LEI 4001 / 8001 / 15001
User manual
LEI 4001 / 8001 / 15001
Model
Programs
Remote controller
Light source type
Luminous flux
IP rating
Light colour mode
Working voltage
Power
Material of housing
Light engine dimensions
Net weight
Fibre optic port diameter
Maximum number of fibre optic
bundles at 0.75 mm diameter
Lifetime of LED light source
Warranty
Package dimensions (excluding
fibre optic bundle)
Weight with packaging
www.stellarlighting.co.uk
email: info@stellarlighting.co.uk
LEI -4001
With remote controller: brightness adjustment, twinkling wheel on/off
With DIP switches: 8 colour-changing speed settings (with colour-twinkle wheel)
Yes, RF
LED CREE
3,500 Lm
IP20
White (6000 K)
100 - 240V
50W
Aluminium
291 mm (L) x 264 mm (W) x 135 mm (H)
4.8 kg
30 mm
1,250
50,000 hours
2 years
360 mm (L) x 330 mm (W) x 210 mm (H)
5.6 kg
LEI-8001
6,100 Lm
80W
5.0 kg
5.8 kg
LEI-15001
11000 Lm
130W
5.2 kg
6.1kg
1
Advertisement
Related Manuals for Stellar Lighting LEI 4001
Summary of Contents for Stellar Lighting LEI 4001
- Page 1 LEI 4001 / 8001 / 15001 User manual LEI 4001 / 8001 / 15001 Model LEI -4001 LEI-8001 LEI-15001 With remote controller: brightness adjustment, twinkling wheel on/off Programs With DIP switches: 8 colour-changing speed settings (with colour-twinkle wheel) Remote controller...
-
Page 2: Safety Notices
LEI 4001 / 8001 / 15001 User manual Safety notices Electrical work safety advice and tips ● Make sure the input voltage is correct. ● Avoid placing the light engine in the rain or in moist areas. Please ensure that the light engine has sufficient ventilation and is not placed in a completely sealed area. - Page 3 LEI 4001 / 8001 / 15001 User manual Light engine information and dimensions Connection method between optical fibres and the light engine Your fibre optic bundle will come with the connector fittings ready to connect to the light engine. Fig.3 Fig.2...
- Page 4 LEI 4001 / 8001 / 15001 User manual 4. Make sure that the optical fibre bundle head is smooth and clean to ensure even light distribution. Light engine setup DIP switches (Fig.6): • DIP switches: 1~3: programs selection (see table further down) •...
- Page 5 LEI 4001 / 8001 / 15001 User manual Fig.8 • RPM is the speed of the twinkling wheel; • If DIP address is set beyond P07, the machine will run P07 instead. Troubleshooting for remote controller connection issues: • • Check if the battery is operational in the remote controller: Press a button on the remote and the the remote or the battery needs replacing.
-
Page 6: Compliance Notes
LEI 4001 / 8001 / 15001 User manual Compliance notes United Kingdom Waste Electrical and Electronic Equipment Regulations 2013 The waste electrical and electronic equipment regulations in the UK promote the purpose of recycling, recovering and reuse of products and components, thereby, intending to reduce the amount of electrical and electronic waste from being disposed off at landfill sites. - Page 7 LEI 4001 / 8001 / 15001 User manual If you have any questions or comments regarding our products, please contact us on info@stellarlighting.co.uk www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
