  • Page 1 P.N.:6530-512E Rev. A Select® Series Owner's manual Constance ® Victoria ™...

  • Page 2: Attention New Spa Owner

    Attention New Spa Owner! Congratulations on the purchase of your new Sundance ® spa! The following is a list of automated functions and maintenance recommendations for your new spa. Automated functions have been listed below in an attempt to suppress any operational concerns you may have during startup and the first 24-hours of ownership! Maintenance recommendations are listed in an attempt to stress their importance in protecting your new spa.

  • Page 3: Table Of Contents

    10.2 Economy Filtration/Heating Modes (F4-F6) ......31 10.3 Lock Modes (L1-L3) ............31 10.4 Selecting The Filtration/Heating Mode ......31 10.5 Programming the Circulation Pump Filtration Cycle ..33 10.6 Programming the CLEARRAY® (Ultraviolet) Water Purification System ............34 ©Sundance Spas, Inc. All Rights Reserved...
  • Page 4 11.0 Spa Maintenance .............36 11.1 Cleaning The Filter ............36 11.2 Draining And Refilling ............38 11.3 Pillow Care ................39 11.4 Cleaning The Spa Interior ..........40 11.5 Maintaining the Cover ............40 11.6 Maintaining The Synthetic Cabinet ........41 11.7 Winterizing ................41 11.8 Restarting Your Spa in Cold Weather .......43 11.9 Top Rail Care And Maintenance ........43 12.0...

  • Page 5: Important Spa Owner Information

    Select Series Important Spa Owner Information ® Your new Sundance Spa is constructed to the highest standards and is capable of providing many years of trouble-free use. However, because heat retentive materials are utilized to insulate the spa for efficient operation, an uncovered acrylic spa surface and wall fittings directly exposed to sunlight and high temperatures for an extended period are subject to permanent damage or discoloration.

  • Page 6: Important Safety Instructions For All Spa Owners

    Select Series Important Safety Instructions for all Spa Owners READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY! This spa was manufactured to meet the standards and specifications outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB Safety Act). When installing and using this spa, basic safety precautions should always be followed, including: DANGER: RISK OF SEVERE INJURY OR DROWNING!
  • Page 7 Select Series • A grounding wire connector is provided on this unit to connect a minimum No. 8 AWG (8.4 mm²) solid copper conductor between this unit and any metal equipment, metal enclosures of electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of the unit.
  • Page 8 Select Series WARNING: RISK OF SEVERE INJURY OR DEATH! • Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, if pregnant or possibly pregnant, consult your physician before using a spa. •...
  • Page 9 Select Series WARNING: In addition to maintenance of filters and water chemistry, proper ventilation is recommended to reduce the risk of contracting a waterborne illness (e.g. an infection, bacteria or virus) and/or respiratory ailments that could be present in the air or water. Consult a licensed architect or building contractor to determine your specific needs if installing your hot tub indoors.

  • Page 10: Entrapment Risk

    Select Series Entrapment Risk The Consumer Products Safety Commission/USA has reported that users of pools and spas have become entrapped (stuck) to drain and/or suction fittings causing death, drowning, or serious injury (see diagram below). This spa was manufactured to meet the standards and specifica- tions outlined in the “Virginia Graeme Baker Pool and Spa Safety Act”...

  • Page 11: Hyperthermia

    A Warning Sign is provided in your warranty packet. Please install at a location near your spa, where it is visible to users of the spa. For additional or replacement Warning Signs please contact your local Sundance spas dealer and reference item number #6530-082. Page 7...

  • Page 12: Important Additional Safety Instructions

    Sundance dealer or local building department should you have any questions regarding your installation. Proper grounding is extremely important. Sundance spas are equipped with a current collector system. A pressure wire connector is provided on the surface of the control box, located outside the equipment door...

  • Page 13: Choosing A Location

    Select Series Choosing A Location IMPORTANT: Because of the combined weight of the spa, water and users, it is extremely important that the base upon which the spa rests be smooth, flat, level and capable of uniformly supporting this weight, without shifting or settling, for the entire time the spa is in place.

  • Page 14: Indoor Location

    Select Series • The closeness to trees and shrubbery (remember that leaves and birds could create extra work in keeping the spa clean). • A sheltered environment (less wind and weather exposure can result in lowered operation and maintenance costs). •...

  • Page 15: Power Requirements

    Select Series • PROPER VENTILATION: Proper ventilation should be discussed with an Engineer or authority competent enough to understand the necessary provisions needed to vent moist or heated air and air associated with chemical odors outdoors. When the spa is in use considerable amounts of moisture will escape potentially causing mold and mildew, over time this can damage certain surfaces and or surroundings.

