Ocean CVK 397 NF X A+ Service Manual

Vertica freezer
Hide thumbs Also See for CVK 397 NF X A+:

Advertisement

Quick Links

Download this manual
VERTICA FREEZER
SERVICE MANUAL
Model
CVK 397 NF X A+
Specifications are subject to possible modifications without prior notice.
Les présentes spécifications sont susceptibles d'être modifiées sans préavis.
Las especificaciones estàn sujetas a cambios sin previo aviso
Pictures of indoor or outdoor units are only sketches which may be different from your equipment.
Les images de l'unité intérieure ou extérieure sont seulement de croquis qui peuvent être différentes du design de votre
équipement.
Las imágenes de unidades de interior o exteriores son sólo los bosquejos que pueden ser diferentes de su equipo.
... someone to rely on

Advertisement

loading
Need help?

Need help?

Do you have a question about the CVK 397 NF X A+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ocean CVK 397 NF X A+

Summary of Contents for Ocean CVK 397 NF X A+

  • Page 1 VERTICA FREEZER SERVICE MANUAL Model CVK 397 NF X A+ Specifications are subject to possible modifications without prior notice. Les présentes spécifications sont susceptibles d'être modifiées sans préavis. Las especificaciones estàn sujetas a cambios sin previo aviso Pictures of indoor or outdoor units are only sketches which may be different from your equipment. Les images de l’unité...
  • Page 2 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT Display and Control Panel 1. It enables the setting value of fridge to be modified and super cool mode to be activated if desired. Freezer may be set to -16,-18,-20,-22,-24 °C, SF. 2.
  • Page 3 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT Display and Control Panel Temperature adjustment and activating SUPER COOLING Mode Initial temperature value for Freezer Setting Indicator is -18 °C. • Press set button once. • When you first push this button, the last value appears on the setting indicator of the freezer.
  • Page 4 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT Fault Codes Sensor short open circuit defect on display USER MODE SERVICE MODE SENSOR TEMPERATURE REACTION REACTION >+50°C or <-50°C (1) Freezer -16 Set Symbol blinks (sensor is short or open) (2) Refrigerator (3) Defrost Short (<...

  • Page 5: Service Mode

    VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT Service Mode Entering service mode: Push SET button continuously for 10 seconds when -24 set symbol active. Appliance will enter service mode 10 sec. later. Canceling service mode: Push SET button continuously for 10 seconds when -24 set symbol active. Appliance will enter service mode 10 sec.

  • Page 6: Reversing The Door

    VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT REVERSING THE DOOR 1. Hold the top hinge cover and remove it toward 2.Unscrew the screws fixing the top hinge that direction (Picture-1) and remove it. (Picture-2) Picture-1 Picture-2 3. Displace the door (Picture-3) Picture-3...
  • Page 7 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT REVERSING THE DOOR 4. Unscrew the adjustable foot (Picture-4) 5. Unscrew the bottom hinge screws. (Picture-5) Picture-4 Picture-5 7. Screw the bottom hinge to the left bottom 6. Unscrew the bottom hinge pin and side of refrigerator.
  • Page 8 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT REVERSING THE DOOR 9. Remove the hinge cover on the top panel and replace to other side.(Picture-9) Picture-9 10. Place the door to the bottom hinge and 11. Place the top hinge cover. (Picture-11) screw the top hinge to the top panel.
  • Page 9 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT ASSEMBLE & DISASSEMBLE OF AIR DUCT Warning: Make sure the unit is unplugged. 1. Remove the refrigerator glass shelves and the flap cover supports left and right. (Picture-1 / Picture-2) Picture-1 Picture-2 2.

  • Page 10: Customer Support

    VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT ASSEMBLE & DISASSEMBLE OF FAN MOTOR 1. Remove the fan motor connector, unscrew the fan motor fixing screws and displace the fan motor and remove the propeller. (Picture-1 / Picture-2) Picture-1 Picture-2 2.
  • Page 11 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT ASSEMBLE & DISASSEMBLE OF FIN EVAP Warning: This process needs gas deflation, gas re-charging and welding processes so its need to be done by trained professionals. 1. Take out the fin evap heater (blue) connector and remove the bitumen covering the tubes. (Picture-1 / Picture-2) Picture-1 Picture-2...
  • Page 12 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT ASSEMBLE & DISASSEMBLE DISPLAY Replacement Head Panel Display 1. By aid of a flat screwdriver or smilar tools remove taps and then unscrew 2. Unhook snapfits on the head panel by reaching from related cavities and pull head panel backward 3.
  • Page 13 VERTICAL FREEZER CVK 397 NF X A+ CUSTOMER SUPPORT ASSEMBLE & DISASSEMBLE SENSOR Remove the freezer sensor cover by pulling forward and disconnect sensor connector. (Picture-1 / Picture-2) Picture-2 Picture-1 Warning: Pay attention not to damage to the sensor cover details! ASSEMBLE &...
