Portable Lamps
Series 6148
Series 6148 E2
The portable lamps of the Series 6148 are explosion-protected
electrical equipment. They are used as portable lighting equipment
in hazardous areas of Zones 1, 2, 21 and 22.
The lamp is charged outside the hazardous area.
Zone
For use in
WebCode
6148A
2015-05-05·EK00·III·en
ATEX / IECEx
0
1
2
20
x
x
>
Latest LED technology
>
Very high light intensity
>
Low weight
>
Lamp head pivoting by 190°
>
Main light continuously
dimmable
>
Long battery life
>
Ergonomic one-hand operation
14755E00
21
22
x
x
E2
E2
E2
E2
E2
E2
E2
E2
E2
E2
E2
E2
E2
E2
Lighting
E2/1
Advertisement
Table of Contents
Related Manuals for Stahl 6148A
Summary of Contents for Stahl 6148A
- Page 1 The portable lamps of the Series 6148 are explosion-protected electrical equipment. They are used as portable lighting equipment in hazardous areas of Zones 1, 2, 21 and 22. The lamp is charged outside the hazardous area. ATEX / IECEx Zone For use in WebCode 6148A Lighting E2/1 2015-05-05·EK00·III·en...
- Page 2 Portable Lamps Series 6148 Selection Table Version Description Order number Weight Portable lamp and charging unit 1.830 6148/1111-111 (12 ... 30 V DC and 110 ... 240 V AC, 50 / 60 Hz) in a packaging set 15752E00 Portable lamp with charging unit, explosion protected Series 6148...
- Page 3 Portable Lamps Series 6148 Technical Data Luminous characteristics Lamps main light, LED: 3 W secondary light, LED: 0.5 W Light intensity 24,000 cd 6500 K Light distribution acc. to DIN 14642 Functions continuous light or flashing light of the main light, continuous light of the secondary light, function of the main light continuously dimmable Emergency light duration main light:...
- Page 4 Portable Lamps Series 6148 Accessories and Spare Parts Designation Figure Description Art. no. Weight Lense clear 0.014 212333 15769E00 orange 0.012 212334 15768E00 0.012 212956 15770E00 green 0.013 220306 16228E00 Connection cable 0.085 120014 Charging cable 230 V with plug 10318E00 0.022 212316...
- Page 5 Portable Lamps Series 6148 Dimensional Drawings (All Dimensions in mm [inches]) - Subject to Alterations ø 4,50 [ø 0,18] 279 [10,98] 64 [2,52] 79 [3,11] 140 [5,51] 14754E00 14753E00 Portable lamp Charging unit 135 [5,32] 55 [2,17] ø 4,50 [ø 0,18] 64 [2,52] 14807E00 Drilling hole pattern for wall mounting bracket...
- Page 6 Operating instructions Additional languages r-stahl.com Portable Lamp Series 6148...
-
Page 7: Table Of Contents
Contents General Information ....................3 Manufacturer .......................3 Information regarding the Operating Instructions ..........3 Further Documents .....................3 Conformity with Standards and Regulations ............3 Explanation of the Symbols ................4 Symbols in these Operating Instructions ............4 Warning Notes ....................5 Symbols on the Device ..................5 Safety Notes .......................6 Operating Instructions Storage ................6 Safe Use ......................6... -
Page 8: En En
They are legally binding in all legal affairs. Further Documents • Data sheet For documents in additional languages, see r-stahl.com. Conformity with Standards and Regulations For certificates and declaration of conformity, see r-stahl.com. 206676 / 614860300010 Portable Lamp 2023-06-01·BA00·III·en·09 Series 6148... -
Page 9: Explanation Of The Symbols
Explanation of the Symbols Explanation of the Symbols Symbols in these Operating Instructions Symbol Meaning Tips and recommendations on the use of the device General danger Danger due to explosive atmosphere Danger due to energised parts Risk of damage to the eyes caused by optical radiation Portable Lamp 206676 / 614860300010 Series 6148... -
Page 10: Warning Notes
Explanation of the Symbols Warning Notes Warnings must be observed under all circumstances, in order to minimize the risk due to construction and operation. The warning notes have the following structure: • Signalling word: DANGER, WARNING, CAUTION, NOTICE • Type and source of danger/damage •... -
Page 11: Safety Notes
• Use the device in accordance with its intended and approved purpose only. • Always consult R. STAHL Schaltgeräte GmbH if using the device under operating conditions which are not covered by the technical data. • We cannot be held liable for damage to the device caused by incorrect or unauthorised use or non-compliance with these operating instructions. -
Page 12: Modifications And Alterations
Function and Device Design Modifications and Alterations DANGER Explosion hazard due to modifications and alterations to the device! Non-compliance results in severe or fatal injuries. • Do not modify or alter the device. No liability or warranty for damage resulting from modifications and alterations. -
Page 13: Technical Data
Technical Data Technical Data Explosion Protection Global (IECEx) Gas and dust IECEx IBE 11.0009 Ex ib IIC T4 Gb Ex tb IIIC T75 °C Db Europe (ATEX, UKEX) Gas and dust IBExU 11 ATEX 1066, CML 21UKEX21301 E II 2 G Ex ib IIC T4 Gb E II 2 D Ex tb IIIC T75 °C Db Certifications and certificates Certificates... - Page 14 110 to 240 V AC: approx. 1.8 m long, with Europlug, 2-pin charging cable 12 to 30 V DC: approx. 1.8 m long, with free ends, 2-pin For further technical data, see r-stahl.com. 206676 / 614860300010 Portable Lamp 2023-06-01·BA00·III·en·09...
