- Page 1 16 GALLON WET/DRY VACUUM Operation Manual MODEL #’s VOC1612PF 3801 This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Warranty ....................3 Important Safety Instructions ..............4 Double Insulation Instructions ............... 6 Extension Cords ..................7 Symbols ....................8 Unpacking & Checking Carton Contents ..........9 General Assembly Instructions ............. 10 Dry Vacuum Operation ................11 Liquid Vacuum Operation .............. -
Page 3: Warranty
WARRANTY We take pride in producing a high-quality, durable product. This Black Diamond product carries a limited two (2) year warranty against defects in workmanship and materials from date of purchase (or, for deliveries in the State of California, two years from the date of delivery) under normal household use. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS VACUUM. Read and understand this operator’s manual and all labels on the vacuum cleaner before operating. Safety is a combination of common sense, staying alert and knowing how your vacuum works. Use this vacuum only as described in this manual. - Page 5 • Do not use without dust bag and/or filters in place. • Do not allow to be used as a toy. Close attention is necessary when used by or near children. • To reduce the risk of injury from accidental starting, unplug the power cord before changing or cleaning filter.
-
Page 6: Double Insulation Instructions
DOUBLE INSULATION INSTRUCTIONS This Wet/Dry Vacuum is double-insulated, eliminating the need for a separate grounding system. Use only identical replacement parts. Read the instructions for Servicing Double-Insulated Wet/Dry Vacuums before servicing. Use this vacuum as described in this manual. Observe the following warnings that appear on the motor housing of your vacuum. -
Page 7: Extension Cords
WARNING SERVICING OF DOUBLE-INSULATED WET/DRY VACUUMS WITH A DOUBLE-INSULATED WET/DRY VACUUM, TWO SYSTEMS OF INSULATION ARE PROVIDED INSTEAD OF GROUNDING. NO GROUNDING MEANS IS PROVIDED ON A DOUBLE-INSULATED APPLIANCE, NOR SHOULD A MEANS FOR GROUNDING BE ADDED. SERVICING A DOUBLE-INSULATED WET/DRY VACUUM REQUIRES EXTREME CARE AND KNOWLEDGE OF THE SYSTEM AND SHOULD BE DONE ONLY BY QUALIFIED SERVICE PERSONNEL. -
Page 8: Symbols
SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, DANGER will result in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, WARNING could result in death or serious injury. -
Page 9: Unpacking & Checking Carton Contents
UNPACKING & CHECKING CARTON CONTENTS Remove all contents from the box. Remove the powerhead and take out any contents inside the collection tank. Check each item against the carton contents list. Carton Contents List: Description Qty. Vacuum Assembly ..........1 Hose ..............1 Handle .............1 Utility Nozzle .............1 Cartridge Filter .......... -
Page 10: General Assembly Instructions
GENERAL ASSEMBLY INSTRUCTIONS A Phillips head screwdriver is required WARNING DO NOT PLUG THE POWER CORD INTO A POWER OUTLET. MAKE SURE THE PLUG IS DISCONNECTED BEFORE ASSEMBLING THE WET/DRY VACUUM. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EXPOSE TO RAIN. UNPACKING YOUR WET/DRY VACUUM &... -
Page 11: Dry Vacuum Operation
the supplied foam wet filter. See page 18 for the foam wet filter installation instructions (Fig. 9). 9. Place the powerhead back on the collection tank and secure in place using the latches (Fig. 10). 10. Insert the locking end of the hose into the vacuum port on the collection tank and turn clockwise to lock into place (Fig. - Page 12 WARNING DO NOT PLUG THE POWER CORD INTO A POWER OUTLET. MAKE SURE THE PLUG IS DISCONNECTED BEFORE CHANGING THE FILTERS. CAUTION DO NOT VACUUM DRYWALL DUST, FIREPLACE SOOT, OR ASH WITH STANDARD WET/DRY FILTER. THIS IS A VERY FINE DUST WHICH WILL NOT BE CAPTURED BY THE FILTER AND MAY CAUSE DAMAGE TO MOTOR.
