Summary of Contents for Redarc Solar SPMB0002
- Page 2 REDARCs xed solar panels and other popular solar panels to an ARB Base Rack and Rhino–Rack Steel Mesh Platform systems. REDARC stock three other variants of Solar Brackets to suit different solar panels and crossbars: SPMB0001 — suited to mount solar panels (35 mm max.
-
Page 3: Warnings And Safety Information
Do not install the mounting brackets unless you have read and understood this manual. Disclaimer: REDARC accepts no liability for any injury, loss or property damage which may occur from the improper or unsafe installation or use of its products. - Page 4 SOLAR BRACKET PARTS Bracket A Bracket B 1. Solar Panel Bracket 4. M6 × 19 mm S/S Flat Washer Supplied with 4 sets of brackets Supplied with 16 at washers. 2. M6 × 12 mm S/S Philips Bolt 5. M6 × 12 mm S/S Flat Washer Supplied with 8 bolts.
-
Page 5: Installation
INSTALLATION DETERMINE THE MOUNTING POSITION The Solar Brackets must be bolted and tted to the solar panel then clamped to the crossbars. Do not install the Solar Brackets to the crossbars rst. To determine where to bolt the Solar Brackets to the solar panel, place the solar panel in the desired location on the crossbars and mark its position. -
Page 6: Completed Installation
ASSEMBLE BRACKETS TO PANEL Position and bolt Bracket A into and in-line with the drilled Solar Panel holes on the solar panel, using the supplied Nyloc Nuts, M6 × 12 mm Flat Washers and M6 × 12 mm Bolts. CAUTION Leave adequate clearance around the Solar Panels to ensure the panels do not become partially shaded when in-use, and to allow access for maintenance Bracket A... -
Page 7: Warranty
Mexico +52 (558) 526-2898 Design and specications are subject to change without notice. | Copyright © 2024 REDARC Electronics Pty Ltd. All rights reserved. REDARC® and THE POWER OF REDARC® are trademarks of REDARC Electronics Pty Ltd. REDARC®, THE POWER OF REDARC®, and REDARC Solar® are trademarks of REDARC Electronics Pty Ltd. - Page 8 Tech Support 1300 REDARC (1300-733-272) Australia +61 8 8322 4848 New Zealand +64 9 222 1024 UK & Europe +44 (0)20 3930 8109 +1 (704) 247-5150 Canada +1 (604) 260-5512 Mexico +52 (558) 526-2898 redarcelectronics.com INST137−3...
