Sensafe Chlorine + eXact Z Quick Start Manual

Digital water testing
Hide thumbs

Advertisement

Table of Contents

Chlorine +
ADVANCED PHOTOMETER SYSTEM
DIGIT AL ACCURACY FOR RELIABLE WA TER CARE
Certified to
NSF/ANSI Standard 50
編譯:莆崧實業(股)
WATER TESTING
DIGITAL
QUICK START GUIDE
Part no. 486205
可
攜
式
水
質
儀

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chlorine + eXact Z and is the answer not in the manual?

Questions and answers

Related Manuals for Sensafe Chlorine + eXact Z

Summary of Contents for Sensafe Chlorine + eXact Z

  • Page 1 Chlorine + ADVANCED PHOTOMETER SYSTEM DIGIT AL ACCURACY FOR RELIABLE WA TER CARE Part no. 486205 可 攜 式 水 質 儀 Certified to NSF/ANSI Standard 50 編譯:莆崧實業(股) DIGITAL WATER TESTING QUICK START GUIDE...

  • Page 2: What You Will Need To Get Started

    目 錄 CONTENTS Welcome..........總覽...
  • Page 3 4. 緊閉基座電池蓋。Replace the base firmly with pressure while tightening the screw. The meter will turn on 電池蓋鎖孔 SCREW automatically. 5. 拴緊螺絲。Tighten the screw with #4 Phillips head Unscrew to remove base screwdriver. Be sure not to over tighten. 編譯:莆崧實業(股) Sensafe.com...
  • Page 4 填入樣品、置入試紙、定量 FILL, DIP, READ TOTAL BROMINE 總溴 486644 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 ® Press the button to power on the Chlorine+ eXact 沖洗取樣槽 FILL CELL 測試前以清水沖洗，再以待測試的樣品(水)沖洗 取樣槽3次(填滿倒空)。最後再以待測樣品(水) 填滿取樣槽。 Before testing, rinse CELL and clean with brush thoroughly. Finally rinse the cell 3 times with the water sample to be tested, then FILL cell to capacity to begin test.
  • Page 5 Place the Cell Cover onto the CELL and READ result displayed as Total Bromine. This result is automatically stored in the bR menu. After testing is complete, rinse the sample cell immediately and clean with brush to remove reagents which coat the CELL wall. 編譯:莆崧實業(股) Sensafe.com...
  • Page 6 填入樣品、置入試紙、定量 FILL, DIP, READ CHLORINE DIOXIDE 二氧化氯 486633 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 Press the button to power on the Chlorine+ eXact ® 沖洗取樣槽 FILL CELL 測試前以淨水沖洗，並以待測試的樣品水沖洗取 樣槽3次(填滿倒空)。最後再以待測樣品水填滿 取樣槽。 Before testing, rinse CELL and clean with brush thoroughly. Finally rinse the cell 3 times with the water sample to be tested, then FILL cell to capacity to begin test.
  • Page 7 Place the Cell Cover onto the CELL and READ result displayed as Chlorine Dioxide. Thisresult is automatically stored in the Cd menu. After testing complete, rinse the sample cell immediately clean with brush to remove reagents which coat CELL wall. 編譯:莆崧實業(股) Sensafe.com...
  • Page 8 填入樣品、置入試紙、定量 FILL, DIP, READ FREE CHLORIDE 自由餘氯 486637 (範圍0.00-12.0 ppm) 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 Press the button to power on the Chlorine+ eXact ® 沖洗取樣槽 FILL CELL 測試前以清水沖洗，再以待測試的樣品(水)沖洗 取樣槽3次(填滿倒空)。最後再以待測樣品(水) 填滿取樣槽。 Before testing, rinse CELL and clean with brush thoroughly. Finally rinse the cell 3 times with the water sample to be tested, then FI L L cell to capacity to begin test.
  • Page 9 填入樣品、置入試紙、定量 FILL, DIP, READ FREE CHLORIDE 自由餘氯 486637 (範圍0.00-12.0 ppm) 取出試紙片 REMOVE STRIP 打開試紙瓶蓋，取出試紙置於乾燥處，旋緊試紙瓶蓋。 Remove one eXact® Strip Micro CL (DPD-1), Part #486637 and set in a dry, convenient place. Replace cap. 編譯:莆崧實業(股) 置入試紙片 DIP STRIP 打開取樣槽的蓋子，按下 鍵。於螢幕倒數計時 20秒的期間內，將試紙置入取樣槽前後來回輕輕擺盪， 試紙深度須觸及槽底。擺盪試紙直至讀秒結束後，取出 試紙片棄置。...
  • Page 10 FILL, DIP, READ填入樣品、置入試紙、定量 486672 TOTAL CHLORINE HIGH 總氯 (廣範圍1.0-200 ppm) 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 ® Press the button to power on the Chlorine+ eXact 沖洗取樣槽 FILL CELL 測試前以淨水沖洗，並以待測試的樣品水沖洗取 樣槽3次(填滿倒空)。 Before testing, rinse CELL and clean with brush thoroughly. Finally rinse the cell 3 times with the water sample to be tested, then FILL cell to capacity to begin test.
