Saddlemen 3501-0232 User's Manual & Installation Instructions

DESCRIPTION:
FITMENT:
Qty Item
2 Saddlebags
2 Studs 5/16 x 2-1/2
2 5/16 docking posts
2 3/8 docking posts
2 Chrome spacers
2 Black wires
8 Butt connectors
2 Socket cap screws 1/16-18 x 3"
2 Keys for QR buckles
Please read these instructions completely before starting installation. All "NOTE," "CAUTION" and "WARNING" notations are serious safety issues and
should be read carefully. Possible injury to riders or damage to the motorcycle and/or accessory may result if improperly installed.
These instructions contain important information for future reference and should be given to the customer.
READ THESE INSTRUCTIONS THOROUGHLY BEFORE INSTALLATION!
Because of the variety of motorcycle configurations, other accessories, and the features and intended use of this Saddlemen accessory, there are many different mount-
ing options. You are responsible for the proper installation of this accessory on your motorcycle. Your attention to these installation instructions and recommendations
will permit safe and proper use of this accessory. You must mount this accessory properly and securely before riding your motorcycle. If you lack the ability to safely and
properly install this accessory, seek out a qualified motorcycle technician for assistance. During installation, support the motorcycle with a suitable stand or lift so it will
not tip over and injure you, or damage the vehicle. Using or mounting this accessory improperly could result in a loss of control of the motorcycle which could result in
damage to your motorcycle or other personal property, the property of third parties, and/or personal injury to yourself or others, up to and including death.
BE SURE TO THOROUGHLY READ AND CLOSELY FOLLOW THE MOUNTING INSTRUCTIONS THAT ARE INCLUDED WITH THIS ACCESSORY:
• The saddlebags must be installed and securely fastened onto the frame or similar foundation on the motorcycle.
• Install the saddlebags securely so they will not shift or move while riding. Make sure the mounting hardware will not contact the wheels, suspension or any other mov-
ing parts of the motorcycle.
• If you do not understand the mounting instructions DO NOT mount the saddlebags. Remove the base or any components you may have already installed on your
motorcycle.
• Thoroughly inspect your motorcycle luggage before every ride. Do not use the saddlebags if the mounting system has been modified, has deteriorated, loosened or is
beginning to fail.
• Before riding, secure your cargo inside the saddlebags and completely close the lids/flaps.
• Continually check the security of the saddlebags at each stop as you ride. Hardware can loosen during operation, so be sure to check it frequently.
• Do not use this accessory if you have any doubts as to whether it is properly mounted to your motorcycle.
• Do not exceed 10 pounds of total weight, combined, of the saddlebag and its contents.
• Do not transport or store flammable or potentially explosive materials in your saddlebags.
• When using this accessory, do not exceed your vehicle's Maximum Gross Vehicle Weight as listed on your motorcycle or in the manufacturer's owner's manual.
• If your saddlebags are ever damaged, do not use them until they have been inspected by your local professional motorcycle dealer. Replace the saddlebags immedi-
ately if they have damage that prevents them from being properly secured to your motorcycle or from securely holding their contents.
DO NOT ATTEMPT TO USE THIS ACCESSORY IF...
• You do not understand the installation and use of its instructions;
• You do not understand any part of the accessory mounting system;
• You have any doubts as to the security of the mounting system.
If you have any concerns or questions, seek help at your qualified motorcycle dealer or call the Saddlemen support line at (310) 638-1222.
Remember: Motorcycling can be a dangerous activity. Installation of any accessory can increase your risk if it is not installed properly. You are responsible to install this
accessory so it will not contact any portion of the drive train, suspension or steering, and so it will in no way interfere with the operation of your motorcycle.
S4 Rigid Mount Saddlebags
H-D® Dyna® models 1996-2017
Qty Item
2 Saddle bag supports
2 Studs 3/8 x 3
2 5/16 lock nuts
2 3/8 lock nuts
2 Turn signal brackets
2 Green wires
2 Hex nuts 5/16-18
4 1/4 Turn bag locks
1 Instructions
PART NUMBER: 3501-0232, 3501-0233
3501-0232, -0233 Rev 3 (12-2022)
