  • Page 1 EWF1142R7SB Washing Machine User Manual WI-FI Connectivity Setup...
  • Page 2 Electrolux manufacturer’s warranty provided with your product. Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Electrolux manufacturer’s warranty in the event that your product fault is due to failure to adhere to this manual.

  • Page 3: Table Of Contents

    ENGLISH CONTENTS 8. CARE AND CLEANING ....25 SAFETY INFORMATION ... 4 8.1 External Cleaning ...... 25 1.1 Conditions Of Use ....... 4 8.2 Descaling ........25 1.2 Child Safety ......... 5 8.3 After Each Wash ....... 25 1.3 General Safety ......5 8.4 Maintenance Wash ....

  • Page 4: Safety Information

    SAFETY INFORMATION 1.1 Conditions Of Use This appliance is intended to be used in household and similar applications such as: • staff kitchen areas in shops, offi ces and other working environment; • farm houses; • by clients in hotels motels, and other residential type environments;...

  • Page 5: Child Safety

    ENGLISH 1.2 Child Safety • This machine is not intended for use by children or persons with infi rmity without supervision. • The children should be supervised to ensure that they do not play with the appliance. • The packaging components (e.g. plastic fi lm, polystyrene) can be dangerous to children.

  • Page 6: Installation

    1.4 Installation 1.5 Use • This appliance is heavy. Care should • Only wash fabrics which are designed be taken when moving it. to be machine washed. Follow the instructions on each garment label. • When unpacking the appliance, check that it is not damaged.

  • Page 7: Product Description

    ENGLISH 2. PRODUCT DESCRIPTION 2.1 Parts Worktop Detergent / Softener Dispenser Control Panel (see page 18) (see page 10) Cabinet Door Drain Pump Filter Front Panel (see page 26) Level Adjustment Feet (Front) Mains Cable Transit Bolts Transit Bolts & Hose Support Water Inlet Hose (see page 37) Water Drain Hose...

  • Page 8: Accessories

    Transit Bolt (when remove) Detergent / Softener Dispenser For more information, see page 18,25 Prewash Main Wash Softener Door (when open) Drum Lifter Stainless Steel Washing Transit bolts must be removed Drum before using the appliance. 2.2 Accessories Drain Pump Filter (when open)

  • Page 9: Load Sensor

    ENGLISH 2.3 Load Sensor This machine has “Load Sensing Device” which shows how much load you put in the machine and maximum load recommended for selected wash programme. The display shows these indicators when the door is open. The weight shown on display is an approximate weight only.

  • Page 10: Control Panel

    3. CONTROL PANEL 3.1 Control Panel Description On/Off Programme selector knob Temp touchpad On/Off button Display SensorWash touchpad Delay End touchpad Stain touchpad Time Manager touchpad Hygienic Care touchpad Start/Pause touchpad Prewash touchpad (Pause to add clothes option) Remote touchpad...

  • Page 11: Programme Chart

    ENGLISH 3.2 Programme Chart Programme; Max. Max. Load Type of load and soil level Temperature Spin (Dry range Speed Clothes) Cottons; 1400 Max. White and coloured cotton. (Adjust wash time according to soil level. See Time Manager Cold to 90°C table on page 14) Mixed;...
  • Page 12 Programme; Max. Max. Load Type of load and soil level Temperature Spin (Dry range Speed Clothes) Daily 39; 1200 5.5 kg Daily wear coloured cotton clothes such as shirts, blouses, towels and undergarments. 30°C to 40°C Ideal for low level of soil.

  • Page 13: Programme Options Compatibility

    ENGLISH 3.3 Programme Options Compatibility Option Programme Time Stain Rinse Sensor Delay Hygienic Prewash Spin Manager Hold Wash Care Cottons         Mixed         Delicates   ...

