Dimplex LIK 12TU Quick Installation Manual
Air/water heat pump
Hide thumbs
Also See for LIK 12TU:
- Installation and operating instructions manual (64 pages) ,
- Installation and operating instruction (140 pages)
Advertisement
Quick Links
Quick Installation Guide
Luft-Wasser-Wärmepumpe
LIK 12TU
+A100 / +A200
Wärmepumpe / Wäremepumpenmanager
heat pump / heat pump manager
pompe à chaleur / gestiennaire de pompe à chaleur
-X1
-X3
-X2
1
electrical
layout
+A300
Elektroverteilung
electrical distribution system
distribution électrique
Sicherung
Wärmepumpenmanager
fuse heat pump manager
coupe-circuit gestionnaire
de pompe à chaleur
-F+A200
C13A
Schütz EVU-Sperre
contactor utility block
contacteur blocage EJP
-K22
-WK22
-W+A200
Oelflex 100
NYM-J
2x0,5mm²
3x1,5mm²
Glen
Dimplex
Deutschland
Dimplex
Sicherung Wärmepumpe -X1
fuse heat pump -X1
coupe-circuit
pompe à chaleur -X1
-F+A100
C13A
-W+A100.1
NYM-J
5x1,5mm²
452160.66.79a
FD 0309
