SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, install or operate the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the circuit breaker box or the main fuse box.
• RISK OF FIRE - Use bulbs specified by the markings and/or labels on the fixture.
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
• Turn off electricity to fixture before replacing the bulb(s).
TOOLS REQUIRED
CARE AND MAINTENANCE
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at
www.quoizel.com.
PACKAGE CONTENTS
Fixture Body
A
x 1
Lock Screw
C
x 8
Candle cover
E
x 4
Installation GUIDE FOR WVR8209EK
Glass panel
B
x 4
Curved Plate
D
x 4
-
MOUNTING HARDWARE
Inner Backplate
AA
x 1
Wire Connector
CC
x 3
Wall Anchor
EE
x 4
1
of
3
-
Released Date: 202 - 3 02-03
Mounting Screw
BB
x 4
Outlet Box Screw
DD
x 2
Screw
FF
x 4
