- Page 1 EclDisplay CRMX FC 40W RGB+WW LED Spotlight with Wireless CRMX and wired control, without lens USER MANUAL English version Rev.01 - 07/24...
- Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY...
-
Page 3: Table Of Contents
HALF SNOOT, FULL SNOOT (CODES ECLDISPHSNOOT, ECLDISPFSNOOT - OPTIONAL) ........................30 CEILING ADAPTER KIT (CODES ECLDISPCEILKIT, ECLDISPCEILFLG - OPTIONAL) ..31 12 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............34 VISUAL CHECK OF PRODUCT HOUSING ..............34 TROUBLESHOOTING ..................... 35 PROLIGHTS - EclDisplayCRMX FC... -
Page 4: Safety Information
• Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. - Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
- Page 6 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - EclDisplayCRMX FC...
-
Page 7: Packaging
• NASPW12SK35M: global Pulse Track clip wire suspension set 5m, 150N, white; • NASKB122/3: global Pulse Track Mounting Clamp for Rod and Wire, 200N, black/white; • NAXTSC6212/3: global Pulse XTS Connector 3-CCT DALI straight connector, black/white. PROLIGHTS - EclDisplayCRMX FC... -
Page 8: Technical Drawing
185 mm 349 mm [7.3 in] [13.7 in] Ø97 mm Ø97 mm [3.8 in] [3.8 in] Ø97 mm [3.8 in] Weight: TBD kg - TBD lbs ECLDISPLAYCRMXFC with ECLDISPPHDZL2040 Fig. 01 PROLIGHTS - EclDisplayCRMX FC Ø59 mm Ø59 mm [Ø2.3 in]... - Page 9 193 mm [7.6 in] Ø99 mm 185 mm 343 mm [3.9 in] [7.3 in] [13.5 in] Weight: 2.19 kg - 4.82 lbs ECLDISPLAYCRMXFC with ECLDISPPRZL1020 Ø99 mm [3.9 in] Fig. 02 PROLIGHTS - EclDisplayCRMX FC Ø60 mm [Ø2.4 in] Ø99 mm...
- Page 10 [3.9 in] Ø60 mm [Ø2.4 in] 154 mm [6.1 in] 185 mm 304 mm [7.3 in] [12.0 in] Ø82 mm [3.2 in] Weight: 1.99 kg - 4.38 lbs ECLDISPLAYCRMXFC with ECLDISPPRZL2040 PROLIGHTS - EclDisplayCRMX FC...
-
Page 11: Tilt Range
4 - TILT RANGE TILT RANGE: 135° Fig. 03 PROLIGHTS - EclDisplayCRMX FC... -
Page 12: Installation
Do not use any type of clamp that does not completely encircle the structure when fastened. C6002 clamp RSR0630A/B Steel security cable Track system 17 [0.7] 97 [3.8] Ø4 [Ø0.2] Ø13 [Ø0.5] Dimensions are in mm / in - Fig. 04 PROLIGHTS - EclDisplayCRMX FC... -
Page 13: Connection To The Mains Supply
(earthed) plug, following the plug manufacturer’s instructions. If you have any doubts about proper installation, consult a qualified electrician. The max power consumption is 35W. Remove the plastic cover to acces to the screw terminal blocks. Fig. 06 PROLIGHTS - EclDisplayCRMX FC... -
Page 14: Connection To Mains Via Terminal Block
CONNECTION TO MAINS VIA TERMINAL BLOCK Fig. 07 CONNECTION TO DMX LINE VIA TERMINAL BLOCK Fig. 08 PROLIGHTS - EclDisplayCRMX FC... -
Page 15: Start Up
