DESCRIPTION:
• Standard tunnel bag (3516-0108) fits motorcycles with a 9-inch wide or smaller rear seat/pillion
- Exterior dimensions : 15" L x 17.5" W x 11" H. Tunnel is 9" wide in front, tapering down to 6" in the rear x 3"D x 15"L
• Wide tunnel bag (3516-0109) fits motorcycles with a 12" wide or smaller rear seat/pillion.
- Exterior dimensions : 15"L x 21" W x 11" . Tunnel is 12" wide in front tapering down to 9" in the rear x 3"deep x 15"long.
• Includes an easy-to-use, universal, rear seat mounting system that easily attaches to most rear seats and pillion pads.
• Large main compartment spacious enough for laptop or notebook computer and three internal pockets.
• Internal tech organizer perfect for smartphones, digital cameras, or music players.
• Adjustable main compartment clamshell straps can be opened a full 180-degrees.
• Three big exterior pockets allow easy access to items on the go, two of which expand an additional two-inches for extra storage.
• Water-resistant construction with an integrated rain cover, so no matter what the weather, you're prepared.
• Thirteen exterior D-rings provide huge flexibility in attaching items to the bag such as jackets or other luggage.
• Six concealed D-rings are easy to use, but without any danger of scratching your bike's finish.
• Comfortable carry handle allows the bag to be used like a suitcase when off the bike.
• SaddleTuff™ 1200 denier, high durability fabric and semi-rigid construction holds shape and looks great even when empty.
Qty
Item
1
Tail Bag
1
Mounting Pad
2
Mounting harness straps
4
Pull down/Shoulder straps
1
Instructions
Please read these instructions completely before starting installation. All "NOTE," "CAUTION" and "WARNING" notations are serious
safety issues and should be read carefully. Possible injury to riders or damage to the motorcycle and/or accessory may result if improperly
installed.
These instructions contain important information for future reference and should be given to the customer.
READ THESE INSTRUCTIONS THOROUGHLY BEFORE INSTALLATION!
Because of the variety of motorcycle configurations, other accessories, and the features and intended use of this Saddlemen accessory
luggage, there can be many different mounting options. You are responsible for the proper installation of this accessory on your motorcycle.
Your attention to these installation instructions and recommendations will permit safe and proper use of this accessory. You must mount
this accessory properly and securely before riding your motorcycle. If you lack the ability to safely and properly install this accessory, seek
out a qualified motorcycle technician for assistance. During installation, support the motorcycle with a suitable stand or lift so it will not tip
over and injure you, or damage the vehicle. Using or mounting this accessory improperly could result in a loss of control of the motorcycle
which could result in damage to your motorcycle or other personal property, the property of third parties, and/or personal injury to yourself
or others, up to and including death.
Tunnel Tail Bag
PART NUMBERS:
Standard 3516-0108
Wide 3516-0109
11-400174 Tunnel Tail Bag Rev1 (08-22)
Advertisement
Related Manuals for Saddlemen TS1450R
Summary of Contents for Saddlemen TS1450R
- Page 1 READ THESE INSTRUCTIONS THOROUGHLY BEFORE INSTALLATION! Because of the variety of motorcycle configurations, other accessories, and the features and intended use of this Saddlemen accessory luggage, there can be many different mounting options. You are responsible for the proper installation of this accessory on your motorcycle.
- Page 2 Your Saddlemen Tunnel Tail Bag has been designed to mount on a variety of motorcycles using the included mounting pad and strap system that attaches the accessory to the rear seat. You (or your professional motorcycle technician) will need to determine the best mounting configuration for your motorcycle or scooter.
- Page 3 Temporarily set the bag onto the seat to see if any portion of the bag will touch the body work of the motorcycle, If so, install protective tape on the bodywork (2) to protect the painted finish (Saddlemen offers a protective tape kit, available from your dealer; please order Saddlemen #4320-0807) IMPORTANT: After installing the seat, lift up on the seat to make sure it is securely attached to the motorcycle.
-
Page 4: Rain Cover
In addition to the three retention straps, the bag is further secured to the mount- ing pad via hook-and-loop fastener material on the top of the mounting pad and on the underside of the tunnel-area of the bag. As you are installing the bag on the motorcycle, press down on the bag to engage the hook-and-loop fastener material. - Page 5 SADDLEMEN LIMITED ONE-YEAR WARRANTY Saddlemen warrants its products for defects in materials, design or workmanship for a period of one year after retail purchase. Items that are defective will be repaired or replaced by Saddlemen at its sole discretion. Damage caused by improper use or improper installation is not a defect;...
