Summary of Contents for Chauvet Professional Maverick Silens 1X Profile

  • Page 1 User Manual Model ID: MAVERICKSILENS1XPROFILE...

  • Page 2: Edition Notes

    Edition Notes The Maverick Silens 1X Profile User Manual includes a description, safety precautions, installation, programming, operation and maintenance instructions for the Maverick Silens 1X Profile as of the release date of this edition. Trademarks Chauvet, Chauvet Professional, the Chauvet logo, Maverick, and Maverick Silens are registered trademarks or trademarks of Chauvet &...

  • Page 3: Table Of Contents

    Gobo Designs ....................Gobo Replacement ..................Procedure......................14 Gobo Replacement Diagrams ................14 4. Operation..................... Touchscreen Control Panel................Control Panel Description .................. 15 Battery Powered Display ..................15 Home Screen ....................Control Panel Lock..................Maverick Silens 1X Profile User Manual Rev. 2...
  • Page 4 Manual Test ....................... 27 System Information ..................Zero Adjust Mode..................Web Server ....................Error Codes....................5. Maintenance..................Product Maintenance ..................Gobo Maintenance..................Transporting on Truss or Racks..............6. Technical Specifications..............Contact Us....................Warranty & Returns..................Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 5: Before You Begin

    The product has XLR sockets for DMX input and output. • Notice: This control circuit is isolated and belongs to the Class 2 data port. • The control circuit has a cumulative leakage current of less than 3.5 mA. Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 6: Safety Notes

    • In the event of a serious operating problem, stop using immediately. If a Chauvet product requires service, contact Chauvet Technical Support. Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 7: Fcc Statement Of Compliance

    LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is 40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit the overall intensity. Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 8: Introduction

    2. Introduction Description The Maverick Silens 1X Profile is a compact member of the award-winning Silens series. A 430W 96+ CRI LED offers the highest quality of light, flawless 16-bit dimming, selectable red shift, dimming curves, and accurate color rendering. Completely fan-less operation makes this totally silent fixture ideal for the most demanding theatre and studio applications.

  • Page 9: Product Dimensions

    17.83 in 453 mm 25.2 in 640 mm 18.41 in 467.5 mm 4.08 in 103.7 mm 14.72 in 9.69 in 374 mm 246 mm 5.51 in 140 mm 5.51 in 140 mm Maverick Silens 1X Profile User Manual Rev. 2...
  • Page 10 Introduction 17.56 in 445.99 mm 25.02 in 635.48 mm 17.83 in 453 mm 20.9 in 530.98 mm Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 11: Setup

    4. Screw the fuse holder cap back in place and reconnect power. Power Linking It is possible to power link Maverick Silens 1X Profile products. See the table below for the current draw at each voltage and frequency: 100 V, 60 Hz...

  • Page 12: Dmx Linking

    Setup DMX Linking The Maverick Silens 1X Profile can link to a DMX controller using a 5-pin DMX connection or a CRMX connection. For more information about DMX, read the DMX primer at: https://www.chauvetprofessional.com/wp-content/uploads/2016/06/DMX_Primer.pdf. Remote Device Management Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate bi-directionally along existing DMX cabling.

  • Page 13: Lumenradio Crmx™ Connection

    4. Select CRMX. (The Signal Strength Indicator will show a ? in front of the bars) 5. Press the reset button on the CRMX™ transmitter. (The Signal Strength Indicator on the Maverick Silens 1X Profile will show a ϟ in front of the bars for 3 seconds while a connection is established.) Product Pairing If the Maverick Silens 1X Profile has already been paired with the CRMX™...

  • Page 14: Usb Software Update

    1. Power on the products. 2. Connect the DMX out of the Maverick Silens 1X Profile with the latest software to the DMX in of the Maverick Silens 1X Profile that needs to be updated. 3. Go to the USB Upgrade main level of the receiving product.

  • Page 15: Mounting

    When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity. Procedure The Maverick Silens 1X Profile comes with 2 Omega brackets to which the user can directly attach mounting clamps (sold separately). Make sure the clamps are capable of supporting the weight of this product.

  • Page 16: Color Wheel

    Setup Color Wheel Rotating Gobo Dimensions 22.9 mm 15.5 mm IMAGE Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 17: Gobo Designs

    Setup Gobo Designs Barking Up a Flaming River Shower Glass (Glass) (Textured glass) Window Pane Floyd (Metal or glass) (Glass) Super Max Sparse Branches (Metal or glass) (Glass) Something Linear (Glass) Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 18: Gobo Replacement

    This provides a layer of protection against the high temperature from the lamp. • All custom gobos in the Maverick Silens 1X Profile gobo wheel 1 must be aluminum or glass. Procedure Follow the recommended procedure below to remove or replace the gobos: 1.

  • Page 19: Operation

    4. Operation Touchscreen Control Panel The Maverick Silens 1X Profile has a touchscreen display as well as 6 control buttons. Navigate the menu structure by pressing the buttons, touching the images of the buttons on the sides of the display, or touching the desired menu option on the display directly.

