VOILE TTS Transit Instructions page 3

Ski mode:
The word "SKI" will be visible when the lever is in the middle
position, as seen when you first step into the binding. This is
one step down from the vertical postion. (SEE FIGURE 10)
"SKI"
FIGURE 10
Exit / Release:
To exit the binding or to release the tech pins before stepping in, depress the lever fully to the bottom position. (SEE FIGURE 12)
Lever in bottom
(horizontal)
position.
If moving the assembly backward to a more active position, you must spin the cartidge barrels clockwise to adjust for the
additional slack.
If moving the assembly forward to a more neutral position, you must spin the cartridge barrels counter-clockwise to release
the additional tension.
To remove
heel wires,
rotate them to
vertical position.
Most
Most
Neutral
Active
Position
Position
Walk mode:
The word "SKI" will be obstructed when the lever is in the
vertical position. This locks the toe piece, preventing release of
the boot while touring. (SEE FIGURE 11)
FIGURE 11
Changing the wire position:
Wire position is easily changed in the field.
1) Pull the lock mechanism heelward
toward the release position.
2) Rotate the cartridge assembly forward
toward the toe piece until the wires are
vertical (SEE FIGURE 12).
3) Spread the wires away from each other,
gently wiggling them until both sides
come free from the riser.
Tip: This is easier to accomplish by
keeping subtle pressure between the
wire's hooks and the ski's topsheet.
4) Reinsert the wires in your desired activity
position.
5) Pull the heel assembly "up" while
pushing the locking mechanism forward
into the lock position.
6) Adjust the cartridge barrels accordingly.
FIGURE 12
See instructions on page one of this
document for more details.
TTS Transit
Telemark Touring Bindings
voile.com
