FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE
INSTALLING OR OPERATING THIS CONTROL COULD CAUSE PERSONAL
INJURY AND/OR PROPERTY DAMAGE.
• 50M58-956 Integrated Furnace Control
50M58-956 is an aftermarket direct replacement control
kit for York two stage furnace products with ECMx blower
motors.
ELECTRICAL RATINGS:
Input Low Voltage: 25 VAC, 60 Hz
Input Line Voltage:
120 VAC, 60 Hz, 1φ
Max Input Current: 0.8 A @ 24 VAC
Relay Contact Ratings:
1
st
Stage Gas Valve: 1.5 A @ 24 VAC
Stage Gas Valve: 0.5 A @ 24 VAC
2
nd
Ignitor Relay: 2.0 A @ 132 VAC
Inducer Relay: 2.2 FLA – 3.5 FLA @ 120 VAC
Circulator Relay: 12 mA RMS @ 24 VAC
Humidifier Load: 1.0 A @ 120 VAC
Electronic Air Cleaner: 1.0 A @ 120 VAC
Flame Current Requirements:
Minimum current to ensure flame detection: 0.3 μA
DC*
Maximum current for non-detection: 0.1 μA DC
Maximum allowable leakage resistance: 100 M ohms
* Measured with a DC ammeter
Flame Establishing Time: 0.8 seconds maximum
Flame Failure Response Time: 2.0 seconds
maximum
OPERATING TEMPERATURE RANGE:
-40° to 176°F (-40° to 80°C)
HUMIDITY RANGE:
5 to 93% relative humidity (non-condensing)
AGENCY APPROVALS: UL USA / Canada
GASES APPROVED:
Natural, Manufactured, Mixed, Liquid Petroleum,
and LP Gas Air Mixtures.
York, ECMx, 2-Stage, IFC
120V Hot Surface Ignition Control Kit
INSTALLATION INSTRUCTIONS
• Installation Instructions
Simple push-button fault recall and tri-color LED displays
status and fault codes for easy troubleshooting.
Failure to comply with the following warnings could
result in personal injury or property damage.
FIRE HAZARD
• Do not exceed the specified voltage.
• Protect the control from direct contact with water
(dripping, spraying, rain, etc.)
• If the control has been in direct contact with water,
replace the control.
• Label all wired before disconnection when servicing
controls. Wiring error can cause improper and
dangerous operation.
• Route and secure wiring away from flame.
SHOCK HAZARD
• Disconnect electric power before servicing.
• Ensure proper earth grounding of appliance.
• Ensure proper connection of line neutral and line
hot wires.
EXPLOSION HAZARD
• Shut off main gas to appliance until installation is
complete.
IMPORTANT NOTE: ELECTROSTATIC DISCHARGE
(ESD) PRECAUTIONS
Before removing the new control board from the static wrap,
it is very important to discharge any static electricity. This
can be accomplished in two methods. Servicer can wear
a ground strap or by touching the metal chassis before
replacing the board.
white-rodgers.com
50M58-956
PARTS INCLUDED
DESCRIPTION
SPECIFICATIONS
WARNING
!
PART NO. 37-7895001
2337

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the White-Rodgers 50M58-956 and is the answer not in the manual?

Questions and answers

Summary of Contents for Copeland White-Rodgers 50M58-956

  • Page 1 50M58-956 York, ECMx, 2-Stage, IFC 120V Hot Surface Ignition Control Kit INSTALLATION INSTRUCTIONS FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE PERSONAL INJURY AND/OR PROPERTY DAMAGE. PARTS INCLUDED • 50M58-956 Integrated Furnace Control •...
  • Page 2 TIMINGS 50M58-956 TIMING TABLE (All times are in seconds, unless noted otherwise) Event Definition Time Pre-purge Time The period of time intended to allow for the dissipation of any unburned gas or residual products of combustion at the beginning of a furnace operating cycle prior to initiating ignition Igniter Warm-up Time The length of time allowed for the igniter to heat up prior to the initiation of gas flow.
  • Page 3: Installation

    INSTALLATION 6. Check to see that all wire connections were made NOTE: All wiring should be installed according to local properly and national electrical codes and ordinances. Ensure all wires are secure to the control board Disconnect electrical power and shut off gas supply and unused blower speed wires are attached to the to unit, then remove unit access panels.
  • Page 4: Cool Mode

    OPERATION On the 50M58-956 control, the circulator will remain at shorted or open condition in the flame probe circuit high heat speed for 30 seconds following the opening will be sensed within 2.0 seconds. The gas valve will of the second stage gas valve and then is reduced to de-energize and the control will restart the ignition low heat speed.
  • Page 5 WIRING TRANSFORMER ECMx BLOWER R IGNITOR IGNITO INDUCER FLAME CURRENT SENSE 1VDC=1µA ORG/BLK ROS2 ROS1 RED/WHT RED/BLK RED/GRN VALVE THERMOSTAT...
  • Page 6: Troubleshooting

    TROUBLESHOOTING Green Amber Error/Condition LED Flash LED Flash LED Flash Flame sensed with gas valve off Pressure switch closed with inducer off 1st-stage pressure switch open with inducer on Limit/Rollout switch open Limit/Rollout switch open more than 15 minutes Pressure switch cycle lockout Lockout due to failed ignition Lockout due to too many flame dropouts Incorrect line voltage polarity...
