Summary of Contents for EMPERO EMP.6FE010
-
Page 1: Table Of Contents
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page... -
Page 2: Ageneral Information
ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Electric Fryers ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.6FE010 400x635x285 480x760x600 EMP.6FE020 600x660x285 700x760x600 EMP.PLS.7FE010 400x760x316 480X860X620 EMP.PLS.7FE020... -
Page 4: A3 Transportation
ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can be moved by hand from area to area.Do not crash and drop the appliance while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ... -
Page 6: Doperation
ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Heat setting button B : Indicator lamp C : Sliding attachment * Operating; • Before operating the fryer,place filter and filter into the tank. • Turn the sliding ratchet that is on oil evacuation pipet o the left and turn off the drainage taps. -
Page 7: Ecleaning & Maintenance
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Always turn off the appliance and disconnect from the power supply before cleaning. • Clean the outer surface of the appliance with a wet cloth and chrome shiner. •... -
Page 8: Ftroubleshooting
ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. Check the resistances. Check the level of oil. THE APPLIANCE DOESN’T FRY WELL Check the thermostat switch.If the oil can not be heated as desired,contact with authorized service. -
Page 9: Gspare Part List-Exploding Drawing
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.6FE010... - Page 10 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.6FE010 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE 243MM LONG HANDLE M.AKS-KLP-LUX-003 TOP COVER SHEET YSC-KNX.SNC-LZ-0204 26*20*12 CM BASKET M.AKS-SPT-INX-002 16CM HANDLE M.AKS-KLP-BKL-007 BASKET BOTTOM SHEET YSC-KNX.SNC-PN-0139 RESISTANCE CONNECTION S/S TOP SHEET YSC-KNX.SNC-LZ-0243...
- Page 11 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.6FE020...
- Page 12 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.6FE020 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE 243MM LONG HANDLE M.AKS-KLP-LUX-003 TOP COVER SHEET YSC-KNX.SNC-LZ-0194 26*20*12 CM BASKET M.AKS-SPT-INX-002 16CM HANDLE M.AKS-KLP-BKL-007 BASKET BOTTOM SHEET YSC-KNX.SNC-PN-0139 RESISTANCE CONNECTION S/S TOP SHEET YSC-KNX.SNC-LZ-0243 121967 230V 2400W RESISTANCE M.ELK-RZS-BRU-FRT-014...
- Page 13 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.7FE010...
- Page 14 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.PLS.7FE010 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE 180 °C THERMOSTAT M.ELK-MEK-TRM1-022 230 °C LIMITOR M.ELK-MEK-LMT-015 FRONT PANEL YSC-KNX.PG7-LZ-0662 BUTTON SOCKET 6 MM M.AKS-DGM-SKT-002 100-180 °C BUTTON BUFFER M.AKS-DGM-EMP-023 BUTTON M.AKS-DGM-EMP-024 TICKET M.AKS-OZL-MTL-006...
- Page 15 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.7FE020...
- Page 16 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.PLS.7FE020 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE 180 °C THERMOSTAT M.ELK-MEK-TRM1-022 230 °C LIMITOR M.ELK-MEK-LMT-015 FRONT PANEL YSC-KNX.PG7-LZ-0392 BUTTON SOCKET 6 MM M.AKS-DGM-SKT-002 100-180 °C BUTTON BUFFER M.AKS-DGM-EMP-023 BUTTON M.AKS-DGM-EMP-024 TICKET M.AKS-OZL-MTL-006...
- Page 17 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.9FE010...
- Page 18 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.PLS.9FE010 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE 243MM LONG HANDLE M.AKS-KLP-LUX-003 TOP COVER SHEET YSC-KNX.PG9-LZ-0430 BASKET M.AKS-SPT-INX-005 16CM HANDLE M.AKS-KLP-BKL-007 BASKET BOTTOM SHEET YSC-KNX.PG9-PN-0562 SUPPORT SHEET YSC-KNX.PG7-LZ-0545 121968 230V 6000 W L:34 RESISTANCE M.ELK-RZS-BRU-FRT-024 SUPPORT SHEET YSC-KNX.PG7-LZ-0546...
- Page 19 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.9FE020...
- Page 20 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE : EMP.PLS.9FE020 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE 243MM LONG HANDLE M.AKS-KLP-LUX-003 TOP COVER SHEET YSC-KNX.PG9-LZ-0430 16CM HANDLE M.AKS-KLP-BKL-007 BASKET BOTTOM SHEET YSC-KNX.PG9-PN-0562 SUPPORT SHEET YSC-KNX.PG7-LZ-0545 121968 230V 6000 W L:34 RESISTANCE M.ELK-RZS-BRU-FRT-024 SUPPORT SHEET YSC-KNX.PG7-LZ-0546...
-
Page 21: Helectric Circuit Schema
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları RESISTANCE CONEXION SHEET YSC-KNX.PG7-LZ-0334 ELECTRIC CIRCUIT SCHEMA EMP.PLS.9FE010 Thermostat Rezistans Limit Switch Contactor (135-180ºC) 3x3500W... - Page 22 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.PLS.7FE010...
- Page 23 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.PLS.9FE020 T1.T2 LS1.LS2 C1.C2 L1.L2 R1.R2 Thermostat Thermostat Resistance Limit Switch Contactor (135-180ºC) signal lamp 6X6000...
- Page 24 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.PLS.7FE020 T1.T2 LS1.LS2 C1.C2 R1.R2 Thermostat Rezistans Limit Switch Contactor (135-180ºC) 3X3500...
- Page 25 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.6FE010 Thermostat Thermostat Resistance Limit switch Contactor (50-180ºC) signal lamp 3X2400...
- Page 26 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.6FE020 T1.T2 LS1.LS2 C1.C2 L1.L2 R1.R2 Thermostat Limit Thermostat Resistance Contactor (50-180ºC) switch signal lamp 6X2400...
