2
EN
USER MANUAL
WASHING MACHINE
EWF1 1 ******

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EWF11 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electrolux EWF11 Series

Summary of Contents for Electrolux EWF11 Series

  • Page 1 USER MANUAL WASHING MACHINE EWF1 1 ******...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooter, service information, buy accessories & spare parts, online product registration: www.electrolux.com CUSTOMER CARE AND SERVICE We recommend the use of original spare parts. When contacting Service, ensure that you have the following data available.

  • Page 3: Safety Information

    1. SAFETY INFORMATION 1.1 Conditions Of Use This appliance is intended to be used in household and similar applications such as: • staff kitchen areas in shops, offices and other working environment; • farm houses; • by clients in hotels motels, and other residential type environments;...

  • Page 4: Child Safety

    1.2 Child Safety • This machine is not intended for use by children or infirm persons without supervision. • The children should be supervised to ensure that they do not play with the appliance. • The packaging components (e.g. plastic film, polystyrene) can be dangerous to children-danger of suffocation! Keep them out of children’s reach.
  • Page 5 1.4 Installation • Never pull the power supply cable to remove the plug from the socket; • This appliance is heavy. Care should always hold the plug itself. be taken when moving it. • Never use the machine if the power •...

  • Page 6: Electrical Connection

    1.6 Electrical Connection CAUTION! Connect the machine to an earthed "An incorrect power supply may void socket outlet. your warranty." The manufacturer declines any responsibility for damage or injury Check that your domestic electrical through failure to comply with the installation can take the maximum load above safety precaution.
  • Page 7 2.1.1 Detergent/Softener Dispenser 2.1.4 Level Adjustment feet Drawer The detergent dispenser drawer compartment information, For details about using detergent and additives, see page 24. Main wash Softener 2.1.5 Transit Bolt (when remove) Prewash 2.1.2 Door (when open) Rating Label Drum Lifter Stainless Steel...

  • Page 8: Technical Data

    3. TECHNICAL DATA Dimensions (Height / Width / Depth) 850 x 600 x 659 mm Power supply (Voltage / Frequency) 220 - 240 V~/ 50 Hz Total power absorbed 2100 W Water supply pressure (Maximum / Minimum) 0.8 MPa / 0.05 MPa Maximum Spin Speed 1400 rpm 4.
  • Page 9 4.2 Positioning WARNING! Before proceeding with installation, read the safety information, and dimension preferred. 600 mm 659 mm 575 mm 850 mm 930 mm ENGLISH...
  • Page 10 20 mm 20 mm CAUTION! When installing the product make sure the levelling feet is not pressing on the power cord. When the machine is levelled, try to rock it from corner to corner. wall If it does rock, adjust the legs again until it is levelled and does not rock.

  • Page 11: Water Inlet

    4.3 Water Inlet 4.4 Water Drainage Connect the water inlet hose to a tap The end of the drain hose can be with 3/4” BSP thread. Use the hose positioned in three ways: supplied with the machine. DO NOT USE •...
  • Page 12 • In a sink, drain pipe branch. This branch must be above the trap so Max. Max. that the bend is at least 60 cm above the ground. 41 cm 88 cm Push the drain hose onto the spigot and secure with a clip, ensure a loop is formed in the drain hose to prevent waste from the sink entering the appliance.

  • Page 13: Control Panel

    5. CONTROL PANEL 5.1 Control Panel Description Programme selector knob Prewash touch key Hygienic Care touch key Display (Child lock option) SmartSelect touch key Stain Pro touch key • Refresh touch key Finish In adjustment • Light touch key Plus touch key •...
  • Page 14 Finish In icon Rinse Hold icon Add clothes icon Child Lock icon UltraMix icon SensorWash icon Notification icon Remote Start mode icon Wi-Fi connection icon The Temperature area: Temperature icon Cold water Maximum load icon The spin area: Spin Speed indicator ) No Spin indicator, Spin phase if off...

  • Page 15: Programmes

    5.3 SmartLeaf feedback There are three different level of SmartLeaf feedback indicated: SmartLeaf symbols give feedback on 1. No SmartLeaf (no icon in the display) consumption, guiding the user to save 2. One leaf icon energy, time and water. 3. Two leaf icon This feature will indicate levels of energy savings in a programme based...

  • Page 16: Woolmark Apparel Care - Blue

    Programme; Max. Spin Max. Load Temperature speed Type of load and soil level (Dry Clothes) range (rpm) Spin 1400 To spin the laundry and to drain the water in the drum. All fabrics, except woollens and delicate fabrics. Rinse + Spin 1400 All fabrics, except woollens and very delicate fabrics.

  • Page 17: Programme Options Compatibility

    6.3 Programme Options Compatibility Programme Options                                No Spin  ...

  • Page 18: Smartselect, Options And Settings

    7. SMARTSELECT, OPTIONS AND SETTINGS 7.1 SmartSelect 7.2 Options This new feature has been created to Temperature Touch key guide the user to save energy, time and water, with the aim of improving the Touch this touch key repeatedly sustainability of cycles, the care and to increase or decrease the wash maintenance of fabrics and consumer temperature if you want your laundry to...
  • Page 19 Hygienic Care Touch key Remote Start Touchpad ( Select this option to add approximately This option allows you to connect 30 minutes of tumbling in vapour after the machine to Wi-Fi network and to link it to rinse cycle. The indicator of this option your smart phone.
  • Page 20 After selecting Finish In time, press Start/ Save App Favourite Programme Pause touch key to start the programme. Machine will then countdown and update time on the display every hours until it Enabled only by enabling Remote Start mode. reaches the starting point of the wash cycle.

