Summary of Contents for Whirlpool ACG540IX
Page 1
SERVICE MANUAL Model : ACG540IX...
Page 3
Contents Technical Data ..........2 Exploded view ..........3 Spare parts list ..........4 Wiring diagram ..........7...
Page 4: Technical Data
Technical Data Electricity supply: 220-240V~50/60Hz Max Gas Power: 7500W Top Gas Power: 1700W Bottom Gas Power: 2500W Oven light: 25W Inner volume of the oven: 56 Liters...
Page 5: Exploded View
Exploded view...
Page 6: Spare Parts List
Spare parts list Parts No. Code Description 2030300108 Inner assembly 2030400003 Doorframe Sealer Subassembly 0.067 30302700136 Connection panel 30302900171 Fixing sleeve 30307100134 Drawer panel 30307200021 Drawer baffle 30307800013 Drawer partition 30313200065 Oven bracket 30200900016 Inner glass fixing block 30200900018 Inner glass fixing block 30200900019 Inner glass fixing block 30201300001...
Page 7
Spare parts list 30302600032 Hinge fixed plate-left 30302600033 Hinge fixed plate-right 30302700138 Connection panel 30302700153 Connection panel 30302700157 Connection panel 30302900184 Oven fixed plate 30302900185 Oven fixed plate 30302900215 Oven fixed plate 30302900216 Oven fixed plate 30302900219 Oven fixed plate 30303900001 Burner baffle 30304000001...
Page 8
Spare parts list 30402100091 Nozzle-auxiliary burner 60.1 30402100100 Nozzle-upper burner 60.2 30402100101 Nozzle-semi-rapid burner 60.3 30402100111 Nozzle 60.4 30402100119 Nozzle-rapid burner 30402300002 Inlet connector 30402400003 Ignition needle-semi-rapid burner 350mm 62.1 30402400004 Ignition needle-semi-rapid burner 500mm 62.2 30402400049 Ignition needle 30402800016 Base cup for auxiliary burner 30402800022 Base cup for semi-rapid burner...
Page 9: Wiring Diagram
Wiring diagram Spark pin switch Spark pin switch Spark pin switch Spark pin switch Oven Spark pin switch Top burner Bottom burner Light Lamp...
