MK-C6W2 light engine with fibre optic fibre bundle
User manual
Technical specification
Light engine model
Programmes
Remote controller
Light source type
CRI (Ra>):
IP rating
Light colour mode
Working voltage
Rated power
Material of housing
Light engine dimensions
Net weight
Remote control dimensions
Fibre optic port diameter
Fibre optic bundle:
Lifetime
Warranty
Package dimensions (excluding fibre optic bundle)
Weight with packaging
www.stellarlighting.co.uk
email: info@stellarlighting.co.uk
Features:
• Complete star kit for small-scale
projects with light engine, remote
controller, 200 fibre bundle
• RGB light engine
• Touch remote with colour wheel
• Small size
MK-C6W2 RGB K
11 programs, brightness (static mode) speed
(dynamic mode), on/off
Yes, RF
RGB LED chip
70
IP20
RGB
DC12V
6 W (Red: 2W, Green: 2W, Blue: 2W)
Aluminium
135 mm (L) x 36 mm (W) x 36 mm (H)
0.3 kg
113.5 mm x 55.5 mm x 22.5 mm
10-14 mm
200 fibres: 160 x 0.75 mm, 40 x 1.0 mm at 2 m
length
50,000 hours
2 years
200 mm (L) x 170 mm (W) x 90 mm (H)
0.7 kg
1
Advertisement
Table of Contents
Related Manuals for Stellar Lighting MK-C6W2
Summary of Contents for Stellar Lighting MK-C6W2
- Page 1 MK-C6W2 light engine with fibre optic fibre bundle User manual Features: • Complete star kit for small-scale projects with light engine, remote controller, 200 fibre bundle • RGB light engine • Touch remote with colour wheel • Small size Technical specification...
- Page 2 MK-C6W2 light engine with fibre optic fibre bundle User manual Safety notices Electrical work safety advice and tips ● Make sure the input voltage is correct. ● Avoid placing the light engine in the rain or in moist areas. Please ensure that the light engine has sufficient ventilation and is not placed in a completely sealed area.
- Page 3 MK-C6W2 light engine with fibre optic fibre bundle User manual Light engine and remote controller dimensions Connection method between optical fibres and the light engine Your fibre optic bundle will come with the connector fittings ready to connect to the light engine.
- Page 4 MK-C6W2 light engine with fibre optic fibre bundle User manual 4. Make sure that the optical fibre bundle head is smooth and clean to ensure even light distribution. connector. Fasten the bundle with the screw on the top of the...
- Page 5 MK-C6W2 light engine with fibre optic fibre bundle User manual Pairing the remote controller Pairing the light engine. However, in some cases the remote controller can unpair from the light engine. In these scenarios, follow these steps: Press th e light will blink 3 times to indicate that the remote control is paired.