-
Page 13: Liquid Vacuum Operation
LIQUID VACUUM OPERATION LIQUID VACUUMING WARNING BE SURE TO READ, UNDERSTAND, AND APPLY INFORMATION ENTITLED ‘IMPORTANT SAFETY INSTRUCTIONS’. DO NOT VACUUM IN AREAS WITH FLAMMABLE GASES, VAPORS, OR EXPLOSIVE DUST IN THE AIR. FLAMMABLE GASES OR VAPORS INCLUDE BUT ARE NOT LIMITED TO: LIGHTER FLUID, SOLVENT TYPE CLEANERS, OIL-BASED PAINTS, GASOLINE, ALCOHOL, OR AEROSOL SPRAYS. - Page 14 7. After use, empty the collection tank by unscrewing the drain cap. Drain liquids into a suitable receptacle or drain (Fig. 7). Remember to refit the drain cap to the collection tank. IMPORTANT! When vacuuming large quantities of liquids, do not immerse the nozzle completely in the liquid;...
-
Page 15: Blower Operation
BLOWER OPERATION This Wet/Dry Vac has blowing capabilities. To use the blower feature, follow the instructions listed below. WARNING ALWAYS WEAR SAFETY GOGGLES COMPLYING WITH ANSI Z87.1 (OR IN CANADA, CSAZ94.3) BEFORE USING BLOWER. KEEP BYSTANDERS CLEAR FROM BLOWING DEBRIS. WEAR A DUST MASK IF BLOWING CREATES DUST THAT MIGHT BE INHALED. -
Page 16: Maintenance
MAINTENANCE EMPTYING THE COLLECTION TANK WARNING ALWAYS DISCONNECT THE PLUG FROM THE POWER OUTLET BEFORE REMOVING THE POWERHEAD FROM THE COLLECTION TANK. 1. Verify that the power cord is disconnected from the outlet (Fig. 1). 2. Disconnect the hose from the vacuum (Fig. 2). 3. -
Page 17: Installing & Cleaning Cartridge Filter
INSTALLING & CLEANING CARTRIDGE FILTER INSTALLING CARTRIDGE FILTER 1. Verify that the power cord is disconnected from the outlet (Fig. 1). 2. Remove the powerhead and place in an upside-down position. 3. Install the cartridge filter over the filter cage, making sure the cage is completely covered (Fig. -
Page 18: Installing & Cleaning Foam Wet Filter
INSTALLING & CLEANING FOAM WET FILTER INSTALLING FOAM WET FILTER 1. Verify that the power cord is disconnected from the outlet (Fig. 1). 2. Remove the powerhead and place in an upside-down position. Follow instructions to remove the cartridge filter on page 17. 3. -
Page 19: Troubleshooting
TROUBLESHOOTING WARNING TO REDUCE THE RISK OF ELECTRIC SHOCK, UNPLUG BEFORE TROUBLESHOOTING. PROBLEM POSSIBLE CAUSE SOLUTION Check the power supply, cord, No power supply. breakers, and fuses. Unplug and check the power cord. Faulty power cord. If damaged, have it repaired by a The wet/dry vacuum will not professional. -
Page 20: Exploded View
EXPLODED VIEW... -
Page 21: Parts List
PARTS LIST Part Part Number Description Quantity 551115101 Handle Assembly Powerhead Assembly 551005103 Float 551436113 Filter Cage 551152109 Latch Assembly Collection Tank 551612103 Vacuum Port Assembly 551002110 Drain Cap 551002111 Caster Foot Assembly 551002113 Hose 551002116 Extension Wand 551006111 Utility Nozzle 551002118 Foam Wet Filter 551030114... - Page 24 For Service or Questions: Call 888-376-7375 BLACK-DIAMOND.COM BLACK DIAMONDTM is a trademark of Mid-States Distributing, LLC. © Mid-States Distributing, LLC. Manufactured for and distributed by Mid-States Distributing, LLC. Fort Worth, TX 76137 USA.