  • Page 11 Place the Cell Cover onto the CELL and READ result displayed as Total Chlorine. This result is automatically stored in the CLH menu. After testing is complete, rinse the sample cell immediately and clean with brush to remove reagents which coat the CELL wall. 編譯:莆崧實業(股) Sensafe.com...
  • Page 12 填入樣品、置入試紙、定量 FILL, DIP, READ HYDROGEN PEROXIDE 過氧化氫 486648 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 ® Press the button to power on the Chlorine+ eXact 沖洗取樣槽 FILL CELL 測試前以淨水沖洗，並以待測試的樣品水沖洗取 樣槽3次(填滿倒空)。最後再以待測樣品水填滿 取樣槽。 Before testing, rinse CELL and clean with brush thoroughly. Finally rinse the cell 3 times with the water sample to be tested, then FILL cell to capacity to begin test.
  • Page 13 Place the Cell Cover onto the CELL and READ result displayed as Hydrogen Peroxide. This result is automatically stored in the HP menu. After testing is complete, rinse the sample cell immediately and clean with brush to remove reagents which coat the CELL wall. 編譯:莆崧實業(股) Sensafe.com...
  • Page 14 填入樣品、置入試紙、定量 FILL, DIP, READ OZONE 臭氧 486634 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 ® Press the button to power on the Chlorine+ eXact 沖洗取樣槽 FILL CELL 測試前以淨水沖洗，並以待測試的樣品水沖洗取 樣槽3次(填滿倒空)。最後再以待測樣品水填滿 取樣槽。 Before testing, rinse CELL and clean with brush thoroughly. Finally rinse the cell 3 times with the water sample to be tested, then FILL cell to capacity to begin test.
  • Page 15 Place the Cell Cover onto the CELL and READ result displayed as Ozone. This result is automatically stored in the O3 menu. After testing is complete, rinse the sample cell immediately and clean with brush to remove reagents which coat the CELL wall. 編譯:莆崧實業(股) Sensafe.com...
  • Page 16 填入樣品、置入試紙、定量 FILL, DIP, READ Peracetic Acid 過(氧)乙酸 486675 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 ® Press the button to power on the Chlorine+ eXact 沖洗取樣槽 FILL CELL 測試前以淨水沖洗，並以待測試的樣品水沖洗取 樣槽3次(填滿倒空)。最後再以待測樣品水填滿 取樣槽。 Before testing, rinse CELL and clean with brush thoroughly. Finally rinse the cell 3 times with the water sample to be tested, then FILL cell to capacity to begin test.
  • Page 17 Place the Cell Cover onto the CELL and READ result displayed as Peracetic Acid. This result is automatically stored in the PA menu. After testing is complete, rinse the sample cell immediately and clean with brush to remove reagents which coat the CELL wall. 編譯:莆崧實業(股) Sensafe.com...
  • Page 18 填入樣品、置入試紙、定量 FILL, DIP, READ pH 酸鹼值 (範圍6.4-8.4) 486639-II 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 ® Press the button to power on the Chlorine+ eXact 沖洗取樣槽 FILL CELL 測試前以淨水沖洗，並以待測試的樣品水沖洗取 樣槽3次(填滿倒空)。最後再以待測樣品水填滿 取樣槽。 Before testing, rinse CELL and clean with brush thoroughly. Finally rinse the cell 3 times with the water sample to be tested, then FILL cell to capacity to begin test.
  • Page 19 Place the Cell Cover onto the CELL and READ result displayed as pH. This result is automatically stored in the PH menu. After testing is complete, rinse the sample cell immediately and clean with brush to remove reagents which coat the CELL wall. 編譯:莆崧實業(股) Sensafe.com...
  • Page 20 填入樣品、置入試紙、定量 FILL, DIP, READ 486670 TOTAL CHLORINE 總氯 (DPD-4法,範圍0.0-12.0 ppm) 開機 POWER ON PHOTOMETER 長按 鍵直到開機，螢幕亮起。 ® Press the button to power on the Chlorine+ eXact 沖洗取樣槽 FILL CELL 測試前以淨水沖洗，並以待測試的樣品水沖洗取 樣槽3次(填滿倒空)。最後再以待測樣品水填滿 取樣槽。 Before testing, rinse CELL and clean with brush thoroughly.
  • Page 21 486670 填入樣品、置入試紙、定量 FILL, DIP, READ TOTAL CHLORINE 總氯 (DPD-4法,範圍0.0-12.0 ppm) 取出試紙片 REMOVE STRIP 打開試紙瓶蓋，取出試紙置於乾燥處，旋緊試紙瓶蓋。 Remove one eXact® Strip Micro CL (DPD-4), Part #486670 and set in a dry, convenient place. Replace cap. 置入試紙片&讀取DIP STRIP AND PRESS READ 打開取樣槽的蓋子，按下 鍵。於螢幕倒數計時 20秒的期間內，將試紙置入取樣槽前後來回輕輕擺盪， 試紙深度須觸及槽底。擺盪試紙直至讀秒結束後，取出...

