1
借(通)用件登记
旧底图总号
A
底图总号
更改单
版本
编号
出图审查 设计 廖伟文
标准
批准
产 品
名称:
产 品
型号:
文 件
名称:
文 件
编号:
编 制
日期:
签字
审核
冷藏箱
BC-319WY3NF1A/HC4(E)
BC-319WY3NF1/HC4(E)
售后服务技术资料
BSSJ00005060
2022 年 5 月 6 日
日期
重 量
共 张
重 要 度
家电开发
中心
售后服务
比例
技术资料
第 张
BSSJ000050
60

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RL-42W42S/W8-001-001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hisense RL-42W42S/W8-001-001

  • Page 1 重 要 度 产 品 名称: 冷藏箱 产 品 BC-319WY3NF1A/HC4(E) 型号: BC-319WY3NF1/HC4(E) 文 件 售后服务技术资料 名称: 文 件 BSSJ00005060 编号: 编 制 2022 年 5 月 6 日 日期: 借(通)用件登记 家电开发 旧底图总号 中心 底图总号 更改单 售后服务 版本 日期 重 量 比例...
  • Page 2 Refrigerator Service Manual Model: RL-42W42S/W8-001-001 RL-42W41S/C2V-001-001...
  • Page 3: Table Of Contents

    Contents 1.Warnings and precautions for safety ........1 2.Appearance and structure ............2 2.1 View of the appliance ............2 2.2 Wind channel structure ............3 2.3 Fridge evaporator structure ..........4 2.4 Compressor room structure ..........5 3.Basic parameters ..............6 4.Operation and functions ............
  • Page 5: Warnings And Precautions For Safety

    1. Warning and precautions for safety Please observe the following safety precautions in order to use safely and correctly the refrigerator and to prevent accident and danger during repair. 1. Be care of an electric shock. Disconnect power cord from wall outlet and wait for more than three minutes before replacing PCB parts.
  • Page 6: Appearance And Structure

    2. Appearance and structure 2.1 View of the appliance BC-319WY3NF1A/HC4(E) RL-42W42S/W8-001-001 View of the appliance 1. Cabinet 2. LED light 3. Glass shelves 4. Bottle rack(optional) 5. Display 6. Small glass shelf 7. 0°C cool plus 8. Crisper box 9. Adjustable bottom feet 10.
  • Page 7: Wind Channel Structure

    2.2 Wind channel structure...
  • Page 8: Fridge Evaporator Structure

    2.3 Fridge evaporator structure 1. Temperature sensor part 2. Wing slice evaporator part...
  • Page 9: Compressor Room Structure

    2.4 Compressor room structure 1.Junction box 2.Dry filter 3. Power line 4.Compressor 5. Up evaporating dish part 6. Lower evaporating dish part...
  • Page 10: Basic Parameters

    3. Basic parameters BC-319WY3NF1A/HC4(E) RL-42W42S/W8-001-001 Content Unit Value Voltage/frequency 220-240V / 50Hz Storage volume (fridge) Energy efficiency class (V NEW Energy 2020) Climate class SN/N/ST/T Energy consumption / year kWh/year Energy consumption (EN153) per 24 h kWh/24 h 0.375 Kind of coolant /Charge ( 134 /R600a) / grammes...
  • Page 11: Operation And Functions

    4. Operation and functions 4.1 Display controls Use your appliance according to the Controlling the temperature following control regulations, your appliance For optimum food preservation, has the corresponding functions and modes We recommend that when you start your as the control panels showed in the pictures refrigerator for the first time,the below.
  • Page 12 2. Super Cool light is off. the fridge is in the unlocked Super Cool can state. it can perform other button operation. refrigerate your food much faster, keeping If no button have been press for 20 ● food fresh for longer period. seconds, the light will be on.
  • Page 13 fridge during this time. refrigerator will turn on and the display will ●When the refrigerator is in standby mode shows normal. Note: The display control only can be setted in the unlocked state and unlocked, press the button for 3 seconds, the light is off, the...
  • Page 14: Reversing The Door

    4.2 Reversing the door The side in which the door opens can be hinge cover(right)as follow diagram. changed from the right side (as supplied) to the left side, if the installation site allows for it. Tools you will need: 3. Remove the three screws as follow diagram.
  • Page 15 the screws ④. Screw cover ① Adjustable bottom feet part ② Support block for door frame Right lower hinge part ① ③ Self-tapping screw Special flange self-tapping screw ② ④ Door stopper ③ 7. Replace part ③ to the left side and Limit block ④...
  • Page 16 8. Set the door into its new place making sure the pin enters the bushing at the lower frame section. 9. Replace the lid by fitting the upper hinge core into the upper door's hole, securing it with the 3 screws. Handle cover ①...
  • Page 17 Handle part ③ Cover-screw cap ④ Warning! When changing the side at which the door opens, the appliance must not be connected to the mains. Remove plug from the mains beforehand. Screw cover ① Screw ②...
  • Page 18: Error Code

    4.3 Error Code Code Problem Analysis Solutions 1. The Environmental Tem. 1. Using a Multimeter with the ohm switch to Sensor is open circuit or short measure the resistor of sensor or checking the circuit. connect ing is well or not. Refrigerator 2.
  • Page 19: Troubleshooting