  • Page 21: Add Clothes

    The software in this product connection enabled. contains components that are based • Mobile device connected to wireless on free and open source software. Electrolux gratefully acknowledges network. the contributions of the open software and robotics communities to the Frequency/ Wi-Fi: 2.4 GHz / 802.11 bgn...

  • Page 22: Wi-Fi Network Connection

    Mode touch key On will enable account, and accept the Terms and users to be able to start cycles remotely Conditions and Electrolux’s Privacy on the our app. Policy in the app to use the connected features of the laundry appliance.

  • Page 23: Over-The-Air Update

    8.3 Over-the-air update 8.4 Wi-Fi Always On The application may propose an update The Wi-Fi Always On function is available for downloading new features. in our app. This function keeps the appliance The update is accepted via app only. connected to the network even when the If a programme is running, the app appliance is turned off.

  • Page 24: Daily Use

    10. DAILY USE 10.1 Loading The Laundry 10.2 Using Detergent And Additives 1. Turn the water tap on. Please refer to section "Detergents 2. Connect the main plug to the main Type and Quantity of Detergent" page socket. 29 before use. 3.

  • Page 25: Options Setting

    - If required, pour fabric softener into Position up: for the Softener compartment. powder detergent When you use the liquid detergent. - Do not use gelatinous or intense liquid detergents. - Do not put more liquid than the maximum level. - Do not set the "Prewash"...

  • Page 26: Changing A Programme

    10.4 Starting A Cycle ( 10.7 Changing The Options To start a programme, press the Start/ It may be possible to change some of Pause touch key. The corresponding the options after a wash programme has pilot light will stop flashing and a default started.

  • Page 27: At The End Of The Programme

    10.9 At The End Of The Programme Alternatively, before pressing the "Start/Pause" touch key, you can press • The appliance stops automatically. the "Spin" touch key to change the spin speed. You can select "No Spin • The acoustic signal will operate. )", if you want the machine to •...

  • Page 28: Washing Hints

    11. WASHING HINTS 11.1 Sorting The Laundry • Wash bras, pantyhose and other delicates in Follow the wash code symbols on each a mesh laundry bag, garment label and the manufacturer’s which you can purchase from your washing instructions. Sort the laundry supermarket.

  • Page 29: Removing Stains

    11.5 Removing Stains 11.6 Detergents Type And Quantity Of Detergent Stubborn stains may not be removed by just water and detergent. It is therefore Low suds detergent is required for this advisable to treat them prior to washing. machine to prevent over suds problems, unsatisfactory washing result and harm to Blood: treat fresh stains with cold water.

  • Page 30: International Wash Code Symbols

    Not enough detergent causes: Use less detergent if: • the wash load to turn grey, • you are washing a small load, • greasy clothes. • the laundry is lightly soiled, Too much detergent causes: • large amounts of foam during washing.

  • Page 31: Care And Cleaning

    13. CARE AND CLEANING 13.5 Cleaning The Dispenser Drawer WARNING! You must DISCONNECT the appliance The Figures that take place in this from the electricity supply, before manual are schematic and may not you can carry out any cleaning or correspond exactly with your product.

  • Page 32: Cleaning The Drawer Recess

    Flush it out under a tap to remove any WARNING! traces of accumulated powder. Disconnect the mains plug from the mains socket. Do not remove the filter while the appliance is operating. Do not clean the drain pump if the water in the appliance is hot.
  • Page 33 3. When the container is full of water, 5. Remove fluff and objects from the put the drainage duct back again pump (if there are any). and empty the container. Do step 2, 3 again and again until no more water flows out from the drain pump.

  • Page 34: Cleaning The Water Inlet Filter

    8. Put the filter back into the housing with exposed section facing up. Make sure that you correctly tighten the filter to prevent leakages. Guide 4. Remove the inlet hose behind the appliance. 5. Clean the filter in the valve with a stiff brush or a towel.

  • Page 35: Frost Precautions

    13.9 Frost Precautions If the appliance is installed in an area where the temperature can be less than 0 °C, remove the remaining water from the inlet hose and the drain pump. Emergency Drain 1. Disconnect the main plug from the main socket.

  • Page 36: Troubleshooting

    14. TROUBLESHOOTING 14.1 Possible Failures Alarm code: Certain problems are due to lack of The appliance does not fi ll with water simple maintenance or oversights, which properly. can be solved easily without calling The appliance does not drain the out an engineer.
  • Page 37 Malfunction Possible cause Solution The drain hose is squashed or Check the drain hose connection. kinked. (Error code: The drain pump is clogged. Clean the drain filter. Machine does (Error code: not empty and/or does The option "Rinse Hold" has been Press Start/Pause touch key to not spin: selected.
  • Page 38 Malfunction Possible cause Solution There is very little laundry in the Load more laundry. drum. Machine vibrates or is Unstable floors e.g. wooden Refer to relevant paragraph in noisy: floors. "Positioning" section. Detergent over dose. Reduce the detergent quantity or use another one.

  • Page 39: Emergency Door Opening

    14.2 Emergency Door Opening In case of power failure or appliance failure, the appliance door remains locked. The wash programme continues when power is restored. If the door remains locked in case of failure, it is possible to open it using the emergency unlock feature.

  • Page 40: Environment Concerns

    15. ENVIRONMENT CONCERNS 15.1 Packaging Materials 15.3 Ecological Hints The materials marked with the symbol To save water, energy and to help are recyclable. protect the environment, we recommend that you follow these tips: >PE<=polyethylene • Normally soiled laundry may be >PS<=polystyrene washed without pre-washing in order >PP<=polypropylene.
  • Page 41 G0044263-001-A28643507...
