- Page 1 Troubleshooting Guide StealthNet™, TrailerNet™...
-
Page 2: Quick Overview
StealthNet™ StealthNet™ with ABS 1. Quick Overview a. StealthNet™ With ABS Harness i. Unit has a cable that connects to in ABS power line to supply power to unit. (Figure 1) 1. Pin 1 Main Power (Positive) 2. Pin 2 Aux. Power (Positive) 3. - Page 3 c. All units come with a Shipping Plug. This plug keeps the unit in ship mode and will not connect to GPS or Cell. i. The Shipping plug needs to be removed prior to installation. ii. The shipping plug can also be used to do a soft reset of the unit. This will just reboot the unit and not clear any trip data.
- Page 4 Inspect for Damage to unit. c. Phillips Connect devices need a clear view of the sky or the ground to communicate with GPS. d. Devices that are not able to connect to GPS will not show accurate location or trips.
- Page 5 1. If the battery drops below 3.20 Volts, the unit will go into a low voltage mode and will not report until the unit is above 3.45 Volts to restart the MCU. 2. You may request an ABS cable or Cigarette lighter cable from Phillips Connect to charge the unit.