  • Page 16: Electrical Wiring Instructions

    Select Series Electrical Wiring Instructions IMPORTANT NOTICE: The electrical wiring of this spa must meet the requirements of the National Electrical Code (NEC) and/or any applicable state or local codes. The electrical circuit must be installed by a qualified electrician and approved by a local building/electrical inspection authority.
  • Page 17 Select Series Figure A Equipment Area Circulation pump Note: Equipment location (such as pumps, behind load box CLEARRAY® system, drain, heater etc.) varies by model. Control Box 1-Speed Pump Power Supply CLEARRAY® Water Entrance(s) Purification System 2-Speed Pump Control Panel Heater 10.

  • Page 18: Spa Fill Up Procedure

    Select Series For Heater Figure-C Figure-D (for a two breaker connection) BLUE to Circuit BLUE Green Board BROWN BROWN North American Models: to Circuit 240 VAC, 3-Wire Connection (60 Hz) Board Green for a two breaker connection BLUE BROWN BLUE BROWN to Circuit Green...
  • Page 19 Select Series CAUTION: TO DECREASE BUILD UP ON COMPONENTS AND MINIMIZE ACRYLIC DAMAGE. Never fill with water from a water softener. If your water is extremely “hard,” it is preferable to fill half-way with hard water and the rest of the way with softened water.
  • Page 20 Select Series 6. Establish A Stable Sanitizer Reading Establish a stable sanitizer reading no less than 1.0 ppm chlorine or 2.0 ppm bromine. To ensure healthy water conditions, always maintain a constant sanitizer reading within the levels recommended on the inside cover of this manual. If sanitizer levels cannot be stabilized, perform the decontamination procedure steps 9-15 on the following page.
  • Page 21 Select Series DANGER: RISK OF PERSONAL INJURY. Check water temperature carefully before entering hot tub! Excessive water temperature can cause burns, welts and body temperature to rise, hyperthermia (over-heating). Decontamination Procedure (Steps 9-15) Steps 9-15 below are only required when sanitizer levels are unstable after performing steps 1-6 above.Disregard steps 9-15 below if sanitizer levels remain stable at the levels recommended on the inside cover of this manual.
  • Page 22 Select Series WARNING: BECAUSE OF THE RISK OF INHALING CHEMICAL VAPORS. • To decrease the risk of injury, drowning or entrapment, never leave your hot tub unattended for any reason while the cover is open and accessible, especially to small children and animals! •...
  • Page 23 Select Series 15. Establish a sanitizer reading no less than 1.0 ppm free chlorine or 2.0 ppm bromine, then allow the hot tub to set undisturbed for 8 hours. Retest water after 8 hours to determine if sanitizer levels are stable. If sanitizer levels are stable, your spa is ready for use. To ensure healthy water conditions, always maintain a constant sanitizer reading within the levels recommended on the inside cover of this manual.

  • Page 24: Control Functions

    Select Series Control Functions Control Panel A. LED Display: Can display current water temperature (default display), water temperature set point, selected filtration/heating mode, and error messages. B. Heat Indicator: Lit when heater is on. C. Warmer ( ) Button: Increases water temperature set point. D.

  • Page 25: Victoria Spa Features

    Select Series Victoria Spa Features Control Panel 12. Vortex (3) Filter Lid & Filter Cartridge 13. Fluidix Intelli-Jets (4) Air Controls w/LED Light (3) 14. Accu-Pressure Jets (6) Pillows (3) 15. Fluidix ST Jets (7) Massage Selector 16. Optional Audio System Speakers, Gravity Drain/Ozone Return/ 6 each Heater Return Fitting...

  • Page 26: Victoria Air Controls Diagram

    Select Series Victoria Air Controls Diagram Air Control Operation Rotate Air Controls 1-3 to add air to designated jet groups. Spa features subject to change without notice. Page 22...

  • Page 27: Victoria Massage/Waterfall Selector Diagram

    Select Series Victoria Massage/Waterfall Selector Diagram Massage Selector Operation Rotate Massage Selector 1 to divert water between desig- nated jet groups. Massage Selectors (1) • Massage Selector #1 controls pump #1. Jets (2) • These jets are always on when the jets pump #2 is running. Waterfall (3) •...

