- Page 1 User’s Manual TM-815EP PCI/ AGP/CNR Mainboard Version: 1.0 Warning: Never run the processor without the heatsink proper and firm installation. Permanent Damage Will result!
-
Page 2: Disclaimer
User’s Manual Copyright Copyright ©2001 by this manufacturer. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, manual or otherwise, without the prior written consent of this manufacturer. -
Page 3: Overview
User’s Manual Overview The TM-815EP Intel’s i815EP chipset removes i752 graphics in the current GMCH chip of 815E; the rest of the function are the same as of 815E. Both support PC 100/133 SDRAM, ultra ATA100 HDD and 4x USB ports. The... -
Page 4: Table Of Contents
User’s Manual CONTENTS COPYRIGHT................2 DISCLAIMER................2 OVERVIEW.................3 CONTENTS................3 INTRODUCTION.................6 ................6 PECIFICATIONS SETUP GUIDE................8 .…………………………………………………...8 AYOUT IAGRA (I/O, USB & IR)..…………………………………...9 ONNECTOR ……..…………………………………………10 UMPER ETTINGS ………………………………………….12 MPORTANT UNCTIONS CAM - A ........16 NTEGRATED ODULE ONNECTION UIDE OF ……………………………..18 &S …………………………………………….20 RIVER OFTWARE BIOS U …………….. - Page 5 User’s Manual AWARD BIOS SETUP.............24 ................25 ETTING Standard CMOS Setup............26 BIOS Features Setup...............28 Advanced Chipset Features Setup..........31 Integrated Peripherals ............33 Power Management..............37 PNP/PCI Configuration Setup..........40 PC Health Status ..…………………..……………………… 42 Frequency / Voltage Control………………………………. 44 Load BIOS Default..............45 Load Setup Default..............45 Supervisor Password ............46 Exiting the Setup Program.............47 TECHNICAL INFORMATION...........48...
-
Page 6: Introduction
User’s Manual Introduction A. Specifications System Chipset Intel i815EP chipset. Intel PPGA-Celeron processors, support 300-766 MHz (Ex. Clk 66 MHz); CuMine FC-PGA 450-800MHz (Ex. Clk 100 MHz); CuMine FC-PGA 533-1 GHz (Ex.Clk 133 MHz) CPU. Memory Available with 32MB to 512MB unbuffered DIMMs expandable to 1.5GB (3 banks) with three 168-pin DIMM socket {support 3.3 V EDO (66MHz only) / SDRAM (66/100/133)}. - Page 7 User’s Manual controls the fan speed of the CPU and chassis fans; and failure alarm. • Automatic CPU and chassis fans on/off control • Opened chassis alarm • Monitors 5VSB/VBAT/1.5V/3/3V/5V/+-12V/CPU voltage and failure alarm • Read back capability that displays temperature, voltage and fan speed.
-
Page 8: Setup Guide
User’s Manual Setup Guide Layout Diagram... - Page 9 User’s Manual Connectors I/O Connectors: J14 . Universal Serial Bus Ports J12 . IrDA Connector 1. VCC 2. CIRRX 3. IRRX 4. GND 5. IRTX...
-
Page 10: Jumper Settings
User’s Manual Jumper Setting JP1 : Wake-On USB (1 & 2) Keyboard 1-2 On Disable (default) 2-3 On Enable JP2: Wake-On Keyboard / Mouse 1-2 On Disable (default) 2-3 On Enable JP4: Wake-On USB (3 & 4) Keyboard 1-2 On Disable (default) 2-3 On... - Page 11 User’s Manual JP7 : PC Speaker or Buzzer Select 1-2 On Buzzer (default) 2-3 On PC Speaker JP9 / JP10: CPU Front Side Bus CPU/DIMM JP10 Auto* 1-2 On 1-2 On 66/100 MHz 2-3 On 2-3 On 100/100 MHz All Off 2-3 On 133/100 MHz...
