- Page 1 Fully Automatic Washing Machine OWNER’S MANUAL Model: AW-T08DU1400LM AW-T08DU1600LM Read This Manual Read and follow the instructions carefully. Keep the operation instructions handy for future use .
- Page 2 CONTENTS SAFETY INSTRUCTIONS Safety instructions ..............INSTALLATION Product description ..............Installation area ................Unpacking the washing machine .......... Installation of the cabinet base cover ........Levelling the washing machine ..........Selection of tap ................Connection of inlet hose, tap and washing machine..OPERATION Preparation before washing.............
- Page 3 SAFETY INSTRUCTIONS Safety instructions For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. Important safety precautions • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision...
- Page 4 SAFETY INSTRUCTIONS Washing Capacity Model Standard Water Pressure 13.0kg AW-T08DU1400LM 0.03MPa~0.8MPa 15.0kg AW-T08DU1600LM 0.03MPa~0.8MPa Explanation of the symbols: Warning! This combination of symbol and descriptive word indicates a potentially dangerous situation which may result in death or serious injuries unless it is avoided.
- Page 5 SAFETY INSTRUCTIONS Warning! The electric shock! • This washing machine is for indoor use only. • Do not put this washing machine in a humid place. • Before doing any maintenance the unit, unplug the appliance from the electrical source. •...
- Page 6 SAFETY INSTRUCTIONS Risk to children! • The appliance can not be used by children and persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 7 SAFETY INSTRUCTIONS Caution! Installing the product! • This washing machine is for indoor use only. • It is not intended for built-in using. • The openings must not be obstructed by a carpet. • The washing machine shall not be installed in bath rooms or very wet rooms as well as in the rooms with explosive or caustic gases.
- Page 8 SAFETY INSTRUCTIONS Risk of damaging appliance! • Your product is only for home use and is only designed for textiles suitable for machine washing. • Do not climb up and sit on the glass lid of the machine. • Cautions during Machine Handling and transport: 1.The accumulated water shall be drained out of the machine.
- Page 9 INSTALLATION Product description Glass lid Water inlet valve Drum Power cord and plug Frame Control panel Cabinet Handle Adjustable foot knob Lid lock Note! • All illustrations in this manual are for reference only. Please refer to the product ,for actual appearance of the parts. Accessories Spring clamper Inlet hose assy...
- Page 10 INSTALLATION Installation Area Warning! • Stability is important to prevent the product from moving! • Make sure that the product does not stand on the power cord. • Keep clearance: 50mm with the drain hose beside the machine, 20mm without the drain hose. W≥20 mm Before installing the machine, the location characterized as follows shall be selected:...
- Page 11 INSTALLATION Warning! • Do not kink protract or compress the drain hose. • Position drain hose properly otherwise improper position may result in water leakage. • If drain hose is too long, do not force it into washing machine as this will cause abnormal noises.
- Page 12 INSTALLATION Selection of tap Please select appropriate tap. Ordinary tap Screw tap Special washing machine tap Connection of inlet hose, tap and washing machine Connect inlet hose to tap properly , depending on the type of inlet hose supplied with the washing machine .
- Page 13 OPERATION Preparation Before Washing Caution! • Before washing, please make sure that the unit is installed properly. • Before washing for the first time, the washing machine shall be operated without clothes using tub clean as the recommended course. • Do not use water with temperatures over 50 °C. A complete cycle is as shown below Liquid detargent Case...
- Page 14 OPERATION Washing matters needing attention • Before washing ,please check the clothes labels and the detergent usage instructions. Use low-density detergent before wash suitable for washing machines. Take items out Tie tassels into Knot, fasten Check the label of the pockets zippers and buttons Put small clothes into a Turn the following clothes...
- Page 15 OPERATION Control Panel • This illustration is for reference only. Please refer to the product ,for actual appearance Start/Hold On/Off Turns the unit on and off. Press this button to start or Hold the washing cycle. Course Option Available according to the laundry type. This allows you to select an Display additional function and will light up...
- Page 16 OPERATION Option Only for models having these functions. Water level select the water level according to clothing categories, degree of soiling and washing habits of users Wash /Rinse /Spin Washing time, number of rinses , spinning time can be selected. GREATWAVES is able to shorten wash time by special rhythm and water flow.
- Page 17 OPERATION Personalized setting of washing course The user can select washing course according to the actual need, and set washing time, number of rinses, spinning time, water volume and course start time. Start Choose the Water Level Set/washing/spinning course time,rinsing times Operations of washing process The user can set a single process or combinations of washing, rinsing and spinning freely according to the need.
- Page 18 OPERATION Washing Course Table Courses are available according to the laundry type. Course Suitable to wash lightly- stained clothes and clothes for summer. SPEED: Mid/High/Low water level selection, the tempo is soft, slow DELICATE: washing and spinning speed, for minimal wear and deformation. Press "Start \Hold "...
- Page 19 OPERATION Recommended Detergent Amount Detergents Softener Manual Water Level Setting Powder Liquid Normal Concentrated type type 15/13 Approx. Approx. Approx. Approx. (8gear) -31mL 65 -100g 65m -92mL 41m -60mL 10kg Approx. Approx. Approx. Approx. 40 -65g -21mL 43m -65mL (6gear) 24m -41mL Approx.
- Page 20 MAINTENANCE Cleaning And Care Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning the cabinet Proper maintenance the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. If there is any water overflow, use dry cloth to wipe it off immediately.
- Page 21 MAINTENANCE Trouble Shooting If the appliance does not start or it stops during the operation, initially try to find a solution to the problem based on the table below. Otherwise, contact the service center. Description Inspection Items If the power is off . If the wate r volume reache the required water level.(The washer will No washing...
- Page 22 Washing Net dimension Including drain hose Rated Model Supply Capacity Weight (W*D*Hmm) (W*D*Hmm) Power 220-240V~, 13.0kg 46kg AW-T08DU1400LM 601x630x1020 601x700x1020 560W 50Hz 220-240V~, 15.0kg 46kg AW-T08DU1600LM 601x630x1020 601x700x1020 560W 50Hz Energy efficiency test program It is identified as Malaysia Efficiency Program as followed: Energy test program operation: 1.