-
Page 15: Transport And Storage
Transport and Storage Transport and Storage General • Transport and store the device only in the original packaging. • Store the device in a dry place (no condensation) and vibration-free. • Do not drop the device. Batteries • Do not transport together with other materials. •... -
Page 16: Dimensions / Fastening Dimensions
Mounting and Installation Dimensions / Fastening Dimensions Dimensional drawings (all dimensions in mm [inches]) – Subject to modification ø 4,50 [ø 0,18] 279 [10,98] 64 [2,52] 79 [3,11] 14754E00 140 [5,51] 14753E00 Portable lamp Charging unit 135 [5,32] 55 [2,17] ø... -
Page 17: Mounting / Dismounting, Operating Position
Mounting and Installation Mounting / Dismounting, Operating Position DANGER Explosion hazard when used in hazardous areas. Non-compliance results in severe or fatal injuries. • Only assemble and use the charging unit in safe areas. 7.2.1 Charging Unit Assembly Due to its IP degree of protection, the charging unit is only suitable for indoor use. - Page 18 Mounting and Installation Table mounting • Place the charging unit (2) on a level surface (3). • Secure it in the correct location using 3 screws (1) (tightening torque 1.5 Nm); screws are not included in delivery. 14772E00 7.2.2 Charging Unit Connection 110 to 240 V AC •...
- Page 19 Mounting and Installation 7.2.3 Assembly of the Adapter in third-party Charging Units Adapter for third-party charging units LG443 • Insert the adaptor (1) into the third-party charging unit LG443 (2). • Push the brackets (3) onto the third-party charging unit LG 443 (2). •...
-
Page 20: Commissioning
Commissioning Commissioning DANGER Explosion hazard when used in hazardous areas. Non-compliance results in severe or fatal injuries. • Only assemble and use the charging unit in safe areas. Insert the portable lamp into the connected charging unit before using it for the first time Charging unit: •... -
Page 21: 9 Operation
Operation Operation DANGER Explosion hazard due to incorrect installation! Non-compliance results in severe or fatal injuries. • Check the device for proper installation before commissioning. • Comply with national regulations. CAUTION Risk of damage to the eyes caused by optical radiation! Non-compliance can result in minor injuries. -
Page 22: Emergency Light Operation
Operation 9.1.3 Switching off • Press the pushbutton when the main light is blinking. • Press the pushbutton at least 5 seconds after the last switching operation. 9.1.4 Dimming Mode WARNING Risk of injury due to rotating parts under stroboscopic lighting. Non-compliance can result in severe or fatal injuries. -
Page 23: Charging Operation
Operation 9.2.1 Switching the Emergency Light Mode on and off Upon delivery, the "Emergency light mode" function is on. With the function switched off and in case of power failure, the following states will be activated at the portable lamp. before insertion into the charging unit: in case of power failure: Main LED and secondary LED: OFF Main LED and secondary LED: OFF Main LED: ON... - Page 24 Operation Charging unit: • Connect to the supply voltage. • Ensure that the "Power" LED lights up. • Insert the portable lamp. Portable lamp: The portable lamp reacts when it is placed in the charging unit – it switches off any LEDs that are switched on, performs a function test and indicates the state of charge and any errors via the LED display.
-
Page 25: 9.4 Battery Capacity Test
Operation Battery Capacity Test DANGER Explosion hazard when used in hazardous areas. Non-compliance results in severe or fatal injuries. • Only assemble and use the charging unit in safe areas. The test: • should be carried out once a year. •... -
Page 26: Indications
Operation Test sequence • The battery is charged for 12 hours. • Then the LED main light is switched on. • The battery is discharged to 10% of its capacity. • The discharge time is measured and evaluated. green green green green Description Battery test aborted Interruption of the charging operation After charging, the battery capacity is less than... - Page 27 Operation Charging operation green green green green Description Battery capacity < 20% Battery capacity < 42% Battery capacity < 65% Battery capacity < 88% Battery capacity ( 98% Battery capacity > 98% Activating and deactivating the emergency light operation green green green green Description Emergency lighting function off Emergency lighting function on Activating/deactivating the charging switch-off when used in a motor vehicle...
-
Page 28: Troubleshooting
• Insert portable lamp into charging unit. • Charge battery. If the error cannot be eliminated using the mentioned procedures: • Contact R. STAHL Schaltgeräte GmbH. For fast processing, have the following information ready: • Type and serial number of the device •... -
Page 29: Maintenance, Overhaul, Repair
Maintenance, Overhaul, Repair Maintenance, Overhaul, Repair CAUTION Risk of electric shock or malfunction of the device due to unauthorized work! Non-compliance can result in light injuries! • Before carrying out work on the device, switch off voltage supply. • Work performed on the device must only be carried out by authorized and appropriately trained qualified electricians. - Page 30 Maintenance, Overhaul, Repair 10.1.1 Battery Replacement DANGER Explosion hazard if the device is opened in a hazardous area. Non-compliance results in severe or fatal injuries. • Only open the device in a safe area. 14945E00 6 screws for head (Torx 10) PCB connection line PCB connection line (+;...
-
Page 31: 10.2 Repair
• Only return or package the devices after consulting R. STAHL! Contact the responsible representative from R. STAHL. R. STAHL's customer service is available to handle returns if repair or service is required. • Contact customer service personally. • Go to the r-stahl.com website. -
Page 32: Disposal
Accessories and Spare Parts NOTICE Malfunction or damage to the device due to the use of non-original components. Non-compliance can result in material damage. • Use only original accessories and spare parts from R. STAHL Schaltgeräte GmbH. Figure Description Art. no. Weight...