  • Page 14: Options

    3.4 Options Delay End Touchpad Temperature Touchpad Before you start the programme, this option makes it possible to defi ne the Press this touchpad repeatedly end of the washing programme from to increase or decrease the wash minimum of 1 hour to maximum of 20 temperature if you want your laundry to hours.
  • Page 15 ENGLISH If Hygienic Care option is selected, SensorWash ( ) Touchpad rinse temperatures will be elevated. Select “SensorWash” option to turn ON the sensors for the dirt and detergent During a vapour cycle, you may residue. notice vapour exiting from the drain hose of the washing machine, this When using this option, the washing is normal and there is no cause for...

  • Page 16: Settings

    3.5 Settings • To deactivate the function, press and hold “Hygienic Care” touchpad about 2 seconds until the icon “ ” goes off . Save Favourite ( Programme This function remains enabled even after the appliance is switched off .

  • Page 17: Start/Pause ( ) And Add Clothes ( ) Touchpad

    ENGLISH 3.6 Start/Pause ( ) and 2. Add Clothes ( Add Clothes ( ) Touchpad You can only add clothes when the icon “ ” shown on the display. This touchpad has 2 functions: 1. Pressing the “Start/Pause” 1. Start/Pause ( touchpad to pause the programme.

  • Page 18: Daily Use

    5. DAILY USE 5.1 Loading The Laundry 5.2 Using Detergent And Additives 1. Turn the water tap on. 2. Connect the main plug to the main IMPORTANT: Please read socket. “Detergents Type and Quantity of Detergent”on page 23 before 3.

  • Page 19: Options Setting

    ENGLISH When you use the liquid NOTE detergent The softener amount used must not - Do not use gelatinous or thick liquid exceed the “MAX” mark in the drawer. detergents. If you use thick softeners it is - Do not put more liquid than the recommended to dilute with water.

  • Page 20: Starting A Cycle ( )

    5.4 Starting A Cycle ( 5.7 Changing The Options To start a programme, press the Start/ It may be possible to change some of Pause touchpad. The corresponding the options after a wash programme has pilot light will stop fl ashing and a default started.

  • Page 21: At The End Of The Programme

    ENGLISH 5.9 At The End Of The To drain the water: 1. Press the “Start/Pause ” touchpad. Programme The appliance drains the water and • The appliance stops automatically. spins with the maximum spin speed for selected programme. • The acoustic signal will operate. Alternatively, before pressing the •...

  • Page 22: Washing Hints

    6. WASHING HINTS 6.1 Sorting The Laundry • Wash bras, pantyhose and other delicates in Follow the wash code symbols on each a mesh laundry bag, garment label and the manufacturer’s which you can washing instructions. Sort the laundry...

  • Page 23: Detergents Type And Quantity Of Detergent

    ENGLISH Stubborn stains may not be removed by 6.6 Detergents Type And just water and detergent. It is therefore Quantity Of Detergent advisable to treat them prior to washing. Blood: treat fresh stains with cold water. Low sudsing detergent is required for this For dried stains, soak overnight in water washing machine to prevent oversudsing with a special detergent then rub in the...

  • Page 24: International Wash Code Symbols

    Not enough detergent causes: Use less detergent if: • the wash load to turn gray, • you are washing a small load, • greasy clothes. • the laundry is lightly soiled, • large amounts of foam during Too much detergent causes: washing.

  • Page 25: Care And Cleaning

    ENGLISH 8. CARE AND CLEANING 8.5 Cleaning The Dispenser WARNING! Drawer You must DISCONNECT the appliance The washing powder and additive from the electricity supply, before you can dispenser drawer should be cleaned carry out any cleaning or maintenance regularly. work.

  • Page 26: Cleaning The Drawer Recess

    Flush it out under a tap to remove any WARNING! traces of accumulated powder. 1. Disconnect the mains plug from the mains socket. 2. Do not remove the fi lter while the appliance is operating. Do not clean the drain pump if the water in the appliance is hot.
  • Page 27 ENGLISH 3. When the container is full of water, 5. Remove fl uff and objects from the put the drainage duct back again and pump (if there are any). empty the container. Do step 2, 3 again and again until no more water fl...