-
Page 12: Important Functions
User’s Manual Important Functions CPU and Chassis Fan Automatic Off The CPU and chassis fans will automatically turn off once the system Enters into Suspend Mode. Dual Function Power Button Depending on the setting in the “Soft-Off By PWR-BTTN” field of The Power Management Setup, this switch will allow the system to Enter the Soft-Off or Suspend mode. - Page 13 User’s Manual Wake-On-USB Keyboard This function allows you to use a USB keyboard to wake up a system that is in the S3 (STR – Suspend To RAM) state. ※ Notice: •If you are using this function for 2 USB ports, the 5VSB power source of your power supply must support ≧1.5A.
- Page 14 User’s Manual How to use Suspend to RAM Function 1. Select “Power Management Setup” in the Main Menu. 2. Select “Enabled” in the “ACPI Function”. 3. Select “S3(STR)” in the ACPI Suspend Type. 4. Press <ESC> to return to the Main Menu. 5.
-
Page 15: Escocam - An Integrated Module
User’s Manual 12. After completing the steps above and you want to power-off the computer, you do not need to go through the process of closing files, applications and operating system. You can power-off the computer at once by pressing the power button or selecting “Standby”... - Page 16 User’s Manual It’s so valuable that you don't have to pay thrice to buy three fashionable devices of PC Camera, Debugging and IrDA ware now because we have integrated them into our EscoCAM in the shape of a lovely whale to escort your system. The whale is the king of the sea and the symbol of all-mighty power.
- Page 17 User’s Manual Audio, video and multi-tasking functions call for faster and faster CPUs to improve system efficiency. However, faster CPUs will generate more heat which must be dissipated in a timely manner. Therefore, a more efficient fans to dissipate heat is as important as watch-out of fan working situation.
- Page 18 User’s Manual The Connection of EscoCAM For Connecting All Mainboards: A PCI daughter card is attached with EscoCAM to connect:...
- Page 19 User’s Manual Or, if you just want use the function of PC Camera, the connection drawing as follows:...
-
Page 20: Driver &Software
Operating System used, the automatic installation is only available for Windows 98. For Windows 2000/ME/NT, you must manually install. 2. Improper driver installation may cause system unstable. Pls go to Totem’s Web site at http://www.totem.com.tw... - Page 21 User’s Manual Browse All The Drivers in CD After selecting mainboard model name, all the available drivers will appears on the screen as follows:...
-
Page 22: Audio Driver
User’s Manual How to install Windows 95/NT/ME/2000 ? 1. Insert the support CD-ROM disc in the CD-ROM drive. Just bypass the error message from PnP function. 2. Since quick installation is not supported by Windows 95/NT/ME/2000, you have to select correct drivers and EXE given file names as follows: Bus Master IDE Driver \IDE\815EP\SETUP.EXE USB Driver... - Page 23 User’s Manual BIOS Update Note Do not update the BIOS if no abnormalities occur. However, if BIOS update is needed, consult your dealer first. Prior to updating your BIOS, you are recommended to save the original BIOS values. 1. Download the AWARD BIOS Flash Utility file (Awdflash.exe) 2.
-
Page 24: Bios Setup
BIOS Setup BIOS Setup Award BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This information is stored in battery-backed RAM so that it retains the Setup information when the power is turned off. Entering Setup To enter the BIOS Setup, press <Del>... -
Page 25: Getting Help
BIOS Setup Getting Help Main Menu The online description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu/Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for highlighted item. - Page 26 BIOS Setup The items in Standard CMOS Setup Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then press the <PgUp> or <PgDn> keys to select the value you want in each item. CMOS Setup Utility –...
-
Page 27: Bios Features Setup
BIOS Setup Japan. This is a 3.5” disk that stores only 1.2MB, the default setting is Disabled. Halt On This field is used to determine when to halt the system by the BIOS if an error occurs. BIOS Features Setup CMOS Setup Utility –... - Page 28 BIOS Setup CPU L2 Cache : Enabled CPU L2 Cache ECC Checking : Enabled CPU L2 ECC Checking : Enabled Processor Serial Number : Disabled Quick Power On Self Test : Enabled First Boot Device : Floppy Second Boot Device : HDD-0 Third Boot Device : LS/ZIP...
