Data and Installation Instructions
(COMPACT-MAINS-DAU) for Vigilon Compact VA System
4188-954_Issue 3_Part 1_03/10 Mains DAU install
www.acornfiresecurity.com
Fault
System Fault
System Fault
Speaker Circuit 1
Power Fault
Speaker Circuit 2
Amplifier 1
Comms Fault
Earth Fault
Amplifier 2
Microphone Fault
Message Fault
Power
www.acornfiresecurity.com
by Honeywell
Mains Powered DAU
Cancel
Buzzer
VA Activated
Volume
by Honeywell
Voice Amplifier Unit
Advertisement
Table of Contents
Related Manuals for Honeywell GENT COMPACT-MAINS-DAU
Summary of Contents for Honeywell GENT COMPACT-MAINS-DAU
- Page 1 Honeywell Data and Installation Instructions Mains Powered DAU (COMPACT-MAINS-DAU) for Vigilon Compact VA System Cancel Fault Buzzer System Fault System Fault Speaker Circuit 1 VA Activated Power Fault Speaker Circuit 2 Volume Amplifier 1 Comms Fault Earth Fault...
-
Page 2: Table Of Contents
www.acornfiresecurity.com Installation instructions Contents Notes on system installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Installation requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Fixture and fittings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4... -
Page 3: Associated Documents
www.acornfiresecurity.com Main Powered DAU Preface Abbreviations This is the first issue of the Installation instructions for the Mains Common Powered Distributed Amplifier Unit. The booklet covers Distributed Amplifier Unit information on how to mount and wire the unit. Device (Loop device) Dual in Lline These instructions must be read in conjunction with the EMIC... -
Page 4: Notes On System Installation
www.acornfiresecurity.com Installation instructions Speakers fitted on ceiling tile Notes on system The installer should provide where required a suitable backing installation board that is fixed behind the ceiling tile to support the installed ceiling speaker assembly. The power-up of the Mains DAU and Earth continuity commissioning of the system is done All earth connection points should be clean to provide a good... -
Page 5: System Wiring
VA Activated Power Fault Speaker Circuit 2 Volume Speaker circuit 2 Comms Fault Amplifier 1 Earth Fault Amplifier 2 Microphone Fault LINE Message Fault Power OUT2 FAULT LINE RELAY AUXILIARY by Honeywell 230V ac Voice Amplifier Unit RELAY 50Hz www.acornfiresecurity.com... -
Page 6: Cables
www.acornfiresecurity.com Installation instructions Loop circuit cable Cables The Vigilon device loop cables carries data and power, therefore its selection is important. Note the following: " ¨ In countries where the European EMC directive is in If instructed, the installer may need to force, only EMC Compliant cables are to be used. -
Page 7: Mains Powered Dau
0ºC to 40ºC temperature Relative Humidity up to 90% (Non condensing) Temperature 5ºC to 45°C by Honeywell Voice Amplifier Unit Emission BS EN 61000-6-3:2007 Residential, Commercial & Light The Mains Powered Distributed Amplifier Unit also called Mains Industry Class B limits... -
Page 8: Power Supply
www.acornfiresecurity.com Installation instructions Power supply Local Audio Input 0dBu. Input impedance 10KW. Standard Designed to EN54-4 : 1998 Accepts balanced line level signals Mains supply 230V 50Hz +10% -6% voltage and fuses protected by: Audio Output 0dBu. Input impedance 10KW. FS3 Fuse - 3.15A (T) 250V Two unbalanced line level Ceramic 20mm x 5mm,... -
Page 9: Audio Pack 1
www.acornfiresecurity.com Main Powered DAU Audio Pack 1 A Message Store Card is fitted in the Mains DAU is identical to those fitted in the Vigilon Compact VA panel and in the micro Distributed Amplifier Units, it contains the messages and tones of the Audio Pack. A factory supplied Mains DAU is fitted with Message Store Cards having Audio Pack 1. -
Page 10: Installation
REMOVE COVER 1A0 (F) ONLY DURING 1A0 (F) Warning COMMISSIONING Removal of cover exposes live parts DANGER by Honeywell XX/XX/XX 1 2 3 4 5 6 7 8 AMP 1 AMP 2 PB16 ACS CONFIG ACS CONFIG DISABLE DISABLE BATT... - Page 11 www.acornfiresecurity.com Main Powered DAU Remove the 'transit plate' from the base of the 'backbox'. The plate is held in place via a cable tie, cut the cable tie and remove the plate. REMOVE THIS PLATE BEFORE FITTING BATTERIES Transit plate Cut the cable tie here and remove the cable tie and transit plate Knockout the required cable entry points from the back box.
