Page 1: Table Of Contents
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page... -
Page 2: Ageneral Information
ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Electric Fryers ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.7FE010 400x730x285 480x800x590 EMP.7FE020 800x730x285 780x830x1050 EMP.9FE010 400x900x850 430x950x1050 EMP.9FE020... -
Page 4: A3 Transportation
ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can be moved by hand from area to area.Do not crash and drop the appliance while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ... -
Page 6: Doperation
ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Heat setting button B : Indicator lamp * Operating; • Before operating the fryer,place filter and filter into the tank. • Turn off the valve that is in fryer. •... -
Page 7: Ecleaning & Maintenance
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Always turn off the appliance and disconnect from the power supply before cleaning. • Clean the outer surface of the appliance with a wet cloth and chrome shiner. •... -
Page 8: Ftroubleshooting
ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. Check the resistances. Check the level of oil. THE APPLIANCE DOESN’T FRY WELL Check the thermostat switch.If the oil can not be heated as desired,contact with authorized service. -
Page 9: Gspare Part List-Exploding Drawing
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.7FE010... - Page 10 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.7FE010 PRODUCT NAME P.CODE HANDLE Y.EMP.7FE010.001 Y.EMP.7FE010.002 BASKET HANGER SHEETMETAL Y.EMP.7FE010.003 RESISTANCE Y.EMP.7FE010.004 BASKET Y.EMP.7FE010.005 BASKET BOTTOM SHEETMETAL Y.EMP.7FE010.006 RESISTANCE CONNECTION MIDDLE TOP Y.EMP.7FE010.007 SHEETMETAL CONTACTOR MTF41 Y.EMP.7FE010.008...
- Page 11 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.9FE010...
- Page 12 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.9FE010 PRODUCT NAME P.CODE HANDLE Y.EMP.9FE010.001 Y.EMP.9FE010.002 BASKET HANGER SHEETMETAL Y.EMP.9FE010.003 RESISTANCE Y.EMP.9FE010.004 BASKET Y.EMP.9FE010.005 BASKET HOLDER Y.EMP.9FE010.006 RESISTANCE CONNECTION MIDDLE TOP Y.EMP.9FE010.007 SHEETMETAL CONTACTOR 3TF41 Y.EMP.9FE010.008 BASE FRAME Y.EMP.9FE010.009...
- Page 13 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.7FE020...
- Page 14 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.7FE020 PRODUCT NAME P.CODE HANDLE Y.EMP.7FE020.001 Y.EMP.7FE020.002 BASKET HANGER SHEETMETAL Y.EMP.7FE020.003 RESISTANCE Y.EMP.7FE020.004 BASKET Y.EMP.7FE020.005 BASKET BOTTOM SHEETMETAL Y.EMP.7FE020.006 RESISTANCE CONNECTION MIDDLE TOP Y.EMP.7FE020.007 SHEETMETAL CONTACTOR 3TF41 Y.EMP.7FE020.008 BASE FRAME Y.EMP.7FE020.009...
- Page 15 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.9FE020...
- Page 16 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.9FE020 PRODUCT NAME P.CODE HANDLE Y.EMP.9FE020.001 Y.EMP.9FE020.002 BASKET HANGER SHEETMETAL Y.EMP.9FE020.003 RESISTANCE Y.EMP.9FE020.004 BASKET Y.EMP.9FE020.005 BASKET HOLDER Y.EMP.9FE020.006 RESISTANCE CONNECTION MIDDLE TOP Y.EMP.9FE020.007 SHEETMETAL CONTACTOR 3TF41 Y.EMP.9FE020.008 BASE FRAME Y.EMP.9FE020.009...
-
Page 17: Helectric Circuit Schema
ELECTRIC FRYERS Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.7FE010 Thermostat (135-180ºC) Limit Switch Contactor Thermostat signal lamp Resistance... - Page 18 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.7FE020 T1.T2 LS1.LS2 C1.C2 L1.L2 R1.R2 Thermostat (135-180ºC) Limit Switch Contactor Thermostat signal lamp Resistance...
- Page 19 ELECTRIC FRYERS Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.9FE010 Thermostat (135- Limit thermostat Limit Thermostat Contactor Resistance 180ºC) 230ºC Switch signal lamp...
- Page 20 ELECTRIC FRYERS ELEKTRİKLİ FRİTÖZLER ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.9FE020 T1.T2 LT1.LT2 LS1.LS2 C1.C2 L1.L2 R1.R2. Limit Thermostat Limit Thermostat Resistance thermostat Contactor (135-180ºC) Switch signal lamp 4000W 230V 230ºC...
