Signal name
Pin (J1)
29
LCD_D9_LD4N
30
LCD_D10_LCK0P
31
LCD_D11_LCK0N
32
LCD_D12_LD5P
33
LCD_D13_LD5N
34
LCD_D14_LD6P
35
LCD_D15_LD6N
36
LCD_D16_LD7P
37
LCD_D17_LD7N
38
LCD_D18_LD8P
39
LCD_D19_LD8N
40
LCD_D20_LD9P
41
LCD_D21_LD9N
42
LCD_D22_LCK1P
43
LCD_D23_LCK1N
44
GND
45
MIPI_TX/RX_CLKN
46
MIPI_TX/RX_D0P
47
MIPI_TX/RX_CLKP
48
MIPI_TX/RX_D0N
49
MIPI_TX/RX_D2N
50
MIPI_TX/RX_D1N
51
MIPI_TX/RX_D2P
52
MIPI_TX/RX_D1P
53
MIPI_TX/RX_D3P
54
GND
55
MIPI_TX/RX_D3N
56
DVP_PWR
57
HSIC_STROBE
58
HSIC_DATA
59
GND
60
CIF_D1
61
CIF_D0
62
CIF_D3
63
CIF_D2
64
CIF_D5
65
CIF_D4
66
CIF_D7
67
CIF_D6
Customize the embedded system based on
Fuction 1
LCD Data9 or LVDS Differential Data4-
LCD Data10 or LVDS Differential Clock0+
LCD Data11 or LVDS Differential Clock0-
LCD Data12 or LVDS Differential Data5+
LCD Data13 or LVDS Differential Data5-
LCD Data14 or LVDS Differential Data6+
LCD Data15 or LVDS Differential Data6-
LCD Data16 or LVDS Differential Data7+
LCD Data17 or LVDS Differential Data7-
LCD Data18 or LVDS Differential Data8+
LCD Data19 or LVDS Differential Data8-
LCD Data20 or LVDS Differential Data9-
LCD Data21 or LVDS Differential Data9+
LCD Data22 or LVDS Differential Clock1+
LCD Data23 or LVDS Differential Clock1-
Power Ground
MIPI Clock negative signal input
MIPI data pair 0 positive signal input
MIPI Clock positive signal input
MIPI data pair 0 negative signal input
MIPI data pair 2 negative signal input
MIPI data pair 1 negative signal input
MIPI data pair 2 positive signal input
MIPI data pair 1 positive signal input
MIPI data pair 3 positive signal input
Power Ground
MIPI data pair 3 negative signal input
HSIC_STROBE
HSIC_DATA
Power Ground
HOST_D1 or TS_D1
HOST_D0 or TS_D0
HOST_D3 or TS_D3
HOST_D2 or TS_D2
HOST_CKINN or TS_D5
HOST_CKINP or TS_D4
8
Your Idea
IO Type
Fuction 2
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
P
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
P
I/O
GPIO0_C1_d
I/O
P
GPIO2_B5_d
I/O
GPIO2_B4_d
I/O
GPIO2_A1_d
I/O
GPIO2_A0_d
I/O
GPIO2_A3_d
I/O
GPIO2_A2_d
I/O
GPIO2_A5_d
I/O
GPIO2_A4_d
I/O