-
Page 12: Wiring Test
REMOVE COVER 1A0 (F) ONLY DURING 1A0 (F) Warning COMMISSIONING Removal of cover exposes live parts Audio DANGER by Honeywell XX/XX/XX 1 2 3 4 5 6 7 8 Device Loop Loop AMP 1 AMP 2 PB16 ACS CONFIG ACS CONFIG... -
Page 13: Mains Supply
www.acornfiresecurity.com Main Powered DAU Mains supply See page 6 for information on recommended mains supply cable. & Ensure that the mains supply cable enters the enclosure through a dedicated cable entry, located adjacent to the mains terminal block and that is also segregated from loop wiring. "... -
Page 14: Battery Supply
11. Mains DAU AMP 1 AMP 2 PB16 ACS CONFIG ACS CONFIG by Honeywell DISABLE D D I I S S A A B B L L E E BATT EMIC XX/XX/XX ENABLE E E N N A A B B L L E E... -
Page 15: Terminals For External Circuits On Main Control Board
Removal of live parts live parts DANGER DANGER AMP 1 AMP 1 AMP 2 AMP 2 1A0 (F) by Honeywell by Honeywell PB16 PB16 ACS CONFIG ACS CONFIG ACS CONFIG ACS CONFIG XX/XX/XX XX/XX/XX 1 2 3 4 5 6 7 8... -
Page 16: Device And Audio Loop Circuits
www.acornfiresecurity.com Installation instructions Device and Audio loop circuits See page 6 for information on recommended loop circuit cable. The device loop circuit and audio loop circuit are connected to each Mains Powered DAU in the manner shown. To maintain earth continuity on the loop, the loop cable screen must be continued through each system device, whether the earth is connected to a device or not. -
Page 17: Speaker Circuits
www.acornfiresecurity.com Main Powered DAU Speaker Circuits See page 6 for information on recommended Speaker circuit cable. The wiring of the two 100V speaker circuit is interleaved to maximise coverage in the event of a circuit failure. The speaker circuit and spur off must be terminated with a 10k Ohms end-of-line (EOL) resistor. The speaker circuits are interleaved in the manner illustrated to alleviated the loss of output to areas if one speaker circuit should fail. -
Page 18: Use Of Multiple End-Of-Line Resistors
www.acornfiresecurity.com Installation instructions Use of multiple End-of-Line Resistors A maximum of up to four end-of-line resistors can be connected to a speaker circuit. This is to ensure a wiring failure on a speaker circuit is automatically detected. An entry of the number of end-of-line resistors connected to each speaker circuit is made during the commissioning of Vigilon Compact VA panel. -
Page 19: Balanced 'Audio Out' Application
www.acornfiresecurity.com Main Powered DAU Balanced 'Audio Out' application A typical application of the unbalanced 'Audio Out' coupled with 'Auxiliary Relay' contacts of Mains Powered DAU is to permit fire alarm output to hearing impaired people within an area having an induction loop installed. The 'Audio Output' is also suitable for connection to 3rd party VA amplifier. -
Page 20: Fault Relay Output
www.acornfiresecurity.com Installation instructions Fault relay output The Fault Relay Contacts are rated 1A @ 24Vdc. The relay is shown in a de-energised state, that is in a Fault condition. Note the relay contact markings are shown for a Fault condition. With no fault on the system the relay will be in an energised state. FAULT RELAY CONTACTS Rated 1A @ 24Vdc. -
Page 21: Local Background Music
www.acornfiresecurity.com Main Powered DAU Local Background music See page 6 for information on recommended cable for background music system. There are many types of entertainment system that are commercially available for connecting to the Mains DAU for the broadcasting background music. &... -
Page 22: Completion Of Installation
VA Activated Power Fault Speaker Circuit 2 Volume Comms Fault Amplifier 1 Earth Fault Amplifier 2 Microphone Fault Message Fault Power by Honeywell Voice Amplifier Unit " Leave all outstanding parts in a safe place for installation during commissioning. www.acornfiresecurity.com... -
Page 23: System Parts
www.acornfiresecurity.com Main Powered DAU System Parts This section lists parts that can be used with the Mains Powered Distributed Amplifier Unit. For further details on the availability of the parts, contact your supplier. COMPACT-MAINS-DAU Vigilon Compact Mains powered Distributed Amplifier Unit 2 x 12V 7Ah Battery Spares CVS-MDMCB... - Page 24 www.acornfiresecurity.com Installation instructions Main Powered DAU 13421-54-DC 20W Music quality Metal Column Speakers with 4.7uF blocking capacitor 13421-70-DC 10W Metal Projector Loudspeaker with 2.2uF blocking capacitor 13421-71-DC 20W Bi-directional Metal Projector Speaker with 4.7uF blocking capacitor 13421-72-DC 10W Bi-directional Metal Projector Speaker with 4.7uF blocking capacitor 13421-73-DC 10W Plastic Projector Loudspeaker with 2.2uF blocking capacitor 13421-74-DC...
