Tools Required
Package Contents
Preparation: Identify and inspect all parts
before beginning the installation.
Missing or damaged parts? Contact your
original place of purchase.
PARTS BAG
Mounting Screw
A
x 3
Wire Connector
B
x 3
Table of
Contents
2022 Quoizel Inc.
For Styles WVR9007A, WVR9007AC, WVR9007EK,
WVR9007SS and WVR9007WT
Light Source
BULB BASE TYPE
Medium (E26)
1 BULB REQUIRED
BULB NOT INCLUDED
Glass Panel & Bulb
Drill Holes
STEP 1
STEP 2
visit us on-line at www.quoizel.com
Installation Guide
150W
Turn off the electricity at the circuit breaker
MAX
before installation. Consult a licensed
electrician if in doubt about installation.
Turn off power to the fixture and allow the bulbs
to cool before replacing.
BULB SHAPE
TYPE A
Fixture Body
C
x 1
Wiring
STEP 3
1 of 3
Warnings and Cautions
Glass Panel
D
x 4
*Glass panels may be
different than pictured
based on which item
was purchased.*
Fixture Body
STEP 4
Released Date: 2022-06-13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Quoizel Westover WVR9007A
Summary of Contents for Quoizel Westover WVR9007A
- Page 1 Table of Glass Panel & Bulb Wiring Fixture Body Drill Holes Contents STEP 1 STEP 2 STEP 3 STEP 4 visit us on-line at www.quoizel.com Released Date: 2022-06-13 2022 Quoizel Inc. 1 of 3...
- Page 2 STEP 2 Step 1 Step 2-3 Place Post Fitter to Post Mark Mounting Holes Location on Post 1/16” Drill Bit Step 4 Drill Holes visit us on-line at www.quoizel.com Released Date: 2022-06-13 2022 Quoizel Inc. 2 of 3...
- Page 3 Black wire Black or Red wire (hot) from fixture from outlet box Bare or Green ground wire Ground wire from Fixture from outlet box STEP 4 visit us on-line at www.quoizel.com Released Date: 2022-06-13 2022 Quoizel Inc. 3 of 3...
