- Page 1 Fully Automatic Washing Machine OWNER’S MANUAL AW-M901BT Read This Manual Please Read and follow the instructions carefully. Please Keep this owner’s manual handy for future use. 16138000A44286 6348448301...
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS Safety instructions ............... INSTALLATION Product description ..............Installation area ................Unpacking the washing machine ......... Base Cover Installation ............... Levelling the washing machine ..........Selection of tap ................Connection of inlet hose, tap and washing machine.. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS For your safety, the information in this manual must be followed to minimize the risk of re or explosion, electric shock, or to prevent property damage, personal injury or loss of life. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision... - Page 4 SAFETY INSTRUCTIONS Washing Capacity Model Standard Water Pressure AW-M901BT 8.0kg 0.03MPa ~ 0.8MPa Explanation of the symbols: Warning! This combination of symbol and descriptive word indicates a potentially dangerous situation which may result in death or serious injuries unless it is avoided.
- Page 5 SAFETY INSTRUCTIONS Warning! The electric shock! • This washing machine is for indoor use only. • Do not put this washing machine in a humid place. • Hands should not be inserted into the rotating drum • Before doing any maintenance the unit , unplug the...
- Page 6 SAFETY INSTRUCTIONS Risk to children! • he appliance can not be used by children and persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 7 SAFETY INSTRUCTIONS Caution Installing the product! • This washing machine is for indoor use only. • It is not intended for built-in using. • The openings must not be obstructed by a carpet. • The w ashing machine shall not be installed in bath room or very wet rooms as well as in the rooms with explosive or caustic gases.
- Page 8 SAFETY INSTRUCTIONS Operating the appliance! • Before washing the clothes for the first time, the product shall be operated without clothes using tub clean as the displayed program on the control panel. • Flammable and explosive or toxic solvents are forbidden. Gasoline and alcohol etc.
-
Page 9: Installation
INSTALLATION Product description Glass lid Water inlet valve Drum Power cord and plug Frame Control panel Cabinet Handle Adjustable foot Drain hose Note! • ll illustrations in this manual are for reference only. lease refer to the product ,for actual appearance of the parts Accessories Inlet hose assy cabinet baseboard... -
Page 11: Levelling The Washing Machine
INSTALLATION Warning! • Do not kink protract or compress the drain hose. • Position drain hose properly otherwise improper position may result in water leakage. • If drain hose is too long, do not force it into washing machine as this will cause abnormal noises. -
Page 18: Operation
OPERATION Washing Course Table Courses are available according to the laundry type. Only for models having these functions: Course Suitable to wash lightly- stained clothes and clothes summer. SPEED: Mid/High/Low water level selection, the tempo is soft, slow DELICATE: washing and spinning speed, for minima l wear and deformation. -
Page 19: Recommended Detergent Amount
(8gear) (6gear) (4gear) (2gear) -
Page 20: Maintenance
MAINTENANCE Cleaning And Care Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning the cabinet Proper maintenance the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. If there is any water overflow, use wet cloth to wipe it off immediately. -
Page 22: Technical Speci Cations
8.0kg 550x565x930 37kg 450W 220-240V~,50Hz AW-M901BT 1. Press the “ON/OFF” switch. 2. Select the “Regular” program(Regular). 3. Adjust washing water level to the highest level “8 gear”. 4. Select "Process", go to “(Rinse)”, adjust the value by pressing the "Set" button, select Rinse 1 time. - Page 23 MEMO...