  • Page 20: Menu Map

    Operation Menu Map Refer to the Maverick Silens 1X Profile product page on www.chauvetprofessional.com for the latest menu map and software. Main Level Programming Levels Description Address 001–512 Sets the starting address Manual Manually set IP address IP Mode DHCP...
  • Page 21 _ _ _ _ _.CHL Selects an update file for this and other Multiple USB Upgrade Fixture Maverick Silens 1X Profile products _ _ _ _ _.CHL Selects an update file for other Other Fixture Type connected products Maverick Silens 1X Profile User Manual Rev. 2...
  • Page 22 24.Shutter 1- 2 25.Shutter 2- 1 26.Shutter 2- 2 27.Shutter 3- 1 28.Shutter 3- 2 29.Shutter 4- 1 30.Shutter 4- 2 31.Focus 32.Focus Fine 33.Zoom 34.Zoom Fine 35.Prism 36.Prism Rot 37.Iris 38.Frost 39.Control Maverick Silens 1X Profile User Manual Rev. 2...
  • Page 23 21.Animation Rotate 22.Shutters Rot 23.Shutter 1- 1 24.Shutter 1- 2 25.Shutter 2- 1 26.Shutter 2- 2 27.Shutter 3- 1 28.Shutter 3- 2 29.Shutter 4- 1 30.Shutter 4- 2 31.Focus 32.Focus Fine 33.Zoom Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 24: Control Configuration

    Use control configurations to operate the product with a DMX, Art-Net™, or sACN controller. Control Mode The Maverick Silens 1X Profile works with wired DMX, WDMX, Art-Net™, and sACN control signals. To select which protocol to use: 1. Go to the Settings main level.

  • Page 25: Subnet Mask

    Wheel) 028  031 UV 032  187 Color wheel indexing 188  219 Color scroll, fast to slow 220  223 Stop 224  255 Reverse color scroll, slow to fast Maverick Silens 1X Profile User Manual Rev. 2...
  • Page 26 Fine focus 000  255 Fine control (16-bit) Zoom 000  255 0–100% – Fine Zoom 000  255 Fine control (16-bit) 000  127 No function Prism 128  255 Prism insert Maverick Silens 1X Profile User Manual Rev. 2...
  • Page 27 064  071 Disable absolute silence 072  079 Enable absolute silence 080  087 Disable steady mode 088  095 Steady mode 1 096  103 Steady mode 2 104  255 Reserved for future use Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 28: Settings Configuration

    2. Select from the BL. O. P/T Move (black out on pan/tilt movement), BL. O. ColorMove (black out on color wheel movement), or BL. O. GoboMove (black out on gobo wheel movement) options. 3. Select from No or Yes. Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 29: Touchscreen Calibration

    Pulse Width Modulation To adjust the frequency of the pulse width modulation: 1. Go to the Settings main level. 2. Select the LED Frequency option. 3. Select the frequency, from 20000Hz or 40000Hz. Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 30: Preset Selection

    1. Connect the Maverick Silens 1X Profile products to receive the Presets by a DMX daisy chain. 2. Make the Maverick Silens 1X Profile with the Presets to transfer the first in the DMX daisy chain. 3. Power on all of the products.

  • Page 31: Test Mode

    Operation Test Mode Auto Test To have the Maverick Silens 1X Profile automatically test all functions one after the other: 1. Go to the Test main level. 2. Select the Auto Test option. Manual Test To manually test an individual function of the Maverick Silens 1X Profile: 1.

  • Page 32: Web Server

    Operation Web Server The Maverick Silens 1X Profile Web Server can be accessed by any computer on the same network as the product. It allows network access to system information, settings such as control setup, manual testing of all functions, firmware updates, and the ability to change the Web Server password.

  • Page 33: Error Codes

    Check the magnetic rod upside down Sensor board is damaged Replace the GOBO sensor board The magnetic rod of GOBO sensor RGobo Reset Fail board is dropped or installed Check the magnetic rod upside down Maverick Silens 1X Profile User Manual Rev. 2...
  • Page 34 Check if there is anything in the way USB has poor connection Replug the USB USB internal wires have poor No such file! Change the USB connection No upgrade file in the USB Check the files in the USB Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 35: Maintenance

    (needle tip applier recommended). Make sure the gobo holder is rotating freely and is not making any abnormal noise. 8. Reinstall the gobos in the gobo holder. Make sure the gobos are in the correct positions. 9. Reinstall the gobo holder in the unit. Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 36: Transporting On Truss Or Racks

    This is to prevent undue stress on the tilt locks and limit the amount of off-axis bounce on internal components. Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 37: Technical Specifications

    5-pin IXLR Amphenol XLR Net RJ45 31 or 39 Ordering Product Name Item Name Item Code UPC Number Maverick Silens 1X Profile MAVERICKSILENS1XPROFILE 03011747 781462220952 UL 1573 CSA C22.2 No. 166 E113093 Maverick Silens 1X Profile User Manual Rev. 2...

  • Page 38: Contact Us

    For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. Maverick Silens 1X Profile User Manual Rev. 2...