  • Page 28: Cleaning The Water Inlet Filter

    8. Put the fi lter back into the housing with exposed section facing up. Make sure that you correctly tighten the fi lter to prevent leakages. Guide 4. Remove the inlet hose behind the appliance. 5. Clean the fi lter in the valve with a stiff...

  • Page 29: Frost Precautions

    ENGLISH 8.9 Frost Precautions If the appliance is installed in an area where the temperature can be less than 0 °C, remove the remaining water from the inlet hose and the drain pump. Emergency Drain 1. Disconnect the main plug from the main socket.

  • Page 30: Troubleshooting

    9. TROUBLESHOOTING 9.1 Possible Failures Alarm code: Certain problems are due to lack of The appliance does not fi ll simple maintenance or oversights, which with water properly. can be solved easily without calling out The appliance does not drain an engineer.
  • Page 31 ENGLISH Malfunction Possible cause Solution The drain hose is squashed Check the drain hose connection. or kinked. (Error code: Machine The drain pump is clogged. Clean the drain fi lter. (Error code: does not empty and/ The option “Rinse Hold” has Press Start/Pause touchpad to drain the or does not been selected.
  • Page 32 Malfunction Possible cause Solution The laundry is not evenly Pause the machine and redistribute distributed in the drum. laundry manually. Machine There is very little laundry in the Load more laundry. vibrates or is drum. noisy: Unstable fl oors e.g. wooden Refer to relevant paragraph in fl...

  • Page 33: Emergency Door Opening

    ENGLISH NOTE If you are unable to identify or solve the problem, contact our service center. Before calling service center, make Scan QR code PNC : Mod : S/N : a note of the model, serial number Made in Thailand and purchase date of your machine: the Service Centre will require this information.

  • Page 34: Technical Data

    10. TECHNICAL DATA Dimensions (Height / Width / Depth) 850 x 600 x 659 mm Power supply (Voltage / Frequency) 220 - 240 V~/ 50 Hz Total power absorbed 2100 W Water supply pressure (Maximum / 0.8 MPa / 0.05 MPa...
  • Page 35 ENGLISH 2. Remove the carton box. Remove the 4. Put one of the polystyrene packaging polystyrene packaging materials. elements on the fl oor behind the Remove the plastic bag which cover appliance. Carefully put down the the machine. appliance with the rear side on it. 5.

  • Page 36: Positioning

    8. Remove the three transit bolts 9. Pull out the plastic spacers. 11.2 Positioning It is important that your washing machine stands fi rm and leveled on the fl oor to ensure correct operation. The appliance must not be installed behind a lockable...

  • Page 37: Water Inlet

    ENGLISH 11.3 Water Inlet Loosen or tighten the feet to adjust the level. A correct adjustment of the Connect the water inlet hose to a tap with appliance level prevents vibration, noise 3/4” BSP thread. and the movement of the appliance when Use the hose supplied with the washing in operation.
  • Page 38 Fitting House Guide • In a sink, drain pipe branch. This branch must be above the trap so that the bend is at least 60 cm above the ground. Pull apart to Hose bend insert hose. Guide hose Max.

  • Page 39: Electrical Connection

    ENGLISH 11.5 Electrical Connection This machine is designed to operate on CAUTION! a 220-240 V, single-phase, 50 Hz supply. Connect the machine to an “An incorrect power supply may void earthed socket outlet. your warranty.” The manufacturer declines any Check that your domestic electrical responsibility for damage or installation can take the maximum load injury through failure to comply...

  • Page 40: Wi-Fi Connectivity Setup

    Terms and and open source software. Electrolux Conditions and Electrolux’s Privacy Policy in the gratefully acknowledges the contributions app to use the connected features of the laundry of the open software and robotics appliance.

  • Page 41: Remote Start

    ENGLISH Wait for confi rmation of connection 13.2 Remote Start which may take up to a minute before When the App is installed and the proceeding to the next step. wireless connection is complete, you can For iOS devices, you will then be start and stop a programme remotely by prompted go to “SETTINGS”...
  • Page 42 External inlet water filter are not designed to be used with hot water.