5. RUBBER RING (accessory included in the box optic); 6. KNOB for adjusting dimmer or CCT (only VW version); 7. REMOVABLE PLASTIC COVER to access to the screw terminal blocks; 8. PLASTIC ARM COVER; 9. LOCK TILT. Fig. 09 PROLIGHTS - EclDisplayCRMX FC... -
Page 16: Rdm Functions
0x0201 DIMMER_INFO 0x0340 CURVE 0x0343 CURVE_DESCRIPTION 0x0344 Dimmer Settings OUTPUT_RESPONSE_TIME 0x0345 OUTPUT_RESPONSE_TIME_ DESCRIPTION 0x0346 MODULATION_FREQUENCY 0x0347 MODULATION_FREQUENCY_ DESCRIPTION 0x0348 DEVICE_HOURS 0x0400 LAMP_HOURS 0x0401 LAMP_STRIKES 0x0402 Power/Lamp Settings LAMP_STATE 0x0403 LAMP_MODE 0x0404 DEVICE_POWER_CYCLES 0x0405 Control IDENTIFY_MODE 0x1040 PROLIGHTS - EclDisplayCRMX FC... - Page 17 0x82E0 0-255 0: No CLEAN ALL DATA 0x82C8 1: Yes 0: No WIRELESS 0x8212 1: Yes 0: No WIRELESS RESET 0x8215 1: Yes 0: No error ERROR MESSAGES 0x82EA 1.Temperature too high 2.LED temperature sensor error PROLIGHTS - EclDisplayCRMX FC...
- Page 18 To check the current working hours of RESET) the unit. SOURCE HOURS (READ AND To see the total operating hours of the RESET) LED source. POWER ON CYCLE (READ AND To see the power cycles of the machine. RESET) PROLIGHTS - EclDisplayCRMX FC...
- Page 19 3600K 0 - 255 3800K 0 - 255 4000K 0 - 255 4200K 0 - 255 4400K 0 - 255 4600K 0 - 255 4800K 0 - 255 5000K 0 - 255 5200K 0 - 255 PROLIGHTS - EclDisplayCRMX FC...
- Page 20 7000K 0 - 255 8000K 0 - 255 9000K 0 - 255 10000K 0 - 255 0 - 255 MANUAL 0 - 255 GREEN 0 - 255 BLUE 0 - 255 WARM WHITE 11 FACTORY DEFAULT PROLIGHTS - EclDisplayCRMX FC...
-
Page 21: Dmx Charts
16 bit value Function Note From From Open Default @ 255 Strobe from Slow to Fast Open Pulse In from slow to fast Close Pulse Out from slow to fast Open Random from slow to fast Open PROLIGHTS - EclDisplayCRMX FC... - Page 22 7000 7100 38229 39139 7100 7200 39139 40049 7200 7300 40049 40959 7300 7400 40959 41870 7400 7500 41870 42780 7500 7600 42780 43690 7600 7700 43690 44600 7700 7800 44600 45510 7800 7900 45510 46421 PROLIGHTS - EclDisplayCRMX FC...
- Page 23 16 bit value Function Note From From 0 - 100% 65535 Default @ 255 / 65535 Warm White 8 bit value 16 bit value Function Note From From 0 - 100% 65535 Default @ 255 / 65535 PROLIGHTS - EclDisplayCRMX FC...
- Page 24 Steel Blue Medium Blue-Green Peacock Blue Magenta Dark Pink Middle Rose Light Salmon English Rose Light Rose Orange Deep Amber Straw Light Amber Spring Yellow Dark Yellow Green Just Blue Sky Blue Lavender Light Lavender Pink Carnation PROLIGHTS - EclDisplayCRMX FC...
- Page 25 Lee Minus Green Pale Gold Orange Deep Straw Rose Purple Deep Purple Soft Green Reserved 2800K 3000K 3200K 3400K 3600K 3800K 4000K 4200K 4400K 4600K 4800K 5000K 5200K 5400K 5600K 6000K 6500K 7000K 8000K 9000K 10000K Full ON PROLIGHTS - EclDisplayCRMX FC...
