–One 8-channels I2S/PCM interface, One 8-channels SPDIF interface
–One USB2.0 OTG, Two USB2.0 Host
–100M/1000M RMII/RGMII Ethernet interface
–Dual channel TS stream interface, descramble and demux support
–Smart Card interface
–4-CH UART, 2-CH SPI (option), 6-CH I2C(up to 4Mbps), 2-CH PWM(option)
–PS/2 master interface
–HSIC interface
–3-CH ADC input

1.3 MINI3288 Features

Feature
Specifications
CPU
RK3288 Quad-core ARM Cortex-A17 MPCore processor
Memory
Default 512MB DDR3L
NAND Flash
8GB eMMC Flash
Power
DC 3.6V-5V power supply
PMU
ACT8846
UART
4-CH (up to 5-CH, option by SPI0)
RGB
24-bit
LVDS
1-CH 10bit Dul-LVDS
Ethernet
1 Gigabit (RTL8211 on board)
USB
2-CH USB2.0 Host, 1-CH USB2.0 OTG
SPDF
1-CH
CIF
1-CH DVP 8-bit and MIPI CSI
HDMI
1-CH
PS2
1-CH
ADC
3-CH
PWM
2-CH (up to 4-CH, option by UART2)
IIC
5-CH
AUDIO IF
1-CH
SPI
2-CH
HSMMC/SD
2-CH
Dimension
70 x 58 mm
Customize the embedded system based on
4
Your Idea
