c/,JI
OSMO MOBILE
6
Quick Start Guide
't~~Af1f~ffi
vl.O
I
\__
---- ····-· . -· j )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OSMO MOBILE 6 and is the answer not in the manual?

Questions and answers

Related Manuals for dji OSMO MOBILE 6

Summary of Contents for dji OSMO MOBILE 6

  • Page 4 User Manual v1.6 2024.06...

  • Page 5: Revision Log

    This document is copyrighted by DJI with all rights reserved. Unless otherwise authorized by DJI, you are not eligible to use or allow others to use the document or any part of the document by reproducing, transferring or selling the document. Users should only refer to this document and the content thereof as instructions to operate DJI UAV.

  • Page 6: Using This Manual

    Scan the QR code above to download the latest version of DJI Mimo app. The iOS version of DJI Mimo is compatible with iOS v12.0 and later. The Android version of DJI Mimo is compatible with Android v8.0 and later.

  • Page 7: Table Of Contents

    Overview Getting Started Charging Attaching the Phone Using Osmo Mobile 6 On-board Features Operating Mode DJI Mimo App Connecting to the DJI Mimo App Camera View Remote Control with Watch Firmware Update How to Update Storage Specifications © 2024 DJI All Rights Reserved.

  • Page 8: Introduction

    14. Charging Port (USB-C) 7. 1/4"-20 UNC Port 15. Trigger 8. Switch Button Osmo Mobile 6 is compatible with DJI OM Fill Light Phone Clamp and DJI Mic, which can be purchased in the DJI Store. © 2024 DJI All Rights Reserved.

  • Page 9: Getting Started

    Getting Started Charging To charge Osmo Mobile 6, connect a USB adapter (not included) to the charging port using the power cable. The battery is fully charged when the battery level indicator turns off on the status panel. Charging time: approx. 1 hour 24 minutes (tested in the environment temperature of 25° C when using a 10 W charger) Max runtime: approx.
  • Page 10 3. Align the marks on the phone clamp and the phone clamp mounting plate. Attach the mobile phone to Osmo Mobile 6. Osmo Mobile 6 will stabilize once the gimbal mode indicator lights up on the status panel.
  • Page 11 Osmo Mobile 6 User Manual 4. The built-in extension rod can be extended to up to 215 mm and the angle can be adjusted from 0 to 90°. © 2024 DJI All Rights Reserved.

  • Page 12: On-Board Features

    Using Osmo Mobile 6 On-board Features Status Panel Displays the System Status Indicator, Battery Level Indicator, and Gimbal Mode. System Status Indicator Descriptions Blinking Pattern Descriptions Pulses red Magnetic is not aligned Solid yellow Bluetooth disconnected Solid green Bluetooth connected...
  • Page 13 Press and hold to enter lock mode. In lock mode, the gimbal will not follow the handle movements. Release to exit lock mode. Charging Port (USB-C) Charge Osmo Mobile 6 by connecting a USB adapter to this port. 1/4"-20 UNC Port The 1/4"-20 UNC port can be used to attach a tripod.
  • Page 14 Press the switch button, shutter/record button, and trigger simultaneously for more than one second to reset the Bluetooth name and connection and reconnect. Osmo Mobile 6 will be powered off automatically if there is no operation for three minutes in standby mode.

  • Page 15: Operating Mode

    Side Grip Mode Low Position Mode Rotate Osmo Mobile 6 to the right or left Extend the built-in extension rod and by 90° to go from Upright to Side Grip adjust the angle to Low Position mode.

  • Page 16: Dji Mimo App

    Album: manage and view footage from the phone or DJI devices. Device: tap to connect to Osmo Mobile 6. Once connected, DJI Mimo enters camera view. Editor: tap to edit photos or videos from Osmo Mobile 6 or import and edit from a mobile device.

  • Page 17: Connecting To The Dji Mimo App

    2. Enable Bluetooth on the mobile phone and connect to the device with an OM6 prefix name in DJI Mimo. 3. Users are required to allow access to certain information when using DJI Mimo for the first time. The exact information will be listed in the prompt. An internet connection is required.
  • Page 18 Osmo Mobile 6 User Manual a. Drag a box on the screen in the camera view in DJI Mimo. A green box around the subject indicates ActiveTrack 6.0 is successfully enabled. Tap the icon on the top corner to stop tracking.
  • Page 19 Osmo Mobile 6 User Manual Fixed Angle, L to R, and R to L, set the interval and duration and start to shoot. For Custom Motion, select up to four positions and the gimbal will move to each position in sequence.
  • Page 20 Osmo Mobile 6 User Manual Gimbal Auto Calibration: reduces drift caused by nearby magnetic interference or human error. Before calibrating, place Osmo Mobile 6 on a flat surface using a tripod. Do not touch the gimbal during calibration. Horizontal Gimbal Adjustment: make sure the magnetic phone clamp is level before adjusting the gimbal.

  • Page 21: Remote Control With Watch

    Osmo Mobile 6 User Manual Remote Control with Watch The DJI Mimo app can be used with an Apple Watch, allowing you to view the camera feed, control the gimbal direction and adjust the composition, and enable ActiveTrack remotely on the watch for an effortless shooting experience.

  • Page 22: Gimbal Control

    Osmo Mobile 6 User Manual Gimbal Control on the left side of the camera view to enter the gimbal control view and adjust the composition on the watch. 1. Joystick: drag the joystick on the screen to control the gimbal direction. Drag or tap the joystick to hide other icons.

  • Page 23: Firmware Update

    Before starting an update, make sure that the battery level indicator shows green or yellow. Connect Osmo Mobile 6 to your mobile device and launch DJI Mimo. You will be prompted if a new firmware update is available. To start updating, connect the mobile device to the internet and follow the on-screen instructions.

  • Page 24: Specifications

    Mechanical Range Roll: -120.30° to 211.97° Tilt: -101.64° to 78.55° Max Control Speed 120°/s Wireless Mode Model Bluetooth 5.1 Other DJI Mimo Grip Tripod Length: 138 mm Dimensions Diameter: 32 mm Weight Approx. 72 g © 2024 DJI All Rights Reserved.
  • Page 25 DJI SUPPORT This content is subject to change. https://www.dji.com/osmo-mobile-6/downloads If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. DJI and OSMO are trademarks of DJI. Copyright © 2024 DJI All Rights Reserved.
