- Page 1 Sivoia QED ™ Roller 64 ™ Fascia and Top/Back Cover Installation Instructions...
- Page 2 Sivoia QED Roller 64 Fascia and Top/Back Cover Installation Instructions Tools Required: Tape Measure 1/4” Hex-Head Driver Wire Cutter/Stripper Level Pliers Power Drill #2 Phillips Screwdriver Notes: 1) Complete wiring and programming information can be found in the Sivoia QED Wire and Programming Guide, P/N 045-038 or at www.lutron.com.
- Page 3 Sivoia QED Roller 64 Fascia and Top/Back Cover Installation Instructions (continued) Warning: Incorrect installation can lead to severe injury, follow all installation instructions. Notes: • The Sivoia QED Roller 64 must be used only with window systems approved by Lutron. •...
- Page 4 Confirm System Dimensions Package Label Compare system dimensions on the package label with the window dimensions to verify appropriate window/shade combination. System Height System Width System Width (Bracket to Bracket Width) SIVOIA QED Roller 64 Fascia and Top/Back Cover Installation Instructions...
- Page 5 Mount Top/Back Cover DANGER - Locate and lock breaker to the shade power supply in the OFF position unplug the power plug-in transformer before doing any wiring. Pre-drill top/back to allow clearance for the wires without interfering with the bracket. Follow figure below for suggested hole locations.
- Page 6 Mount Top/Back Cover (continued) Verify mounting surface is level/plumb before attaching top/back cover. Note: Top/back cover may rub fabric if installed with an improper tilt or may cause flap to fall. Mount the top/back cover using the appropriate fasteners. The ceiling side of the top/back cover is the side with the larger of the two snapping tabs.
- Page 7 Position the Mounting Brackets Mark the location of the mounting brackets so they are centered over the window. Note: Bracket to Bracket Distance = Fabric Width + 1.5” (38 mm) = System Width. Note: For a ceiling and jamb mount, allow clearance to prevent fabric from rubbing against trim, window, top treatment, etc.
- Page 8 Install Fascia Brackets Note: If not using a top/back cover, go to step 4.2 Hook the top of the fascia bracket behind the top triangular tab of the top/back cover. Then rotate the bracket until it snaps onto the bottom tab of the top/back cover. Mount the brackets.
- Page 9 Wire 7-Pin Terminal Block Strip 2” (50mm) of the jacket off the cable run from the wall. Wire 7-Pin terminal block (provided) to cable using the included screwdriver. Note: SVQ-CBL-250 shown. EGND (Yellow/Green) 24 VAC (Red) 24 VAC (Red/White) To EDU MUX (Purple) Connector MUX (Gray)
- Page 10 Orient the Buttons and Wiring For the following bracket and button orientations, route the wires as shown. Note: The buttons should be accessible when the shade is installed. Note: Make sure the wires are not pinched or damaged. Note: The wires may go in either or both of the indicated slots. Buttons SIVOIA QED Roller 64 Fascia and Top/Back Cover...
- Page 11 Mount the Shade Install the idler side of the shade onto its bracket. Depress the spring loaded idler and install the EDU side of the shade onto its bracket. SIVOIA QED Roller 64 Fascia and Top/Back Cover Installation Instructions...
- Page 12 Adjust the Shade Ensure that the shade is level and centered. Adjust shade by removing the necessary screws and moving the brackets as needed, or installing bracket leveling spacers. Note: You may have to remove the shade to access the bracket screws. Note: If using a top/back cover, only the width is adjustable.
- Page 13 Connect Terminal Blocks Plug 7-pin terminal block on cable into EDU terminal block (a cable tie can be used to secure the terminal blocks together). Dress wires to ensure fabric does not rub while the shade is moving. SIVOIA QED Roller 64 Fascia and Top/Back Cover Installation Instructions...
- Page 14 IR Receiver Connection (if applicable) 10.1 Plug in the IR receiver. 10.2 Position the IR receiver. Note: The IR receiver should not be covered from view of the remote control or interfere with the shade. SIVOIA QED Roller 64 Fascia and Top/Back Cover Installation Instructions...
- Page 15 Secure and Check the Shade 11.1 Tighten retaining screws in each bracket to secure the shade. SIVOIA QED Roller 64 Fascia and Top/Back Cover Installation Instructions...
- Page 16 Secure and Check the Shade (continued) 11.2 Reconnect power to the shade power supply. Use the programming stylus to run the shade up and down using the adjustment buttons ( ), re-level if needed. Observe: Pay careful attention to the shade roll up to ensure that it does not telescope extremely to one side or the other.
- Page 17 Setting Limits from the EDU Setting the Open Limit from the EDU Note: Setting the Open Limit lower than the Close Limit will cause the shade to move down when raise is pressed and up when lower is pressed. 12.1 Tap the “Open Limit Button”...
- Page 18 Setting Limits from the EDU (continued) Setting the Close Limit from the EDU 12.4 Tap the “Close Limit Button” ( ). The green LED on the roller Shade EDU will turn on steady, indicating that the EDU is Steady LED in “Set Close Limit Mode”.
- Page 19 Attach Fascia Note: Fascia and endcaps are installed after the shade is mounted and programmed. 13.1 Hook the top tab of the fascia on the bracket as shown. 13.2 Swing the fascia down toward the shade, and snap the triangular lip onto the bracket. 13.3 Ensure the fabric does not rub on anything.
- Page 20 Install Fascia Endcaps 14.1 Snap the fascia endcap onto the fascia bracket by aligning the pins with the holes on the bracket, and pressing it into place. SIVOIA QED Roller 64 Fascia and Top/Back Cover Installation Instructions...
- Page 21 Finish System Programming The Sivoia QED shade is now installed, wired, and the OPEN/CLOSE limits for each shade have been set. The next step is to finish programming the system. Use the instructions in the Wiring and Programming Guide (p/n 045-038) or the Technical Reference Guide (p/n 367-592) and perform these four easy steps: 1.
-
Page 22: Troubleshooting
Troubleshooting Symptom Solution Shade will not move..EDU is not powered - check EDU Power..Shade is caught on something - free shade..Shade is not assigned to keypad, IR, or CCI. Shade does not fully open or fully close..Limits have been set incorrectly - refer to “set open limit”... - Page 23 Notes: _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ SIVOIA QED Roller 64 Fascia and Top/Back Cover Installation Instructions...
-
Page 24: Technical Assistance
Technical Assistance Limited Warranty Lutron offers an 8-year limited warranty for our WORLD ADDITIONAL LUTRON HEADQUARTERS SALES OFFICES: shading systems. Please contact customer Lutron Electronics Co., Inc. Germany service or visit our website for a complete 7200 Suter Road Tel: +49-309-710-4590 warranty statement.
