Exibel BAX90 Manual

Wireless over-ear
headphones with ANC
Art.no 39-3343-1/-2 Model BAX90 / H655BT
Please read the entire instruction manual before using the
product and then save it for future reference. We reserve the
right for any errors in text or images and any necessary changes
made to technical data. In the event of technical problems or
other queries, please contact our Customer Services.
Safety
• Protect your hearing. Listening on high
volume for prolonged periods can lead to
permanent hearing loss. Set the volume to a
low level before using the product.
• Be careful when using the product if it poses
a possible danger to yourself or others
due to your inability to clearly hear your
surroundings.
• Never subject the product to high temperature,
dust, heavy vibration, or impacts.
• Keep the product away from water or other
liquids.
• Do not place the product in continuous
sunlight or near naked flames.
• Never attempt to tamper with or modify the
product in anyway.
• Never let the battery charge for extended
periods when it is not inuse. Discontinue
charging during thunderstorms.
• Turn off both the product and mobile phone
in areas where you are requested to do so,
such as in hospitals, aircraft or areas where
there is a risk of explosion.
English
Buttons and functions
1. [ + ] Press to raise
the volume, hold
in to change to the
next track
2. [ ] Press to start
and pause music
playback. Press to
answer or end a
call. Press 2 times
to use Siri/Google
assistant. Hold to
reject an incoming
call. Hold to turn the
headphones on/off.
3. [ - ] Press to lower
the volume, hold
in to change to the
previous track.
4. [ ANC ] Press to
switch between
normal mode, ambient sound or active noise cancellation
5. LED indicator
6. [DC 5V] USB-C port for the included charging cable
7. AUX - 3.5 mm input
8. Microphone
Charging
Charge the battery for 1.5 hours before using the headphones
for the first time.
Min. 1 A
1. Connect the included charging cable to the USB-C port and
to a USB-charger or computer.
2. The LED indicator (5) shines red when charging is in progress.
3. The LED indicator will shine blue when the battery is fully
charged.
Operating instructions
On/off button
On − use with a previously paired external device
Hold [ ] for approximately 3 seconds.
1
2
Off
3
Hold [ ] for approximately 5 seconds.
4
5
6
7
On − to use the headphones with a new external device
8
Follow the instructions in the Bluetooth connection section.
Bluetooth-anslutning
3 s
1. Switch the headphones on by holding [
The LED indicator (5) starts flashing blue and red. The
1.5 h
headphones are now detectable for other Bluetooth devices.
2. Activate Bluetooth on the device to be paired and begin
scanning. When the headphones has been found by the
Bluetooth device it will appear as exibel BAX90.
3. Select the headphones from the list. Once a connection has
been established the LED indicator will shine with a fixed
blue light.
4. Start playback on your device. Adjust the volume and control
playback from the Bluetooth device or directly on the
headphones.
3 s
5 s
Bluetooth
Devices
exibel BAX90
] for 3 seconds.