- Page 26 LED FREQUENCY 4000HZ LED FREQUENCY 6000HZ LED FREQUENCY 25KHZ STAND ALONE MASTER DMX STAND ALONE MASTER NO DMX STAND ALONE SLAVE DMX FAULT HOLD DMX FAULT BLACKOUT DMX FAULT STAND ALONE Reserved FACTORY DEFAULT OF CONTROL FUNCTIONS Reserved PROLIGHTS - EclDisplayCRMX FC...
-
Page 27: Accessories Installation
NOTE: the mounting procedure described below is the same for all lenses. Loosen the two marked knob of the ECLDISPLAY. Insert the optic (2-A) and rotate it (2-B) so the marked grooves (3) of the optic coincides with the four marked flaps of the unit (4). PROLIGHTS - EclDisplayCRMX FC... - Page 28 The marked lever in position A allows the locking of the blades. Rotating the lever to position B or C allows the release of the blades. This operation must be repeated for both levers on the frame system. Fig. 10 PROLIGHTS - EclDisplayCRMX FC...
-
Page 29: Barndoor And Filter Frame (Code Ecldispbdnffb - Optional)
(3). Insert the holder from above throught the track Move the marked rod down (6). (4). Then insert the barn door (5). Fig. 11 PROLIGHTS - EclDisplayCRMX FC... -
Page 30: Anti-Glare Louvre (Code Ecldisplouvre - Optional)
NOTE: the rubber ring can also be used to fix a filter with a maximum diameter of 79 mm. Anti-glare louvre Rubber ring Insert the anti-glare louvre or a filter of maximum size of Ø79 mm into the rubber ring. Mount the anti-glare louvre with the rubber ring on the optic. Fig. 12 PROLIGHTS - EclDisplayCRMX FC... -
Page 31: Gobo Holder (Code Ecldispgobohind - Optional)
To mount the gobo remove the spring (1) from the gobo holder. Then insert the gobo following the sequence of image 2. Loosen the two marked knobs of the optic (3). Then move the cover plate (4). Insert the gobo holder into the slot provided on the optic (5). Fig. 13 PROLIGHTS - EclDisplayCRMX FC... -
Page 32: Half Snoot, Full Snoot (Codes Ecldisphsnoot, Ecldispfsnoot - Optional)
Loosen the three marked knob. Insert the half snoot on the optic and tighten the knobs in the egraved ring. Loosen the three marked knob. Insert the full snoot on the optic and tighten the knobs in the egraved ring. Fig. 14 PROLIGHTS - EclDisplayCRMX FC... -
Page 33: Ceiling Adapter Kit (Codes Ecldispceilkit, Ecldispceilflg - Optional)
230 mm 100 mm 35 mm [1.4 in] [3.9 in] [9.1 in] [3.9 in] [1.4 in] 110 mm [4.3 in] Ø200 mm [7.9 in] Measurements for cuts on the panels (1) and of the ECLDISPCEILFLG (2). PROLIGHTS - EclDisplayCRMX FC... - Page 34 Mount the marked ceiling adapter kit on the ceiling by tightening the screws in the marked points (4). Fit the M6 screw to fix the projector (placed upside down) in the holes provided in the back housing (see detail). Fit the M4 screw to lock rotation. PROLIGHTS - EclDisplayCRMX FC...
- Page 35 (6). Tighten the M4 screw (6) to lock the vertical movement of the plate. Mount the flange tightening the two marked screws (7) to complete the ceiling adapter kit. Fig. 15 PROLIGHTS - EclDisplayCRMX FC...
-
Page 36: Maintenance
WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel. -
Page 37: Troubleshooting
Timeout error after fixture • One or more hardware • Check product stored error messages for more reset. • components requires information. Contact PROLIGHTS Service or an • mechanical adjustments authorized service partner. Mechanical effect loses • Mechanical hardware •... - Page 38 Note...
- Page 39 Note...
- Page 40 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
