- Page 1 Troubleshooting Guide SolarNet...
-
Page 2: Quick Overview
Connector for optional tether cable 1. Quick Overview a. SolarNet With Tether Harness i. Unit has a cable that connects to power line to supply power to unit. (Figure 1) 1. Pin 1 Main Power (Positive) 2. Pin 2 Aux. Power (Positive) 3. - Page 3 d. LED Indicators i. LED indicators may not show if the unit is not powered externally. Units working on Battery may need to sense vibration to get LEDs to light. ii. The LED indicators behaviors are in the table 1. e.
- Page 4 Inspect for Damage to unit c. Phillips Connect devices need a clear view of the sky or the ground to communicate with GPS. d. Devices that are not able to connect to GPS will not show accurate location or trips.
- Page 5 1. If the battery drops below 3.20 Volts, the unit will go into a low voltage mode and will not report until the unit is above 3.45 Volts to restart the MCU 2. You may request an Power cable or Cigarette lighter cable from Phillips Connect to charge the unit.