  • Page 28: Constance® Spa Features

    Select Series Constance® Spa Features Control Panel 12. Fluidix Intelli-Jets (7) Filter Lid & Filter Cartridge 13. Accu-Pressure Jets (12) Air Controls w/LED Light (4) 14. Fluidix ST Jets (7) Pillows (4) 15. Optional Audio System Speakers, Massage Selector Gravity Drain/Ozone Return/ 16.

  • Page 29: Constance Air Controls Diagram

    Select Series Constance Air Controls Diagram Air Control Operation Rotate Air Controls 1-4 to add air to designated jet groups. Spa features subject to change without notice. Page 25...

  • Page 30: Constance Massage/Waterfall Selector Diagram

    Select Series Constance Massage/Waterfall Selector Diagram Massage Selector Operation Rotate Massage Selector 1 to divert water between desig- nated jet groups. Massage Selectors (1) • Massage Selector #1 controls pump #1. Jets (2) • These jets are always on when the jets pump #2 is running. Waterfall (3) •...

  • Page 31: Operating Instructions

    Select Series Operating Instructions The spa control system has automatic functions that operate upon startup and normal operation to protect the system. Upon power up, the readout displays the following information: 1. Control panel displays current software release. 2. Control panel displays “888” and all indicator LEDs are lit, permit- ting visual inspection of all display segments and indicator lights for proper operation.

  • Page 32: Activate Jets Pumps

    Select Series Activate Jets Pumps The JETS 1 button activates the functions of the main 2-speed jets pump. The first press activates pump 1 in low speed, the second press activates high speed, and the third press shuts the pump off. The JETS 2 button controls jets pump 2 which only operates in high speed.

  • Page 33: Multi-Colored Led Light Operation

    Select Series Multi-Colored LED Light Operation A. Pressing the LIGHT button activates the footwell, waterfall, and air control LED lights in sequence as follows: High - Medium - Low - Off. Anytime the light system has been manually activated, it will automatically turn off after approximately 2 hours.

  • Page 34: Adjusting Fluidix Nex, Intelli-Jets, Reflex And St Jets

    Select Series Adjusting Fluidix Nex, Intelli-Jets, Reflex and ST Jets The jets in your new hot tub offer the advantage of no moving parts and zero maintenance. They can also be adjusted for a high and low impact massage, providing the ultimate Fluidix Intelli-Jet massage! To adjust the jets: 1.

  • Page 35: 10.0 Automatic Filtration Cycles

    Select Series 10.0 Automatic Filtration Cycles Your new spa includes a circulation pump that filters the water continuously for 8 hours (default setting). The circulation pump draws water through the short side of the double-ended filter cartridge and effectively removes small debris in your spa. Note: The 8-hour circulation pump system also supplies heated water to the spa when the heater turns on.
  • Page 36 Select Series Standard Filtration/Heating Modes F0 No filtration (a one minute “blow-out” cycle every 24 hours to purge all plumbing lines) F1 1 hour of filtration per day (one 30-minute cycle every 12 hours); this is the factory default setting. F2 1.5 hours of filtration per day (one 30-minute cycle every 8 hours) F3 2 hours of filtration per day (one 30-minute cycle every 6 hours)

  • Page 37: Programming The Circulation Pump Filtration Cycle

    Select Series 10.5 Programming the Circulation Pump Filtration Cycle Press and hold the Jets pump 1 ( ) and Cooler ( ) button at the same time for 3 seconds to access the circulation pump programming. Continually press the Warmer ( ) button to scroll up through the cycles below.

  • Page 38: Programming The Clearray® (Ultraviolet) Water Purification System

    Select Series 10.6 Programming the CLEARRAY® (Ultraviolet) Water Purification System A. Programming the CLEARRAY System (U) or Corona Discharge Ozone (O3) Press and hold the Jets pump 1 ( ) and Cooler ( ) button at the same time for 3 seconds. Scroll pass the circulation pump programming menus by pressing the Warmer button, Figure 1.
  • Page 39 Select Series B. Resetting the duration countdown timer (CLEARRAY System only) Once the duration countdown timer for the CLEARRAY System has reached zero, you will need to reset it, replace the UV bulb and clean the quartz tube. To reset the duration countdown timer: Press Press Press...

  • Page 40: 11.0 Spa Maintenance

    Select Series 11.0 Spa Maintenance Proper and regular maintenance of your spa will help it retain its beauty and performance. Your authorized Sundance dealer can supply you with all the information, supplies and accessory products you will need to accomplish this. DANGER: RISK OF SEVERE INJURY OR DROWNING BY ENTRAPMENT!
  • Page 41 Select Series DANGER: TURN POWER TO SPA OFF! TO DECREASE RISK OF DEATH, DROWNING, OR ENTRAPMENT, NEVER OPERATE SPA WHEN FILTER IS NOT PROPERLY INSTALLED OR IF SKIMMER ASSEMBLY IS DAMAGED OR ALTERED! Refer to the filter cleaning/replacement procedure: TURN POWER TO HOT TUB OFF! Replace! Filter DO NOT...