- Page 29 BIOS Setup Self Test the items checked during POST and to speeds up the Power On Self Test. When you are sure that your system hardware is smooth and stable enough, we recommend to enable this item for speeding up POST. rd/ and Other The BIOS trys to load the operating system from the Boot Device...
-
Page 30: Advanced Chipset Features Setup
BIOS Setup Security Option This allows you to limit access to the System and Setup, or just to Setup. The default is Setup. System: The system will not boot and the access To the Setup will be denied if entered password is Incorrect. - Page 31 BIOS Setup ↑↓→Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults The settings on the screen are for reference only. Your version may not be identical to this one. SDRAM CAS This setting defines the CAS timing parameter of the Latency Time SDRAM in terms of clocks.
-
Page 32: Integrated Peripherals
BIOS Setup Enabled : Enabled the Video BIOS Cacheable to speed up the VGA performance. AGP 4X Mode This allows to copy BIOS code from slow ROM to fast RAM. Default is Enabled. Enabled : This option will improve system performance. - Page 33 BIOS Setup AC 97 Modem : Auto IDE HDD Block Mode : Enabled KB/Mouse Power On : Disabled KB Power On Password : Enter KB Power On Hot Key : Ctrl-F1 Onboard FDC Controller : Enabled Onboard Serial Port 1 : 3F8/IRQ4 Onboard Serial Port 2 : 2F8/IRQ3...
- Page 34 BIOS Setup setting. Disabled: The HDD will run in normal mode. USB Controller Enabled this item when your system contains a Universal Serial Bus (USB) and you have a USB keyboard. Default is Enabled. USB Keyboard Enabled this item when your system contains a Support Universal Serial Bus (USB) and you have a USB keyboard.
- Page 35 BIOS Setup address si 2E8H/IRQ3. UATR2 Mode This field is available only if Onboard Serial Select Port 2 is Disabled. UART mode enables you to select the Infrared protocol – Normal (default), HPSIR or ASKIR. HPSIR is HP’s IR protocol with a maximum baud rate up to 115.2Kbps.
-
Page 36: Power Management
BIOS Setup DMA3 for the ECP mode. Default is 3. PWR Lost Resume Default is Keep Off State Game Port This determine which Address of Game Port will use. Default Value is 201. Address Midi Port Address This determine w hich Address of Midi Port will use. - Page 37 BIOS Setup : Move Enter : Select +/-/PU/PD:Value : F10: Save ESC: Exit F1: General Help F5: Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults The settings on the screen are for reference only. Your version may not be identical to this one.
- Page 38 BIOS Setup Default is disabled. HDD Power Down When this item is Enabled and after the set time of system inactivity, the HDD will be Powered Down when other Drives are remain active. The setttings are /2/3/4/5/6/7/8/9/10/11/12/13/14/15 Min. Default is Disabled. Soft-Off By PWR Use this item to select soft-off function.
-
Page 39: Pnp/Pci Configuration Setup
BIOS Setup PNP/PCI Configuration Setup CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software PnP/ PCI Configurations Reset Configuration Data : Disabled Resources Controlled By : Auto (ESCD) IRQ Resources : Press Enter PCI/VGA Palette Snoop : Disabled * PCI IRQ Assignment * Slot 1, 5 : Auto... - Page 40 BIOS Setup Reset This item allows you to clear ESCD (Extended System Configuration Data). Default is Configuration Data Disabled. If you have plugged in some Legacy cards to the system and they were recorded into ESCD, you can set here Enabled in order to clear ESCD.
-
Page 41: Pc Health Status
BIOS Setup PC Health Status This page sets some of the parameters for monitoring function of this mainboard. CMOS Setup Utility – Copyright © 1984-2000 Award Software PC Health Status Current System Temperature 27°C/80°F Current CPU Temperature 36°C/90°F Current Chassis FAN Speed 0 RPM Current CPU FAN Speed 0 RPM... - Page 42 BIOS Setup Current System These items display the system perature temperature measurement. The system will alert you if a safe temperature is exceeded. Currrent CPU These items display CPU temperature Temperature measurement. The system will alert you if a safe temperature is exceeded. Current Chassis These items indicate chassis cooling fan speeds in RPM.
