MK-S16 RGBW-T / MK-S20 RGBW-T
User manual
Model
Programs
Remote controller
Light source type
CRI (Ra>):
IP rating
Working voltage
Power
Material of housing
Light engine dimensions
Net weight
Fibre optic port diameter
Maximum number of fibre optic
bundles at 0.75 mm diameter
Lifetime
Warranty
Package dimensions (excluding
fibre optic bundle)
Weight with packaging
www.stellarlighting.co.uk
email: info@stellarlighting.co.uk
MK-S16 RGBW-T
MK-S16 RGBW-T
Speed, brightness, 20 colour changing programs, music sync mode, twinkling wheel
speed, on/off
Yes, RF remote and Bluetooth app (RF remote dimensions: 105 mm x 58 mm x 9 mm)
RGBW LED
70
IP20
DC 12 V
16 W
Aluminium
84 mm (L) x 84 mm (W) x 42 mm (H)
0.24 kg
20 mm
550
50,000 hours
2 years
190 mm (L) x 123 mm (W) x 56 mm (H)
0.4 kg
MK-S20 RGBW-T
MK-S20 RGBW-T
20 W
91 mm (L) x 87 mm (W) x 64 mm (H)
0.32 kg
2 x 20 mm
2 x 550
220 mm (L) x 157 mm (W) x 86 mm (H)
0.5 kg
1
Advertisement
Related Manuals for Stellar Lighting MK-S16 RGBW-T
Summary of Contents for Stellar Lighting MK-S16 RGBW-T
- Page 1 MK-S16 RGBW-T / MK-S20 RGBW-T User manual MK-S16 RGBW-T MK-S20 RGBW-T Model MK-S16 RGBW-T MK-S20 RGBW-T Speed, brightness, 20 colour changing programs, music sync mode, twinkling wheel Programs speed, on/off Remote controller Yes, RF remote and Bluetooth app (RF remote dimensions: 105 mm x 58 mm x 9 mm)
-
Page 2: Safety Notices
MK-S16 RGBW-T / MK-S20 RGBW-T User manual Safety notices Electrical work safety advice and tips ● Make sure the input voltage is correct. ● Avoid placing the light engine in the rain or in moist areas. Please ensure that the light engine has sufficient ventilation and is not placed in a completely sealed area. - Page 3 MK-S16 RGBW-T / MK-S20 RGBW-T User manual Connection method between optical fibres and the light engine Your fibre optic bundle will come with the connector fittings ready to connect to the light engine. 1. Align all the optical fibre ends and fasten with tapes which can resist temperature over 130℃...
- Page 4 MK-S16 RGBW-T / MK-S20 RGBW-T User manual Remote controller operation (MK-S16 RGBW-T) Notes: The device can be controlled by the RF remote and the Bluetooth App at the same time. www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
- Page 5 MK-S16 RGBW-T / MK-S20 RGBW-T User manual Remote controller operation (MK-S20 RGBW-T) Notes: The device can be controlled by the RF remote and the Bluetooth App at the same time. Dual-port independent control: 1. Control both ports at the same time: •...
- Page 6 MK-S16 RGBW-T / MK-S20 RGBW-T User manual Troubleshooting for remote controller connection issues: • • Check if the battery is operational in the remote controller: Press a button on the remote and the indicator t there is either no battery in the remote or the battery needs replacing.
- Page 7 MK-S16 RGBW-T / MK-S20 RGBW-T User manual Bluetooth App control guide 1. Download the Bluetooth App Option 1: QR code: • Both Android and Apple phones can scan the QR code to download the app Option 2: App store: My smartLED •...
- Page 8 MK-S16 RGBW-T / MK-S20 RGBW-T User manual 3. Operation and modes Static mode Dynamic mode Sound control mode Twinkle mode www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
-
Page 9: Bluetooth Connection Settings
MK-S16 RGBW-T / MK-S20 RGBW-T User manual The MK-S20 RGBW-T light engine supports dual port control. • • • Bluetooth connection settings www.stellarlighting.co.uk email: info@stellarlighting.co.uk... - Page 10 MK-S16 RGBW-T / MK-S20 RGBW-T User manual 4. Troubleshooting for Bluetooth connection issues • Check that the light engine is powered on. • Check that the Bluetooth is turned on the mobile device. • Check if another mobile phone is already connected to the light engine. If another mobile phone is already connected to the light engine, disconnect it first.
-
Page 11: Compliance Notes
MK-S16 RGBW-T / MK-S20 RGBW-T User manual Compliance notes United Kingdom Waste Electrical and Electronic Equipment Regulations 2013 The waste electrical and electronic equipment regulations in the UK promote the purpose of recycling, recovering and reuse of products and components, thereby, intending to reduce the amount of electrical and electronic waste from being disposed off at landfill sites. - Page 12 MK-S16 RGBW-T / MK-S20 RGBW-T User manual If you have any questions or comments regarding our products, please contact us on info@stellarlighting.co.uk www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
