- Page 1 FES MOTOR MANUAL Version 1.6 Type: FES-LAK-C100 LZ design d.o.o., Brod 3D, 1370 Logatec, Slovenia tel +386 59 948 898 info@lzdesign.si www.front-electric-sustainer.com SPORTINE AVIACIJA ir Ko Pociunai, LT-59327 Prienai, Lithuania tel: +370 319 60567 info@lak.lt www.lak.lt...
-
Page 2: Table Of Contents
FES-LAK-C100 MOTOR manual, Version 1.6 June 2022 Table of Content 1. Important notices ..................... 3 1.1 Limited Warranty ....................3 2. General ........................4 3. Model designation ....................4 4. Technical data and limitations of motor ..............5 5. Drawing of motor ..................... 7 6. -
Page 3: Important Notices
LZ design retains the exclusive right to repair or replace the unit or software, or to offer a full refund of the purchase price, at its sole discretion. SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY. -
Page 4: General
FES-LAK-C100 MOTOR manual, Version 1.6 June 2022 2. General Congratulations on your purchase. This is a high-end product of brushless synchronous permanent magnet motor with electronically controlled commutation system 3 phase, which will keep its capability for a long time if treated the right way. -
Page 5: Technical Data And Limitations Of Motor
DC current from Battery packs to 3 phase current which supply motor. We use controller type which needs hall position sensors in motor, but this motor can work also with some sensorless controllers. Electrical motor type FES-LAK-C100 power ratings at 133V on motor controller and loaded with FES-LAK-P11-100 propeller: 75 Nm... - Page 6 FES-LAK-C100 MOTOR manual, Version 1.6 June 2022 Power Consumption Max climb Power consumption curve Horizontal flight 0; 0 1000 2000 3000 4000 5000 n (RPM) Rpm versus Power at 116V Page 6 of 10...
-
Page 7: Drawing Of Motor
FES-LAK-C100 MOTOR manual, Version 1.6 June 2022 5. Drawing of motor Page 7 of 10... -
Page 8: Maintenance
FES-LAK-C100 MOTOR manual, Version 1.6 June 2022 6. Maintenance The motor does not need any maintenance. Opening or disassembling of the motor would cause a forfeit of warranty claims! It could be also very dangerous, due to very strong magnets on rotor! Though, it must be considered that no foreign objects at all can enter the interior of the drive. -
Page 9: Removal Of Motor
FES-LAK-C100 MOTOR manual, Version 1.6 June 2022 7. Removal of motor Note: Removal of motor from sailplane is only allowed in case of written permission from manufacturer otherwise warranty is not valid anymore! Warning: It is not allowed to fly with removed motor from the sailplane, as C.G. -
Page 10: Repair And Service
FES-LAK-C100 MOTOR manual, Version 1.6 June 2022 9. Repair and service In case of a fault or damage(s), contact manufacturer. 10. Revision history June 2022 Initial release of manual v1.6 Page 10 of 10...