-
Page 43: Frequency/Voltage Control
BIOS Setup Frequency/Voltage Control CMOS Setup Utility – Copyright © 1984-2000 Award Software CPU Frequency Control Open Slight Adjust Disabled Clock By Slight Adjust Spread Spectrum Disabled CPU Clock Ratio : Move Enter : Select +/-/PU/PD:Value : F10: Save ESC: Exit F1: General Help F5: Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults... -
Page 44: Load Best Performance Settings
BIOS Setup Load Best Performance Settings When you press <Enter> on this item, a dialog box appears as below: Load Best Performance (Y/N) ? N Pressing ‘Y’ loads the BIOS default values for the most stable, minimal- performance system operations. Load Optimized Defaults When you press <Enter>... -
Page 45: Supervisor Password
BIOS Setup Change Password Type the password, up to 8 characters in length, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory. You will be asked to confirm the password once again. Now, type the password again and press <Enter>. -
Page 46: Exit Selecting
BIOS Setup Exit Selecting Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y... -
Page 47: Technical Information
Technical Information System Block Diagram Award BIOS 6.0 POST Code :... -
Page 48: Post Code
Technical Information POST (HEX) Description Test CMOS R/W functionality. Early chipset initialization: -Disable shadow RAM -Disable L2 cache (socket 7 or below) -Program basic chipset registers Detect memory -Auto-detection of DRAM size, type and ECC. -Auto-detection of L2 cache (socket 7 or below) Expand compressed BIOS code to DRAM Call chipset hook to copy BIOS back to E000 &... - Page 49 Technical Information POST (HEX) Description Reserved Reserved Test F000h segment shadow to see whether it is R/W-able or not. test fails, keep beeping the speaker. Reserved Auto detect flash type to load appropriate flash R/W codes into run time area in F000 for ESCD & DMI support. Reserved Use walking 1’s algorithm to check out interface in CMOS circuitry.
- Page 50 Technical Information 2. Check validity of RTC value: e.g. a value of 5Ah is an invalid value for RTC minute. 2. Load CMOS settings into BIOS stack. If CMOS checksum fails, use default value instead. Prepare BIOS resource map for PCI & PnP use. If ESCD is valid, take into consideration of the ESCD’s legacy information.
- Page 51 Technical Information series Super I/O chips. See also POST 63h. Reserved Test DMA Channel 0 Reserved Test DMA Channel 1. Reserved Test DMA page registers. Reserved Reserved Test 8254 Reserved Test 8259 interrupt mask bits for channel 1. Reserved Test 8259 interrupt mask bits for channel 2. Reserved Reserved Test 8259 functionality.
- Page 52 Technical Information Initialize USB Keyboard & Mouse. Reserved Test all memory (clear all extended memory to 0) Clear password according to H/W jumper (Optional) Reserved Display number of processors (multi-processor platform) Reserved 1. Display PnP logo 2. Early ISA PnP initialization -Assign CSN to every ISA PnP device.
- Page 53 Technical Information & Auto-configuration table. Reserved 1. Assign resources to all ISA PnP devices. 2. Auto assign ports to onboard COM ports if the corresponding item in Setup is set to “AUTO”. Reserved 1. Initialize floppy controller 2. Set up floppy related fields in 40:hardware. Reserved Reserved Reserved...
- Page 54 Technical Information 3. If password is set, ask for password. Save all data in stack back to CMOS Initialize ISA PnP boot devices 1. USB final Initialization 2. Switch screen back to text mode Reserved NET PC: Build SYSID Structure. Reserved 1.
-
Page 55: Problem Sheet
Technical Information A. Problem Sheet Customer Name address... -
Page 56: Memo
Technical Information Mainboard Mode Mainboard Rev Serial No. BIOS version Configuration Brand Brand Type Type & Size Voltage Speed Brand Brand Floppy disk Mode VGA card Chipset Size RAM Type Brand Brand Hard disk Mode CD-ROM Mode Size Speed Brand Brand Sound card Mode Lan card...
