTEM ▲... -
Page 21: Battery And Recharge
14. BATTERY AND RECHARGE 14.1. Low battery signal During its operation, the system alerts the user with a voice message when the battery is low. From the first message, the system has a 1-hour autonomy. Warning is given every 10 minute. 14.2. -
Page 22: Summary Table Of Controls
15. SUMMARY TABLE OF CONTROLS Turning on 2 sec Turning off 4 sec Increase Volume Decrease Volume Pairing up Menu*** 4 sec Configuration Menu 4 sec Answer phone call* Voice call 2 sec Speed Dialling Menu** Hang up/reject a phone call 2 sec Manual Device Connection... - Page 23 Certification and Safety Approvals FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 24 compliance could void user’s authority to operate the equipment. Industry Canada(IC) Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1)this device may not cause interference, and (2)this device must accept any interference, including interference that may cause undesired operation of the device.
