SightCare CLOVER 5 User Manual

Handheld video magnifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CLOVER 5
Handheld Video Magnifier
User Guide
Rev 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLOVER 5 and is the answer not in the manual?

Questions and answers

Related Manuals for SightCare CLOVER 5

Summary of Contents for SightCare CLOVER 5

  • Page 1 CLOVER 5 Handheld Video Magnifier User Guide Rev 2.0...

  • Page 2: Table Of Contents

    Contents Precaution Quick Start Overview Compositions Accessories Battery and Charging Writing stand Operation...
  • Page 3 Power Button Beep Type Magnification Color Mode Brightness Two-Color Tuning Lighting Freeze Memory Auto power saving...
  • Page 4 Restore Troubleshooting The unit does not turn on Black screen or White screen The image does not change Smudges or blemishes on the screen Specifications...

  • Page 5: Precaution

    Precaution Before using Clover 5 for the first time, you must charge its battery. Refer to Battery and Charging section for more details. Always operate the unit in a place where the temperature is between 10°and 35°C(50°and 95°F).
  • Page 6 Keep the unit away from wet areas, rain, and other sources of liquids. Do not submerge the unit. Do not attempt to repair the unit. Any unauthorized attempt will void the product warranty. Contact your distributor to service. Use the supplied power adapter and battery.

  • Page 7: Quick Start

    Quick Start Overview Thank you for purchasing CLOVER 5. CLOVER 5 is a handheld video magnifier with a 5 inch widescreen LCD display. The unit allows you to put the magnifier on or close to the object for continuous zoom or freeze the image...
  • Page 8 fold-away writing stand. This unit is ideal for viewing labels, books, newspapers and more.

  • Page 9: Compositions

    Compositions 1. LCD screen 2. Zoom In 3. Color Mode Up 4. Color Mode Down 5. Zoom Out...
  • Page 10 6. Camera 7. LED lights 8. Writing stand 9. Battery slot...
  • Page 11 10. Power LED 11. Power 12. Beep 13. Freeze 14. Charging/DC port...

  • Page 12: Accessories

    Accessories User Manual Power Adapter Cleaning Cloth battery Carrying Case...

  • Page 13: Battery And Charging

    Battery and Charging Battery installation 1. Turn the unit to make the back face up.
  • Page 14 2. Press the arrow icon on the battery cover and slide outward to open the battery cover. 3. Insert the battery to the right position in the slot. 4. Place and slide back the battery cover. Charging the battery 1. Connect the supplied cable to the USB port on the power adapter and round port on the unit.
  • Page 16 The status of Power LED indicator  Charging when the unit is off, the power LED will be green, then auto turn off when fully charged. A fully charge will take about 3 hours, supporting the unit working continuously for about 3 - 3.5 hours. When the unit is on and the power adaptor is not ...

  • Page 17: Writing Stand

    Writing stand Open the writing stand as the following figure shows. And you can write under the camera.

  • Page 18: Operation

    Operation Power Button  Press and hold the Power button for 3 seconds to turn on/off the unit when it is off.  Press the Power button to check the current status of battery capacity, color mode, freeze mode and beep.

  • Page 19: Beep Type

     Press other button when holding the Power button will make combo function, refer to the following instructions for more details. Beep Type  Unit on/off beep  Button beep  Threshold beep  Low battery beep...

  • Page 20: Magnification

    Beep Control：  Press and hold the Freeze button for 3 seconds to turn on/off the beep. Magnification  Press the Zoom In button to increase magnification, and hold the Zoom In button continuous increasing.

  • Page 21: Color Mode

     Press the Zoom Out button to decrease magnification, and hold the Zoom Out button for continuous decreasing.  Magnification Range: 4x – 20x Color Mode A color mode is a pre-defined color combination. Full color mode is suitable for picture, map viewing, and enhanced contrast mode is combined with different foreground and background colors and can help to read clearly.
  • Page 22  Press the Color Mode Up / Down button cycle through the color combination list.  Press the Color Mode Up button and the Color Mode Down button at the same time to quick switch between Full color mode and current enhanced contrast mode.
  • Page 23  Holding the Color Mode Up button and the Color Mode Down button at the same time for 5 seconds to switch between the Simplified Color Combination List and the Integrated Color Combination List (factory default). The Simplified Color Combination List (5 modes)： White on Black Black on White White on Blue...
  • Page 24 The Integrated Color Combination List (19 modes) White on Black Black on White Yellow on Black Black on Yellow White on Blue Blue on White Yellow on Blue Blue on Yellow Green on Black Black on Green Violet on Black Black on Violet Blue on Black Black on Blue...

  • Page 25: Brightness

    White on Green Green on White White on Red Red on White Red on Black Brightness Adjust the display brightness for Full color mode and Enhanced contrast mode. Factory default value will be highlighted green. Power button and Zoom In button /Zoom ...

  • Page 26: Two-Color Tuning

    Two-Color Tuning By fine adjusting the combination of foreground and background color in Enhanced contrast mode, the tuning will improve the adaptability for viewing different materials. Factory default value will be highlighted green. Power button and Color Mode button  adjust the background / foreground color in the contrast color mode.

  • Page 27: Lighting

    Lighting  Power button and Freeze button ， turn on/off the LED Lighting. Freeze Freezing an image on the LCD screen can be useful for further reading by zooming in or zooming out or changing the color mode for a better view. ...
  • Page 28  When increase the magnification of the locked image, you can use the following combo button to navigate. Power button and Color Mode button , navigate upward or downward. Power button and Zoom button ,navigate leftward or rightward.

  • Page 29: Memory

    Memory The unit will memorize automatically the most recent settings such as color mode, magnification, beep when power off normally and use them in the next power on. Auto power saving If no operation and no moving for over 3 minutes, the unit will turn off automatically.
  • Page 30 Holding the Power Power button Freeze button for 3 seconds to turn on/off the Auto Power Saving. Restore Holding the Freeze button and the Zoom Out  button at the same time for 3 seconds to reset to the default factory settings. Auto power off when resetting is done.
  • Page 31 Troubleshooting The unit does not turn on  Connect to the power adapter  Charge the battery  Reinstall the battery Black screen or White screen  If the unit is sitting on a flat pure surface, the screen may be black or white, Lift the unit off to ensure change happens.
  • Page 32  Adjust the magnification  Adjust the color mode  Restart the unit  Reinstall the battery The image does not change  If the unit enter the freeze mode, the image will not change  Press power button to check the current status ...
  • Page 33  Reinstall the battery Smudges or blemishes on the screen  Adjust brightness  Clean the LCD screen and camera Please contact your local distributor if problem is not solved。...
  • Page 34 Specifications  Display: 5 inch wide screen LCD  Size: <=152*80*22mm  Weight: <210 grams (Battery included)  Color Mode: Simplified 5 modes; Integrated 19 modes  Magnification: Approximately 4x ~ 20x  Battery: Rechargeable & detachable Li battery Nearly 3~3.5 hours continuous use Charges in approximately 3 hours ...
