Sony Mavica FVP-1 Quick Reference Operating Instructions

S o n y M a v i c a C o l o r P r i n t e r
f o r u s e w i t h t h e V i s t a C a m O m n i
Q
U I C K
Initial
Setup:
Insert the INK CARTRIDGE (far right-hand side).
Step One:
Turn printer ON (far left-hand side - wait for green power light).
Step Two:
Set the following switches (top left-hand side).
Step Three:
To capture and print image:
Note: Use picture button to toggle between MEMORY and INPUT.
Step Four:
To save to disc:
Step Five:
To read or print from disc:
Step Six:
To return to "live" camera image move INPUT SELECT (far left-hand side)
to VIDEO/STILL.
For more detailed information about these and other Mavica
printer functions, please refer to the Sony Mavica Owner's Manual.
R
E F E R E N C E
1) INPUT SELECT: Move to VIDEO/STILL
2) PRESET SELECT: Move to OFF
3) DATE ON or OFF: (see manual for date settings)
4) Rotate PRINT MODE dial to: SINGLE IMAGE (arrow at
the 12:00 position)
1) INPUT light must be illuminated to capture.
2) Depress the CAPTURE button and wait for the tone
3) Insert print paper glossy side up (until approximately 1" remains).
4) Depress PRINT button.
5) Wait until printing has been completed (approximately 100 seconds).
6) To return to "live" image, depress the PICTURE button (INPUT light
illuminated).
1) Insert 3.5" floppy (MS DOS format, high-density only) in
appropriate slot (front left).
2) Depress CAPTURE button (wait for tone; MEMORY light illuminated).
3) Depress SAVE (top right-hand side) and wait for tone.
*The image is now saved onto the disk*
1) Move INPUT SELECT to floppy disc (FD). All stored images
will be displayed.
2) Use the CURSOR (middle button with four arrows) to choose
desired image. Press ENTER to select image. Image is outlined in blue.
3) Depress the CAPTURE button to enlarge then depress PRINT to
print image.
4) To return to stored images press PICTURE button.
O
P E R A T I N G
( M o d e l F V P - 1 )
T M
I
N S T R U C T I O N S
(memory light flashes)