  • Page 22: Dpd Interferences

    DPD法的測試干擾 DPD INTERFERENCES eXact Strip Micro CL (DPD-1 & DPD-4) Interferences ® Interfering Levels & Treatments Interferi Substan Acidity If sample has acidity above 150mg/L CaCO3 test may not develop full color. Neutralize to pH 6.0 to 7.0 with 0.5N Sodium hydroxide.

  • Page 23: For Best Accu Racy

    Minimize exposure of meter and test reagents to heat above 80°F (27°C). When installing batteries, verify the O-ring is still attached to the screw before tightening. Cleaning the cell with water and brush after each test is recommended for best accuracy and prior to storage of unit. Sensafe.com...

  • Page 24: Troubleshooting

    For additional technical support, call (803) 329-9712. Industrial Test Systems, Inc. 1875 Langston Street, Rock Hill, SC 29730 800-861-9712 or 803-329-9712 its@sensafe.com | sensafe.com ITS Europe, Ltd. The UK Centre for Homeland Security Building 7, Chilmark, Salisbury, Wiltshire SP3 5DU UK +44 1722 717911 Manufacturing quality products since1989 itseurope@sensafe.com | itseurope.co.uk...

  • Page 25: Built I N Sample Cell

    If the meter is faulty or otherwise defective contact ITS by phone (+1-803-329- 9712 Ext. 0) or email (its@sensafe.com) to describe the problem and obtain a return authorization form before returning the photometer to ITS. Damage caused by improper packing of the photometer for return shipment to ITS will not be covered by the warranty.

  • Page 26: Compliance Testing

    能力符合檢測方法 ABOUT COMPLIANCE TESTING This DPD test system for Chlorine and Chlorine Dioxide are accepted for reporting by most health departments because the tests are USEPA (DIN Standard 38 408 G4/G5, ISO 7393/2) accepted for testing requirements for Free Chlorine, Total Chlorine, and Chlorine Dioxide.
  • Page 27 L1, L2 or L3, with L1 being the highest accuracy rating. TEST RANGE ACCURACY RATING PARAMETERS Total Bromine 0 - 17 ppm Free Chlorine 0 - 12 ppm 6.4 - 8.4 pH Sensafe.com...

  • Page 28: Patent Information

    Value provided represents best possible accuracy under laboratory conditions, but may vary throughout the detection range. For a complete list of accuracies throughout all ranges, please visit sensafe.com/exact-ez-chlorine-plus/. Requires the use of 2 strips if reading is above 6 ppm.