    5.Trouble shooting 5.1 Common problem and checking If you experience a problem with your appliance or are concerned that the appliance is not functioning correctly, you can carry out some easy checks before calling for service, please see below. Warning! Don’t try to repair the appliance yourself. If the problem persists after you have made the checks mentioned below, contact a qualified electrician, authorized service engineer or the shop where you purchased the product.
  • Page 20 Temperature inside is too Increase the temperature by following the “Display controls” cold chapter. Check whether the top of the refrigerator is tilted back by Doors can’t be closed 10-15mm to allow the doors to self close, or if something inside is easily preventing the doors from closing.
  • Page 21: Faulty Start

    5.2 Faulty start...
  • Page 22: Refrigeration Failure

    5.3 Refrigeration failure 5.3.1 Fridge compartment...
  • Page 23 5.3.1 Fridge compartment...
  • Page 24 5.3.2 Refrigerator compartment...
  • Page 25: Thick Frost In Freezer Compartment

    5.4 Thick frost in refrigerator compartment...
  • Page 26: Dew In Refrigerator Compartment

    5.5 Dew in refrigerator compartment...
  • Page 27: Breaking Of Light

    5.6 Breaking of light...
  • Page 28: Noise

    5.7 Noise 5.7.1 Compressor noise...
  • Page 29 5.7.2 Refrigerator flowing noise...
  • Page 30 5.7.3 Fan motor noise...
  • Page 31 5.7.4 Pipe noise...
  • Page 32: Circuit And Checking

    6. Circuit and checking 6.1 Circuit diagram 6.2 Main control board 6.2.1 Checking method If the problem is probably caused by main control board, change it directly to confirm. 6.2.2 Removing the main control board 1. Unplug the appliance. 2. Remove the screw by screwdriver and remove the electric box, as picture 1 3.
  • Page 33 Picture1 Picture2 Picture3 Picture4 6.3 Compressor 6.3.1 Basic parameters Input voltage:220~240V Input frequency:50Hz 6.3.2 Checking method 1.Compressor will start 10 seconds after power-on, if it starts unsuccessfully, remove the electric box cover and check. 2.Check the connecting wiring between compressor and main control board and repair if it is broken.
  • Page 35 6.3.3 Removing the PTC starter and overload protector 6.3.3.1 Circuit and checking 1.Unplug the appliance 2.Remove the screws of protector box by screwdriver,as picture 1. 3.Pry up the protector box from top by screwdriver,as picture 2. 4.Unplug the overload protector,as picture 3. 5.Unplug the PTC starter,as picture 4.
  • Page 36: Compressor

    6.4 Fan motor 6.4.1 Basic parameters 6.4.1.1 Refrigerator Fan motor (R. Fan motor) Rated voltage: DC12V Rated input power: <2.51W 6.4.2 Checking method [ Refrigerator Fan motor (R. Fan motor)] 1.Check the connecting wiring of fan motor is well or not, repair if it is broken.
  • Page 37: Light

    Picture7 Picture8 Picture9 6.5 Light 6.5.1 Basic parameters Rated voltage:DC12V Rated power:1.5 W 6.5.2 Checking method 1.Check the connecting wiring between light and main control board is well or not, repair if it is broken. Refrigerator light corresponding pin No.5 and No.6 on XP2 connector of mainboard.
  • Page 38: Display Panel

    Picture3 Picture4 6.6 Display panel 6.6.1 Basic parameters Input voltage:5V 6.6.2 Checking method 1.Display panel will lighten as soon as power-on, if it light unsuccessful, remove the display panel box cover and check. 2.Check the connecting wiring between display panel and main control board and repair if it is broken.
  • Page 39: Sensor

    6.7 Sensor Measuring the sensor resistance Use a multimeter with the ohm switch to measure the resistor of sensor. You'd better measure the following temperature resistance is more accurate, and more likely to get the temperature. Normally at surrounding -18 ℃ ,5 ℃ ,25 ℃ , the corresponding resistance is about 17kohm,5kohm,2kohm.
  • Page 40: Removing Environment Temperature Sensor Unit

    6.9 Removing environment temperature sensor unit 1. Unplug the appliance. 2. Using a screwdriver to pry the right upper hinge cover, as picture 1. 3. Take out the environment temperature sensor unit, as picture 2. Picture1 Picture2...
  • Page 41: Cooling System Repairing

    7. Cooling system repairing 7.1 Refrigeration system Compressor discharges high temperature high pressure R600a gas refrigerant Refrigerant enters anti-condensation pipe , condenser, then becomes middle temperature high pressure liquid after condensation Refrigerant enters dry filter,water and imperity will be filtrated Refrigerant enters Electromagnetism valve, and Capillary, then pressure will be reduced Refrigearnt enters finned evaporator and...
  • Page 42: Summary Of Repair

    7.2 Summary of repair...
  • Page 43: Regulation Of Repair

    7.3 Regulation of repair...
  • Page 44: Practical Work Of Repair

    7.4 Practical work of repair...
  • Page 45 7.4 Practical work of repair...
  • Page 46: Brazing Reference Drawing

    7.5 Brazing reference drawing...
