SECTION
U
DATA PACKAGE
INTRODUCTION
This
section
contains data packages
for
the
Model
130.
Each data package
is
a
quick-access
document,
con-
taining
maintenance data arranged
for
convenient
viewing of the schematic diagram and
all
supporting
data.
Each data package
includes a
parts-location
illustration, a
replaceable parts
list,
voltage/waveform
data,
and
a
schematic diagram. Voltage
and waveform
data are provided on the diagrams
at
indicated
test
points
as
an
aid to
troubleshooting. Also,
a
list
of
manufacturers
is
included
in this section.
RECOMMENDED SPARE PARTS
LIST
Information
is
provided
to
maintain the instrument
on
a
component
level.
Price
and
delivery
information
should be obtained from
the
Wavetek
representative
in
your
area or directly
from
the
factory.
DESCRIPTION
MANUFACTURER
PART
NO.
QTY
DIODE FAIRCHILD FD6666
2
DIODE SEMTECH SCE-1
1
DIODE
WAVETEK
130-506
1
FUSE
1/8A 230
V LITTELFUSE
313-125
1
FUSE
1/4A 115
V
LITTELFUSE
313-250
1C
RCA
*CA3030
(-15)
1
1C
RCA
*CA3030
(-16)
1
1C
RCA
*CA3036
(-17)
1
1C
FAIRCHILD
*jUA709C (-14)
1
LAMP
MURA
L28/40
1
SINE
MODULE WAVETEK
130-011
1
TRANSISTOR
FAIRCHILD 2N2905
1
TRANSISTOR FAIRCHILD 2N3299
1
TRANSISTOR FAIRCHILD 2N3646
2
TRANSISTOR FAIRCHILD 2N3638
1
TRANSISTOR
MOTOROLA
MPS3640
1
TRANSISTOR
MOTOROLA
2N 3903
1
TRANSISTOR
MOTOROLA
2N3905
1
TRANSISTOR SPRAGUE
TD101
1
TRANSISTOR FAIRCHILD
MPS
L08
1
TRANSISTOR FAIRCHILD
2N2369
1
TRANSISTOR TEXAS
INST
•TIP
29
1
TRANSISTOR TEXAS
INST •TIP 30
1
MATCHED
"T
n
A
C A
1
o
11
1 1
n»
r/-\i
i
l.i-/
/
o\
\
o/
O
1 1
Z.
MATCHED
TRANSISTOR FAIRCHILD •2N3646
(-11)
2
MATCHED
TRANSISTOR FAIRCHILD •2N3638
(-9)
2
*
Denotes
special
parts that should be ordered
from Wavetek. These
parts
have been
tested or selected
by Wavetek
for
optimum
performance.
3/72