  • Page 42: Draining And Refilling

    Select Series Periodically, the polyester mesh (pleated) filter will need a more thorough cleaning to remove imbedded oils and minerals. For this, we suggest cleaning as illustrated above (step D), followed by soaking the filter overnight in a plastic container filled with a solution of water and a specially formulated filter cleanser available from your Sundance dealer.

  • Page 43: Draining Procedures

    Select Series Draining Procedures: Figure G 1. Turn off power to spa at breaker. 2. Locate the 3" gray drain valve cap on side of the spa cabinet. Unscrew drain valve cap to expose the underlying male garden hose fitting (Fig. G-I). 3.

  • Page 44: Cleaning The Spa Interior

    Select Series 11.4 Cleaning The Spa Interior To preserve the sheen of your spa's surface, it is crucial that you avoid using abrasive cleaners or cleaners which have adverse chemical effect on the surface. If you are not certain as to the suitability of a particular cleanser, consult your authorized Sundance dealer.

  • Page 45: Maintaining The Synthetic Cabinet

    6. Use only recommended cover lift systems. 7. Use only chemicals and cleaners recommended by Sundance Spas. 8. Remember to keep spa covered when not in use. Maintaining proper water levels assures efficient operation and efficient electrical usage.
  • Page 46 Select Series Expert winterization of your spa is highly recommended, contact your authorized Sundance dealer. In emergency situations, damage can be minimized by taking the following steps: CAUTION: TURN OFF POWER TO HOT TUB! 1. Follow the directions on pages 38-39 for draining the spa. 2.

  • Page 47: Restarting Your Spa In Cold Weather

    Procrastination in regard to water maintenance will result in poor and potentially unhealthful conditions for soaking and even damage to your hot tub investment. For specific guidance on maintaining water quality, consult your Authorized Sundance Spas dealer who can recommend appropriate chemical products for sanitizing and maintaining your hot tub.

  • Page 48: Ph Control

    Select Series 12.1 pH Control pH is a measure of relative acidity or alkalinity of water and is measured on a scale of 0 to 14. The midpoint of 7 is said to be neutral, above which is alkaline and below which is acidic. In spa water, it is very important to maintain a slightly alkaline condition of 7.4 to 7.6 pH.

  • Page 49: Clearray® Water Purification System

    Select Series 12.3 CLEARRAY® Water Purification System DANGER! TURN POWER OFF! DO NOT LOOK AT LIT BULB. Your new hot tub has our water purification system SEVERE EYE DAMAGE OR BLINDNESS CAN OCCUR! factory installed that will begin disinfecting your water Power Lamp instantly.

  • Page 50: Clearray® Bulb Replacement And Quartz Tube Maintenance

    Select Series 12.4 CLEARRAY® Bulb Replacement and Quartz Tube Maintenance Important: It is MANDATORY that the UV bulb is replaced and the quartz tube be cleaned every 12 months to maintain optimum performance. Figure 1 #3 shown as reference only. It is attached to the #10 metal plate.
  • Page 51 Select Series Figure 3 Figure 4 Figure 5 Figure 6 3. Disconnect UV bulb socket (6) from the power cord socket (4), Figure 3. 4. Slowly remove the UV bulb (7) out of the quartz tube, Figure 4. 5. Remove the quartz seal compression nut (9) by turning it counterclockwise, Figure 5.

  • Page 52: 13.0 Error Conditions/Error Messages

    Select Series 14. Reconnect the UV bulb socket (6) to the power cord socket (4) make sure you use the latex glove provided when handling the UV bulb. WARNING: DO NOT TOUCH THE NEW UV BULB WITH YOUR BARE HAND. Oil on your skin will cause hot spot on the UV bulb and shorten the life of your UV bulb.

  • Page 53: Overheat Condition

    Select Series 13.2 Overheat Condition WARNING: RISK OF HYPERTHERMIA (OVER-HEATING) CAUSING SEVERE INJURY, BURNS, OR WELTS. DO NOT ENTER SPA WATER! Water is too hot. Overheat protection. Heater is deactivated. Spa water temperature is above acceptable limits. When the actual water temperature is approximately 2°F (1°C) above the set temperature, the circulation pump will stop operating to reduce (frictional) heating.

  • Page 54: Panel Displays Col

    “blb” and the water temperature. The countdown timer for the UV bulb needs to be reset (Section 10.6, page 35). A new UV bulb can be purchased from a local Sundance Spas dealer. 14.0 Troubleshooting Procedures In the event your Sundance spa is not working the way it should, please first review all the installation and operating instructions in this manual and check the message on the panel display.

  • Page 55: Pump Does Not Operate But Light Does

    Select Series 14.2 Pump Does Not Operate but Light Does Press the JETS 1 Button: 1. If no water movement is detected, make sure power is going to the spa and check the water level. If it does not solve the problem, contact your authorized Sundance dealer.

  • Page 56: 15.0 North American Circuit Diagram

    Select Series 15.0 North American Circuit Diagram This wiring diagram is used for all North American 240 VAC (60 Hz) dedicated power models. Page 52...

  • Page 57: 16.0 Export Circuit Diagram

    Select Series 16.0 Export Circuit Diagram This wiring diagram is used for Export 230 VAC (50 Hz) dedicated power models. Page 53...

  • Page 58: 17.0 Optional Bluewave® Spa Stereo System

    Select Series 17.0 Optional BLUEWAVE® Spa Stereo System To start enjoying your new stereo receiver, please read the following operation instructions in their entirety. 30-pin 3.5 mm cable Connector USB connector 1. Media Locker Handle Slide the handle to lock and unlock the protective door. 2.

  • Page 59: Pairing The Remote And Stereo

    Select Series WARNING: RISK OF ELECTRICAL SHOCK HAZARD EXISTS AND EQUIPMENT DAMAGE! Never install or remove electrical devices (e.g. Apple Device/MP3/USB/AUX/ Bluetooth) while hands are wet or while sitting partially or fully immersed in the spa! CAUTION: Never leave electrical devices in the Media Locker when spa is not is use to prevent damage from outdoor elements! Never spray Media Locker with a pressurized water hose for any reason! Damage to the...
  • Page 60 Select Series 2. Treble Setting: Press the Audio button 2 times to access the treble setting. The LCD display will change to “TRE 0,” Figure E Figure E. Press the Up button to adjust the setting to a maximum of +5. Press the Down button to adjust the setting down to Note: The default setting is “0.”...

  • Page 61: Standard Wireless Remote Control Functions

    Select Series 9. Stereo Setting: Press the Audio button 9 times to access the Stereo setting. The LCD display will change to Figure M “STEREO,” Figure M. Press the Up button to select either Stereo or Mono. 17.3 Standard Wireless Remote Control Functions A wireless radio frequency (RF) remote control is supplied on all spas with the optional audio system.

  • Page 62: Electronic Device Connections And Functions

    Select Series Press the button to change music Preset 3: Press to access a preset folders. station. DIR + Press to play songs in a random Not used order. RANDOM 17.4 Electronic Device Connections and Functions IMPORTANT REMOTE NOTICE: • If stereo unit is “ON”...
  • Page 63 Select Series ACCESSORY CONNECTED Figure D Figure C Figure B Figure E (device purchased purchased separately) separately) CAUTION RISK OF ELECTRICAL SHOCK OR EQUIPMENT DAMAGE! Never install, remove or operate any electrical device (e.g. Apple Device/MP3/USB/AUX/Bluetooth) while hands are wet or while sitting partially or fully immersed in the spa! Note: The DRM (Digital Rights Management) Files cannot be played on this deck.

  • Page 64: Wireless Remote Battery Replacement Procedure

    Select Series E. Connecting Your Auxiliary Player Using the 3.5 mm Cable: 1. Plug one end of the cable to “Aux” connection on the stereo, Figure F. 2. Plug the other end of the cable into the head phone jack connection on the Apple device/MP3 Player. 3.

  • Page 65: Bluewave® Spa Stereo System Specifications

    Select Series 3. Remove battery door by lifting the door upward (Figure C). OPEN CLOSED Fig. C OPEN CLOSED 4. Replace battery using an equivalent (Figure D). Fig. D OPEN CLOSED 5. Reinstall the battery cover, using the coin rotate the door to the Close position (Figure E).

  • Page 66: Stereo Cautions

    Select Series 17.7 Stereo Cautions DANGER RISK OF SHOCK OR “CAUTION - Risk of Electric Shock. Do not ELECTROCUTION! leave compartment door open.” “CAUTION - Risk of Electric Shock. Replace components only with identical components.” 3. “Do not operate the audio/video controls while inside in the spa.”...
